Electronic Project Kit

1
Electronic Project Kit

• Grant Ellington
• North Carolina State University

Biological Agricultural Engineering
2
Objectives

• Learn to read and follow an electric schematic
• Identify electronic circuit components
• Function of circuit components
• How to solder correctly
• Promote Science and Technology

3
General Instructions

• Refer to Figure 1 for parts layout and parts list
• Refer to Assembly Instructions step 1-3
• Suggested assembly order
• Install resistors first (especially if new to
  soldering)
• Install IC socket (notch down), trimmer resistor
  (P1) and LEDs
• Solder 9V snap plus wire to switch and board
• Solder thermistor to wire pair and board
• Install IC Chip (notch down)

4
Temperature Warning Kit
5
Top Edge
Front Side
Back Side
6
(No Transcript)
7
Correct Solder Joints
8
Resistor
Provides resistance to impede the flow of
current or electrical charge Limits the
current in desired components of a circuit
22K Ohm
10 Ohm
Variable
9
Resistor Value
1st numeric value 2nd numeric value 3rd
multiplier 4th tolerance
1st band
4th band
2nd band
3rd band
Refer to Resistor Color Code (Kit Instructions
Figure 5)
10
Resistors Positioned Correctly
R1
R2, R3
R4
11
Integrated Circuit (IC)
Multiple circuit components processed or
contained in a single substrate or chip
IC Socket
IC Chip
12
LED (Light Emitting Diode)

• Emit light in response to
• small voltage
• Polarity sensitive
• Anode
• Cathode (short leg)

Flat Side (Notch)
Short Leg (-)
(-)
()
Refer to LED Info (Kit Instructions Figure 4)
13
On-Off Switches
SPST - Single Pole Single Throw
Push Button Momentary
Toggle
SPDT - Single Pole Double Throw (3-way)
DPDT - Double Pole Double Throw
14
Switch and 9V Battery Snap
(red)
- (black)
15
Thermistor

• Temperature sensing device
• Resistance changes with
• temperature
• Negative coefficient type
• Limited range

16
Thermistor Connection
Heat Shrink Tubing
Solder to board
17
Additional Resources

• 4-H Electric Curriculum Project Guides
• Entering Electronics
• Soldering and Troubleshooting Tips on Electric
  Program web page
