Fast Direct GPS Signal Acquisition Using FPGA

1
Fast Direct GPS Signal Acquisition Using FPGA

• Jing Pang
• Janusz Starzyk

School of Electrical Engineering and Computer
Science Ohio University Athens, OH U. S. A.
2
Outline

• Direct P-code Acquisition Overview
• GPS Background
• GPS signal structure
• Parallel code phase search for signal acquisition
• P-code Generator Architecture
• P-code Tuning Model
• P-code Property
• Noncircular convolution with zero padding
• Autocorrelation and acquisition margin
• Direct Average Method
• Design Platform, Design Flow and Hardware
  Architecture
• Summary

3
Direct P-code Acquisition

• Time domain acquisition
• Massive physical parallel correlators
• FFT search
• Most of the reported approaches require large
  size FFT
• New approach
• Direct average
• Small size FFT for FPGA implementation

4
GPS Signal Structure
Modulo-2 summation
Mixer
Summation
5
GPS Receiver Acquisition
6
Parallel Code Phase Search
FFT-based Circular Correlator
Digital IF
Code Generator
Y
N
Carrier Generator
peak detected ?
more freq. bins ?
N
Y
Failed
Acquired
Acquisition Result
7
Circular Correlator
A?B
a ? b
a
A
FFT
IFFT
b
B
B
Conjugation
FFT
8
GPS P-code Generator
Short cycle 4092, 4093 Held after 3749 short
cycles 7 Day Reset Extra 37 chips Generate
P-code Different satellites
9
LFSR X1 And X2
X1B
X1A
X2B
X2A
10
Epochs
11
P-codes Reset Timing
12
P-code Generator Tuning Model
z1a index to the X1A LFSR State at the
specified Time
x1a divide-by 3750 counter
y1a z-counter value
13
P-code Property

• Circular convolution for periodic code
• Circular convolution with zero padding

14
P-code Property

• Each satellite uses unique P-code to implement
  CDMA technique

15
Acquisition Margin

• Mean value of acquisition margin 25.954
• Standard deviation 1.841
• Each acquisition margin value is obtained over 1
  ms

16
Direct Average Method

• Direct average method is proposed due to the
  extremely long period of P-code
• Direct average over 128 samples autocorrelation
  result
• Summation of correlation results for 15 1-ms
  windows

17
Direct Average Method

• Acquisition margin distribution over 1 s.
• The mean value of the acquisition margin 26.882
• The standard variation 2.676

18
Design Platform

• Nallatech Board

PCs PCI interface
19
Xilinx VirtexE Architecture

• Overall architecture
• One Slice of a CLB
• IOB
• GRM

20
Design Flow
Design Entry
Functional Simulation Timing Simulation
User C Application
Design Synthesis
Nallatech DLL Software Interface Nallatech
Custom Hardware Interface
Mapping
Placement
Routing

VirtexE chip
Bit File
21
FPGA Design Partition
Average
IFFT Processor
FFT Processor
GPS signal
Average
Local reference generation unit
Local Reference FFT Processor
NCO
Maximum selection Other control decision logic
Correlation peak peak location
2
22
VirtexE FPGA Design Cost

• 1. NCO 2. P-code generator 3. Average
  4. FFT 5. IFFT 6. Complex conjugate
  multiplication
• 7. Correlation amplitude square
• 8. Peak selection and decision logic
• Total available CLB slices 15552
• Total available Block Rams 144

23
Summary

• Flexible GPS P-code generator tuning model
• Produce P-code starting from any time of a GPS
  week
• Direct Average Method
• Improve acquisition speed
• Simplify FPGA hardware design
• Hardware FPGA implementation
