Feature selection using hybrid method for text clustering

1
Feature selection using hybrid method for text
clustering

• Ning Kang
• INFS 795

2
Outline

• Introduction
• Feature selection(supervised/unsupervised)
• Association mining and frequent itemset
• Local adaptive clustering method
• Objective and problem definition
• Experimental Design and result analysis
• Conclusions

3
Introduction

• Text clustering is to group similar documents
  together.
• The general bag of words representation raises
  one severe problem the high dimensionality of
  the feature space and the inherent data sparsity.

4
Introduction

• Clustering in such high dimensional spaces
  presents tremendous difficulty and the
  performance of clustering algorithm will decline
  dramatically, much more than that in predictive
  learning such as decision trees or Naive Bayes
  classification.
• Introduce irrelevant feature will hurt clustering
  result.
• Curse of dimension by measure similarity

5
Feature selection

• Feature selection is a process that choose a
  subset from the original feature set according to
  some criterions.
• Depending on if the class label information is
  required, feature selection can be either
  supervised or unsupervised.

6
Supervised Feature selection

• Information gainmeasures the information
  obtained from category prediction by presence or
  absence of the term in a document.
• x2 statistic (CHI)measures the association
  between the term and the category.

7
Unsupervised feature selection

• Document Frequency
• Term strengthit is computed based on the
  conditional probability that a term occurs in the
  second half of a pair of related documents given
  that it occurs in the first half
• Entropy-based ranking The term is measured by
  the entropy reduction when it is removed. The
  entropy is defined as the following equation

8
Association Rule Mining

• Given a set of transactions, find rules that will
  predict the occurrence of an item based on the
  occurrences of other items in the transaction

9
Frequent Itemset

• Itemset
• A collection of one or more items
• Example Milk, Bread, Diaper
• k-itemset
• An itemset that contains k items
• Support count (?)
• Frequency of occurrence of an itemset
• E.g. ?(Milk, Bread,Diaper) 2
• Support
• Fraction of transactions that contain an itemset
• E.g. s(Milk, Bread, Diaper) 2/5
• Frequent Itemset
• An itemset whose support is greater than or equal
  to a minsup threshold

10
Apply association rule in text mining

• Scenario 1
• baskets documents
• items words in documents
• frequent word-groups ? linked concepts.
• Scenario 2
• baskets web pages
• items outgoing links
• pages with similar references ? about same topic

11
Co-clustering

• To capture the local correlations of data, a
  proper feature selection procedure should
  operate locally
• A local operation would allow to embed different
  distance measures in different regions
• Definition simultaneous clustering of both row
  and column sets in a data matrix.

12
Locally Adaptive Clustering (LAC)

• Weighted cluster subset of data points, together
  with a weight vector, such that the points are
  closely clustered according to the corresponding
  weighted Euclidean distance
• Objective Find cluster centroids, and weight
  vectors.
• By Professor Carlotta Domeniconi etc.

13
Local adaptive clustering
1
y
2
x
w1xgtw1y
w2ygtw2x
14
Locally Adaptive Clustering (LAC)

• Error function

Subject to
Where
15
Objective and motivation

• Text dataset has very high dimension size, it is
  hard to apply local adaptive method.
• To clustering problem,generally dimension gt16
  will be considered high dimension.
• May have some common irrelevant feature to all
  clusters, and each cluster may have its own
  subset of relevant features(subspace clustering).

16
What can we gain?

• In text applications, web clustering based on
  site contents results in 5,000-15,000 attributes
  (pages/contents) for modest Web sites.
• Biology and genomic data can have dimensions that
  easily surpass 10,000 attributes.
• The difference of the gap is significant.
  Although the newly developed sub-space clustering
  algorithm can in some extent s solve the high
  dimensionality problem by finding local
  correlations in the data and perform
  dimensionality reduction on the locally
  correlated clusters individually.

17
What can we gain?

• This kind of algorithm may works well for
  dimensionality less than 200,but obviously it
  will not work well for dimension such as 10,000.
• We try to apply some global feature selection
  method on original feature space to reduce the
  feature to 200300 since in most condition there
  is a lot of common unrelated features for all
  clusters. Then we take advantage of local
  adaptive clustering method to find local
  correlated features for each cluster.

18
How do we combine?

• The main point of the hybrid feature selection
  method is apply local adaptive clustering
  algorithm to a preselected feature space which
  using frequent itemset ideas. To say concretely
• Step1 . Represent document set into Bag of Word
  format D.
• Step2 . Applying association rule to Set D to get
  a group of frequent termset SS1,Sn.
• Step3 . Combine all the termset in S to get a set
  of global feature GS S1??Sn.
• Step4 . Apply Local Adaptive Clustering
  algorithm(LAC) to document set D on selected
  feature space GS.
• Step5 .Get the documents partition and the local
  weight for each partition.

19
Problem Definition

• Given a set S of D documents in the
  Norg-dimensional space and M is the number of
  document in dataset, N is the dimensional space
  which is gotten after applying association rules
  mining on space MNorg . A set of k
  centersc1,,ck, Cj ?RN, j1,k coupled with a
  set of corresponding weight vectorsw1,,wk,
  wj?RN, J1,..,,k.partition S into k
  setsS1,,Sk
• Where wji and cji represent the ith components
  of vectors wj and cj respectively.

20
Dataset used
21
Experiment design

• Preprocessing the dataset
• Stop word deduction(Based one a stopword list)
• Low frequency word deduction(dfgt3)
• Data representation
• relative term frequency(rtf)term
  frequency(tf)/total frequency in that document
• Distance measurement
• normalized Euclidean distance

22
Experimental Design

• Apply association rule mining to get a set of
  frequent itemset as a pre-selected set of feature
  for each dataset based on designed frequent
  itemset support.
• Apply Local adaptive clustering(LAC) method to
  each dataset to get weighted feature sets for
  each category based on the pre-selected feature
  set.

23
SPAM dataset(support, h)
24
Weighted features

• Some selected typical features with high rank.
• SPAMconference,applications,algorithm,
• Papers,committee,neuroscience
• NON-SPAMsales, money, marketing, credit, pay,
  free,order,product

25
Weight comparison for selected feature
26
Stdev comparison for selected feature
27
Why it happens?
3
1
2
Distribution of feature i in a certain
cluster 2,3 will get high weight, 1will get low
weight
28
Experimental Result Analysis(1)

• From above result(table 1 and 2), we can see when
  dimension of the feature reduced from 791 to 285
  in terms of the original feature space 9210, the
  clustering result is nearly the samearound 2
  which is fairly good. Obviously, the setting of
  support for association rules is the most
  important factor that influence the final result.
  And the weighting parameter h also has impact on
  the final result.

29
20Newsgroup dataset
30
Experimental Result Analysis(2)

• By analysis of the weight for some selected key
  word, we found when a word(feature) in a certain
  class get a high weight, that word has a low
  standard deviation among that class which means
  the value of that feature for each document in
  that class is relative tight. So this kind of
  feature can be a discriminative feature and
  should get a higher weight.

31
Comment on result

• The setting of support for the association rules
  in first step is very important. The setting of
  support should be the one which can get selected
  feature around 200-300 features. In this
  situation, it can get relatively good clustering
  performance and also can converge very fast by
  contrast of using high dimension space.

32
Conclusion

• By applying association rule to documents
  dataset,it dramatically reduce the feature space
  from 10,000 to 200300 and still keep the low
  error rate,but improve the computation time.
• By applying local adaptive clustering on selected
  feature, we get weight vector which reflect the
  real discriminative word feature for each
  cluster.
• Effectively help local adaptive cluster algorithm
  to high dimensional data such as text data.

33
Future Work

• Try other dataset such as microarray dataset.
• Try to find some formula between the support
  setting,data points numbers and the original
  features and target features.
• Try to find a way to get the best h
• Try to find a way to identify the cluster using
  weight vector or feature distribution
• Change the initiate center chosen

34
Reference

• Aggrawal, C.C Yu, P.S (2000). Finding
  generalized projected cluster in high dimensional
  spaces. Proc. of SIGMOD00
• Yang,Y.(1995). Noise reduction in a statistical
  approach to text categorization.Proc. of SIGIR95
• C. Domeniconi, D. Papadopoulos, D. Gunopulos, S.
  Ma, "Subspace Clustering of High Dimensonal
  Data", in Proceedings of the SIAM International
  Conference on Data Mining , Lake Buena Vista,
  Florida, April 22-24, 2004.
• Hichem Frigui and Olfa Nasraoui, Simultaneous
  Categorization of Text Documents and
  Identification of Cluster-dependent keywords.
• Daniel Babara, Carlotta Domeniconi and Ning Kang,
  Classifying Documents without Lables. SDM04
• Hichem Frigui and Olfa Nasraoui, Simultaneous
  Clustering and Attribute Discrimination
• Yiming Yang and Jan O.Pedersen, A comparative
  study on Feature Selection in Text
  Categorization.
