Internet Traffic Characterization

1
Internet Traffic Characterization

• Amogh Dhamdhere

2
What is covered in this talk

• Why characterize Internet traffic ?
• Measurement and analysis methodologies.
• Measurement studies.
• Variation of Internet traffic (time of day, day
  of week effects)
• Packet level characteristics (packet sizes).
• Flow level characteristics (Flow sizes, flow
  durations).
• File size distributions.
• Distribution by application.
• Distribution by protocol.

3
What is not covered

• Everything that will be covered in future
  presentations !!
• Delay and loss measurements
• TCP related measurements (TCP flavors etc)
• Self similarity of Internet traffic
• Flow measurements
• Peer to peer traffic measurements

4
Goals of this research..

• Observe Internet traffic characteristics.
• Develop reasonable models to understand these
  characteristics.
• Failure of traditional mathematical modeling
  techniques (e.g. Queueing theory).
• Earlier models deal with issues which are
  non-critical from the practitioners point of
  view.
• Attempt to close the void between theory and
  practice.

5
Why Characterize Internet Traffic ?

• Provisioning network resources (capacity, buffer,
  etc)
• How should the network be provisioned to satisfy
  certain constraints.
• Constraints may differ with the type of traffic.
• E.g. Buffer provisioning
• Current tools (eg SNMP) may not be sufficient
• Analyzing network performance
• TCP performance
• Routing performance

6
Why Characterize Internet Traffic ?

• Obtain characteristic workloads for use in
  simulations
• Typical packet sizes
• Typical flow durations
• Most commonly used TCP flavors
• Important for ISPs to formulate policy decisions
  (Service Level Agreements)
• Developing techniques to detect network anomalies
  e.g. Denial of Service attacks.
• Verify rule of thumb type design guidelines.

7
Measurement Methodologies

• Objectives of a monitor
• Collection of detailed traffic statistics from
  heterogeneous network links.
• Non-interference with the measured network
  (non-intrusiveness).
• Obtaining a global view of the monitored network
  from a reasonable number of monitoring points.
• Types of monitor
• Active monitors
• Passive monitors

8
IPMON (Sprint)

• Passive monitor for the Sprint backbone network.
• Capable of monitoring links of capacities ranging
  from OC-3 to OC-48.
• Uses an optical splitter on the monitored link.
• Records packet traces including IP and TCP/UDP
  headers, timestamp.
• Trace sanitizer.
• Analysis component
• Flow statistics (start and end time of flows,
  flow sizes)
• Protocol (TCP, UDP) and application (web, email,
  streaming) split of traffic.

9
IPMON
10
Other Projects

• OC3MON (MCI) - Passive monitor designed for OC3
  links (155 Mbps).
• NetScope (ATT) - A set of tools for traffic
  engineering in IP backbone networks.
• Network Analysis Infrastructure (NAI) -
  Performance of vBNS (very high speed Backbone
  Network Service) and Abilene networks.
• Some routers have built-in monitoring
  capabilities.
• Netflow Cisco routers.
• Commercial tools
• Niksuns NetDetector and NikScouts ATM Probes.

11
Measurement Studies

• Wide Area Internet Traffic Patterns and
  Characteristics Thompson, Miller, Wilder, MCI
  Telecommunications, 1997.
• One of the first studies of commercial backbone
  traffic.
• Used the OC3MON traffic monitor described
  earlier, at two locations on MCIs commercial
  backbone.
• Characterize traffic on timescales of 24hrs and 7
  days in terms of traffic volume, flow volume,
  flow duration, packet sizes, traffic composition
  (by protocol, application).
• Two links monitored. Domestic and International.

12
MCI Study Daily and weekly effects

• Traffic volume shows a clear diurnal pattern,
  with traffic tripling from 0600 through 1200
  noon EDT.
• Traffic decreases by about 25 during the
  weekend.
• The two directions of the monitored link are not
  symmetric.

13
MCI Study Asymmetry in packet sizes

• Packet sizes are different in the two directions,
  and are roughly inversely proportional to each
  other.

14
MCI Study Packet size distributions

• Packet size distributions are trimodal.
• 40-44 bytes - TCP ACKs, control segments etc.
• 552 or 576 bytes - Default MSS when MTU Discovery
  is not used is 512 or 536 bytes.
• 1500 bytes MTU for Ethernet.

15
MCI Study International Link Traffic

• International link traffic shows similar time of
  day, day of week effects.
• Packet sizes in the two directions are asymmetric
  Larger packets in the U.S. to U.K. direction.

16
MCI Study Protocol and Application Mix

• Protocol composition
• TCP dominates (95 of bytes, 90 packets, 75
  flows)
• UDP second (5 bytes, 10 packets, 20 flows)
• ICMP most of the remaining.
• Application composition
• Web (75 bytes, 70 packets, 75 flows)
• Other (may also be web-related)
• DNS (1 bytes, 3 packets, 18)
• SMTP (5 bytes, 5 packets, 2 flows)
• FTP (5 bytes, 3 packets, lt1 flows)
• NNTP (2 bytes, lt1 packets, lt1 flows)
• Telnet (lt1 bytes, 1 packets, lt1 flows)

17
Measurement Studies

• Trends in Wide Area IP Traffic Patterns
  McReary, Claffy, CAIDA, 2000.
• Data collected by the NAI project from May 1999
  through March 2000 at the NASA Ames Internet
  Exchange.
• Analysis of packet size distributions,
  protocol/application mix etc.
• Show increasing trends in traffic from new (at
  that time) applications e.g. streaming media,
  online games, Peer to Peer (Napster).
• No change in the overall trend in the TCP/UDP
  traffic ratio as compared to the analyses at MCI
  and CAIDA in 1998.

18
CAIDA Study Packet Size Distributions

• Packet size distributions show same trimodal
  trend as previous results.

19
CAIDA Study Protocol and Application Mix

• Protocol mix
• TCP and UDP are still the most popular protocols,
  and in roughly the same proportions.
• Application mix (TCP)
• Web is still the most popular application
• New applications like peer to peer file sharing
  (Napster) now appear in the list. (Napster at 5th
  position)
• Application mix (UDP)
• Streaming media (RealAudio) now comprises a
  substantial portion of total UDP traffic.
• Online games (Half Life, EverQuest, Unreal, Quake
  3) also have substantial share.

20
CAIDA Study Long Term Trends

• The protocol mix of the traffic (TCP and UDP)
  does not change significantly over time.
• Decline in the contribution of FTP to the overall
  traffic mix.
• Possibly due to shift from active to passive mode
  FTP, because of an increase in packet filtering
  firewalls.
• Alternate protocols for file transfer.
• Decline in the fraction of RealAudio traffic.
• RealAudio traffic has remained fairly constant,
  while other traffic has increased.
• Decline in the fraction of game traffic

21
CAIDA Study Long Term Trends

• Significant increase in peer to peer traffic
  (Napster)

22
CAIDA Study Short Term Trends

• Email traffic increased significantly in November
  and early December, decreasing after December
  holidays.

23
CAIDA Study Short Term Trends

• Online gaming shows day of week effects, with
  traffic nearly doubling over weekend periods.

24
Measurement Studies

• Longitudinal study of Internet traffic from
  1998-2001 Fomenkov, Keys, Moore, Claffy, CAIDA,
  2001.
• Unique long term view of Internet traffic.
• Multiple observation sites (20)
• Four metrics of measured traffic
• Number of bytes.
• Number of packets.
• Number of flows.
• Number of source-destination pairs (port number
  and protocol fields ignored). This measures the
  number of Internet hosts communicating via the
  monitored link.

25
Longitudinal Study

• Bit and packet rates show diverse behavior
• Some sites show sustained growth, some are
  constant and some fluctuate between growth and
  reduction.
• No clear diurnal pattern in the measured traffic
  !
• No consistent long term growth Refutes the
  notion that Internet traffic ic universally and
  rapidly increasing.
• Usage patterns
• Traffic composition varies significantly from
  site to site.
• WWW traffic reached maximum between late 1999 and
  early 2000.
• Has been constant or decreased since.
• This could be due to the onset of noticeable
  amounts of P2P traffic.

26
Longitudinal Study Application Mix
27
Measurement Studies

• Packet Level Traffic Measurements from the Sprint
  IP Backbone Fraleigh, Moon, Lyles, et al.
  Sprint Labs, 2003
• Most recent (2001-2002) study of traffic on a
  commercial backbone link.
• Analyses the impact of new applications
  (distributed file sharing, streaming media)
• New results for end-to-end loss and delay
  performance of TCP connections.
• Measurements of network delays in the backbone
  and U.S. transcontinental links.
• Methodology Uses the IPMON architecture
  described earlier.

28
SPRINT Study Traffic Load

• Traffic load in bytes
• SNMP is not able to capture the burstiness of the
  traffic at smaller timescales.
• Most backbone links are utilized under 50. Less
  than 10 of the backbone links experience
  utilization higher than 50 in any 5 min
  interval.
• Noticeable peaks in traffic load are observed due
  to DoS attacks.
• Traffic in a bidirectional link is asymmetric.
• Many applications are inherently asymmetric.
• Hot potato routing.

29
SPRINT Study

• SNMP is not able to capture the burstiness of the
  traffic at smaller timescales.

30
SPRINT Study Application Mix

• Application mix varies from link to link.
• In most cases, web represents more than 40 of
  total traffic (As seen in previous studies)
• However, on some links, the web contributes less
  than 20, while P2P accounts for 80.
• Streaming applications are a stable component of
  the traffic.

31
SPRINT Study - Flows

• The number of flows and the traffic load are not
  necessarily correlated. i.e a large number of
  flows does not always mean a large traffic load.

32
Measurement Studies Flow level

• Understanding Internet Traffic Streams
  Dragonflies and Tortoises Brownlee, Claffy
  CAIDA.
• Results of flow level measurements from two
  links OC3 link (Auckland) and OC12 link (UCSD)
• Uses an extension of NeTraMet to monitor stream
  lifetimes.
• Previous classifications of flows were on basis
  of size (packets or bytes)
• Elephants (large transfers)
• Mice (short transfers)
• Propose alternate classification of TCP flows on
  basis of their lifetime.
• Tortoises (long lasting transfers)
• Dragonflies (short duration transfers)
• Here flows are defined as sets of packets
  traveling in either direction between a pair of
  end-points.

33
Dragonflies and Tortoises

• Percentages of streams and bytes.
• Long Running (LR) streams (gt15 mins) account for
  about 1 of the streams.
• Very Short streams (lt2 sec) account for 40 70
  of streams, showing a diurnal pattern of
  variation.
• At UCSD site, 50 of all bytes were in LR
  streams, while this fraction was 5 for Auckland.
  Most of these streams are non-web traffic.

34
Short Streams Streams lasting less than 15 mins

• Lifetime distributions
• 45 of streams have lifetimes less than 2 sec.
• Distributions do not change rapidly over time.

35
Short Streams Streams lasting less than 15 mins

• Byte size distributions
• Short stream size distributions for UDP, non-web
  TCP and web TCP are considerably different.
• Distributions are stable over long periods of
  time

36
Tortoises Streams lasting more than 15 mins

• Bit rates
• Longer duration LR streams are low-rate
  (interactive) or high rate (multimedia) with
  approximately equal frequency.
• Medium duration LR streams tend to be high-rate.
  (file transfers)
• UDP streams run at constant bit rates, but these
  rates may change in response to the applications
  state (online games).

37
Tortoises Streams lasting more than 15 mins

• LR stream lifetimes
• LR stream lifetimes seem to follow a power law
  distribution.

38
Measurement Studies Flow level

• Internet Stream Size Distributions Brownlee,
  Claffy, CAIDA 2002.
• Measurements of
• Per minute distributions of stream sizes in bytes
  for a period of one hour.
• Two different types of traffic considered Web
  traffic, and non-web TCP traffic.
• Web streams
• 87 under 1kB, 8 between 1 and 10 kB, 4.8
  between 10 and 100 kB.
• Non-web streams
• 89 under 1kB, 7 between 1 and 10 kB, 1.5
  between 10 and 100 kB.

39
Internet Stream Size Distributions
40
File Size Distributions

• The Structural cause of file size distributions
  Downey, 2001.
• A new model for the operations that create new
  files.
• Files appear because of common operations.
• Copying.
• Translating and filtering.
• Editing.
• Using this, the distribution of file sizes can be
  predicted to be lognormal.
• Start with a single file of size s.
• Select a file size s at random from the current
  distribution.
• Create a new file with size fs and add to the
  distribution. (f is a factor chosen from some
  other distribution.
• Hence size of nth file is sn s f1 f2
  f3..fm
• log(sn) log(s) log(f1) .

41
File Size Distributions

• File sizes on web servers
• Studies by Arlitt and Williamson claim file size
  match the Pareto model.
• This may not be true !!
• Some of the analyzed data sets better fit the
  lognormal model.
• Traces of downloaded files.
• Fits a hybrid model with lognormal distribution
  with a Pareto tail.
• Two mode lognormal model is also a good match.
• Summary The distribution of file sizes is NOT
  heavy tailed !
• Implications on self-similarity of Internet
  traffic
• Most explanations assume that distribution of
  file sizes is long-tailed.
• Need to revise explanations of self-similarity.

42
Non-commercial networks

• Some results from the abilene network during the
  duration of one week.
• Application mix
• Web traffic is much lower as compared to
  commercial backbone networks.
• Email traffic is higher.
• Measurement traffic amounts to 5 of all traffic
  !!
• Protocol mix
• TCP is still the most dominant (90 of bytes).
• UDP accounts for 5.
• ICMP around 4.
• Numbers similar to that on commercial backbone
  links.

43
Future Directions

• Self-similarity The need to verify assumptions.
• Downey questioned the assumptions about file size
  distributions.
• Inter-arrival time distributions.
• Transfer length distributions.
• Burst size distributions.
• Dependence of traffic characteristics on TCP
  algorithms.
• Measurement based forecasting of DoS attacks and
  flash crowds.
• Real time monitoring of critical parameters. Use
  this characterization to automatically make
  decisions.
• Provisioning.
• Routing etc.

44
Future Directions

• Characterization of P2P traffic.
• Previous measurement studies on P2P systems
  focused on node behavior, topology etc.
• Need to better characterize the traffic generated
  by P2P applications.

45

• Thank You !
