WebAccess HMI

1
WebAccess HMI SCADA softwareProduct Overview

2
What Is WebAccess Software?

• Web Browser-based
• HMI and SCADA software
• For industrial control systems
• And facilities automation.

HMI  Human Machine Interface
SCADA  Supervisory Control and Data Acquisition
3
Industry Applications

• Building Automation
• Energy Power
• Petroleum Chemicals
• Semiconductor
• Transportation
• Water Wastewater

HMI  Human Machine Interface
SCADA  Supervisory Control and Data Acquisition
4
Web Browser HMI SCADA

• View and control
• Automation equipment.
• via PLCs, Controllers, IO
• In real-time
• Using an ordinary web browser
• Internet explorer 5.5 or 6.0
• Unofficially, Netscape navigator 6.1
• Animated graphics
• Rotate, color change, motion across screen
• Trends data logging
• Alarms, recipes, scheduler more

5
What makes WebAccess unique?

• Web browser based Engineering!
• Build Graphics (DRAW).
• Configure Tags, Alarms, Recipes, Schedules and
  databases.
• Download, Start and Stop Nodes.
• Using Internet Explorer 5.5 or 6.0
• Unofficially Netscape Navigator 6.1
• Remotely support customers
• Reduce trips to field.
• Faster customer response.
• Reduce startup and down time.
• Engineering Tool is independent of software
  version installed at customers site.
• Engineers technicians always have the right
  version of software needed.

6
What makes WebAccess unique?

• Ordinary Web Server
• Microsoft IIS
• standard option in Windows NT, 2000, Server
  2003, and XP.
• Redundant SCADA node
• standard feature.
• Redundant Communication Ports
• Standard feature, If device driver protocol
  support this.
• A true Thin Client
• Any web browser and any pocket PCs, PDA and
  handheld using Windows CE.
• Designed for the Web
• No legacy software.
• 2003 technology.

7
Traditional HMI and SCADA

• Traditional not designed for the Web
• Limited or no remote database configuration
• Limited or no graphics building via web browser.
• limited function Web Client.
• 1980s technology.
• locked into legacy software.
• Web is a patch onto system.
• Proprietary.
• Software versions requires cataloging, tracking
  and repurchase of engineering tool(s).
• Example
• Intellution/Emerson, Wonderware/Foxboro, Johnson,
  Indusoft, Citec, Iconics.

8
What makes WebAccess unique?
Review

• Ordinary Web Browser to View and Control with
  full animation.
• Ordinary Web Server.
• A true Thin Client.
• Redundant SCADA node.
• Redundant Communication Ports.
• Designed for the Web.
• Web browser based Engineering!
• Remotely support customers.
• Engineering Tool is independent of software
  version installed at customers site.
• Engineers technicians always have the right
  version of software needed.

9
Productivity tools in WebAccess

• Import AutoCAD DXF files
• Fully Edit (fill, color, group) and fully
  animate.
• Floor plans, equipment drawings, PIds.
• Import Gif, Bitmap, JPEG, icons.
• Animate for size, position, frames.
• One set of graphics for both web local
  displays
• No conversion of graphics required.
• EXCEL import/export
• Create and edit tags, alarms, recipes, etc.
• Import SCADA nodes
• Move easily from development laptop to customers
  PC.
• Scale-up, down, merge projects easily.

10
Productivity tools in WebAccess

• Vector based Graphics
• Build at any resolution
• View at any resolution
• Scale within browser
• Auto fit within browser client
• Rendering of graphic and animation on client side
  to optimize system load
• Smaller file sizes than bitmaps
• Zoom with detail
• Libraries of Symbols, and Widgets
• Symbols and pre-animated Widgets
• Create Symbols and Widgets.
• Move Libraries to other projects

11
Productivity tools in WebAccess
TAG

• Object oriented tag database
• Parameters
• Guide novice users with pre-defined addressing
  for all device drivers.
• Blocks
• PID, VAV and other controllers.
• Setpoint, Measurement, Output, AM, tuning
  parameters, grouped into one tag.
• Reduces time to build database
• Block Detail Display reduces display building.
  Allows one display to view hundreds of the same
  Block Type.
• Alarms standard feature of all tags
• No separate alarm tags needed.
• Check box to enable.
• High-High, High, Low, Low-Low, Rate-of-Change, Hi
  Deviation, low deviation and State alarms.

Tag Name
Parameters
Address
Bit Length
Conversion
Scaling
Eng. Units
Description
More..
12
Complete SCADA solution

• Alarm Handling Package
• Complete, Out-of-the-box
• Alarm Summary Display
• Sort and filter by Priority, Time, Location
• Global Alarms
• See and Acknowledge alarms from all SCADA nodes
• Email and Pager notification of Alarms
• Acknowlegde alarms by reply email
• PDA and Pocket PC view and acknowledge alarms
• Alarm Log
• Printer, hard drive and central database.
• Disable alarms by Groups
• Fast response Alarm Graphic, and more

13
Complete SCADA Solution

• Trending data logging
• 12 tags on one graph
• Add /change tags without loosing data
• Scroll by second, hour, day, month
• Change scale (zoom)
• X-Y plot and time based
• HTML report (copy and paste data to EXCEL, etc.)
• Local recording to hard drive
• Centralized recording to single DB for all SCADA
  nodes

14
Complete SCADA Solution

• Scheduled Reports
• Shift, Daily and Monthly reports generated
  automatically
• View current and previous reports in Web Browser
• HTML report (copy and paste data to EXCEL, etc.)
• Email reports in HTML format
• Prints to printer or file
• Centralized recording to single DB for all SCADA
  nodes

15
Complete SCADA Solution

• Scheduler
• Calendar, time of day, day of week and holiday
  schedules
• Analog, discrete and text values
• Temperature setbacks, lighting control, equipment
  applications

16
Complete SCADA Solution

• Recipes
• Download hundreds of setpoints and change
  equipment status with a single button
• Redirect multiple recipes to multiple units
• Batch, blending, startup and shutdown applications

17
Complete SCADA Solution

• Integrated Video and Audio
• Video in graphic Display with pushbuttons, trends
  etc.
• Scripts to animate or rotate between cameras
• IP enabled cameras
• Active X controld
• Windows media
• JPEG web cams
• Security
• Traffic and transportation
• View and hear equipment startup

18
Complete SCADA Solution

• Security
• Area of responsibility
• Tags assigned to single area
• Users assigned to one or more areas. Can not
  change tags outside assigned area.
• Level
• 127 access levels within an area.
• Users
• Restricted users view display and data assigned
  to them.
• General all displays except system displays.
• Power user all displays.
• Project user DRAW, configuration tool.

19
Complete SCADA Solution

• Data base and Tag browser

• View the entire database of every SCADA Node.
• Current Value.
• Description.
• Span, Eng. Units.
• Drill down to Point Detail info on
  Configuration address, location.
• Find Displays, trends, alarm groups
  using the tag.

20
Building Automation SCADAmore than an HMI

• Integral Building Automation functions
• Scheduler
• Alarm Notification by pocket PC, pager, email,
  etc.
• Alarm acknowledgement via email and Pocket PCs
• Security Video and Audio
• Replaces 3rd Party software cost, reliability,
  ease of use
• Adds BA functionality to traditional automation
  IO
• Leading Edge Internet technology
• Access with web browsers
• Remote Engineering Technical Support.
• Direct access by accounting for more accurate
  energy usage / time of day invoicing
• Web browser access is current trend in BA
  industry
• Turn Building Automation into Energy Management
• Aggregate multiple facilities into a single
  system
• Improved electrical rates load shedding, peak
  shaving, etc.

21
Industrial Controls SCADAmore than an HMI

• Distributed Controls System (DCS) functions
• Alarm Summary, Alarm Log, Alarm Groups
• Operator Action Logs
• Overview, Group, Block Detail, Point Detail
  Display hierarchy
• Recipes
• Trending
• Scheduled Reports Shift, Daily, Monthly
• Blocks and Block Detail Displays interface to PID
  other functions
• Ease of use, Speeds system development
• Adds DCS functionality to traditional automation
  IO and PLCs
• Leading Edge Internet technology
• Access with web browsers
• Remote Engineering Technical Support.
• Web browser access is current trend in industrial
  HMI SCADA

22
System Architecture
23
True Internet Connectivity

• Clients are ordinaryWeb Browsers
• MicrosoftInternet Explorer 5.5 and 6.0
• Netscape 6.1
• Desktops
• Laptops
• Handhelds
• Pocket PCS (iPAQ), PDAs
• Windows CE, 95, 98, ME, NT, 2000, XP Server
  2003

24
True Internet Connectivity

• Full Control
• Setpoints
• Equipment Start / Stop
• Acknowledge Alarms
• Thin Client has full control too!
• Full Animation in Clients
• Clients are Engineering Station too!

25
True Internet Connectivity

• Unlimited concurrent clients
• No Client License Fees!
• Automatic Download of Plug-in if needed
• No Plug-in required for Thin Client

26
True Internet Connectivity

• Access with IP address, computer name or URL
• Pass through Dynamic IP
• Private IP
• with ICS or NAT
• Port Mapping
• Firewalls
• T1, DSL, ADSL, ISDN, 56K, 33.6K
• Wireless Ethernet

27
Multi-Layer Internet Security

• Microsoft IIS security
• Windows Integrated Security
• VPN (Virtual Private Networks)
• Secure Sockets Layer (SSL) Certificates
• Beyond ordinary Web Server security

• Web Access adds additional security to connect
• User name and Log-in
• To view a display.
• To Change a value.
• 32 Areas of Responsibility.
• User must be assigned to same Area the tag is
  assigned.
• 127 Password Levels, User must also have a
  password Level that matches or exceeds that
  assigned to the tag.
• Power, General and Restricted users to limit
  display access.

28
Fully Scale-able Web Application

• Networks.
• Multiple clients and SCADA nodes.
• WebAccess can aggregate multiple facilities into
  one system using TCP/IP.

• Single Machine Interface

29
Fully Scale-able Web Application

• Standalone single HMI
• Remote support
• Via dial-up, intranet or Internet
• Remote monitoring
• by managers, engineering, accounting.
• After-hours, Emergency or Swing Shift
• Hazardous locations

30
Fully Scale-able Web Application

• Unrestricted number of SCADA nodes
• SCADA node connects to Programmable
  Controllers,I/O Devices,Loop Controllers, DCS
  Systems, DDC Systems, RTUs, Instruments
• Up to 3000 devices on a SCADA node
• extendable to 16k
• 60,000 tags per node
• No limitation on the location of SCADA nodes or
  devices.

31
Partial Drivers List Automation Equipment
32
WebAccess Engineering tools

• Easy to install
• without prior web knowledge or experience of web
  site building
• No HTML required by user
• No graphics conversion
• Automatic download of plug-in if needed by
  clients
• Download files with a single pushbutton

33
WebAccess application

• Enables the average user to implement and
  maintain a small or large scale control system
  using built in networking tools.

34
Customers Local International
Federal Reserve
Waste Water Controls China
Embarcadero Center 6 SCADA nodes to control five
30-floor office buildings in San Francisco
University of California Berkeley Campus Ten
WebAccess nodes monitor control 50 campus
buildings
INTEL 5 facilities including 2 FAB locations
Sandia Labs
35
Customer Local
36
Customer - International

• Application Home Automation.
• Phase I Scale Monitor 30,000 apartments.
• Phase II Scale Monitor 3 Million apartments.

37
Typical Customer

• Single PC
• With occasional remote access

38
International Customers

• Multiple language versions
• English
• Japanese
• Simplified Chinese
• Traditional Chinese
• Localization design
• Just fill in a column in Excel for translation
• easily add a new language to Broadwin WebAccess

39
Completely Browser-based HMI

• All operations performed over the Internet (or
  intranet) using a web browser.

• Real-time data for operators and managers.
• Monitor, control, acknowledge alarms, download
  recipes, change setpoints, start and stop
  equipment
• Remote support by engineers and technicians.
• All engineering, configuration, programming, and
  technical support using an ordinary web browser.
• Real-time data remote support the first
  completely web browser-based HMI.
• The competition offers only half a solution.

40
High Performance Design for the Web

• Optimized for internet traffic
• Speed sensitive data communication adjusts for
  each client
• Vector based graphics
• Smaller file size and faster downloads than
  bitmaps
• High performance vector graphic engine
• Very low CPU utilization
• Runs on Client side to reduce network load
• Win32, multi-threaded data kernel
• all Microsoft Win32 platforms including Windows
  XP
• Best driver performance
• at least 7x faster than Intouch, 3x faster than
  iFix

41
Conclusion
The first fully Web browser-based HMI / SCADA
software

• Ordinary Web browser.
• Ordinary Web Server.
• Full Animation Client.
• A true Thin Client for PDA and Pocket PC.
• Email and text messaging of Alarms.
• Web browser is the Engineering Tool .
• Configure Database, Tags, Alarms, .
• Build Graphics, Download Software, start nodes
  remotely.
• 2003 technology.
• Designed for the Web.

42
Contact
BroadWin Technology Inc. 111 Deerwood Road,
250San Ramon, CA 94583 USAEmail
info_at_broadwin.comTelephone [phone]Fax
[phone]www.broadwin.comTom Carter
Product ManagerFrank Lin - President
