Performance Test Planning Part 1
CS 4803 EPR
Enterprise Computing Performance
2
Lecture Overview

• Performance Test Planning
• Terms and definitions
• Objectives
• Test scope
• Performance Requirements
• Who develops them?
• Suggested elicitation process
• Project and political realities
• Presentation to Business Analysts
• Test environment
• Review of performance simulation market tools
• Case Studies and White Papers
• Student Presentations 1

3
Terms and Definitions

• Transaction Logical business operation
• Key term
• Different everywhere
• Can have a narrow or broad context
• Context generally limited to middleware and
  database tiers

4
Terms and Definitions

• Performance Test The catch all for all
  performance related types of testing. Often used
  in different ways by different people. Term can
  refer to any type of performance-related test.
• Load Test A test of a computer system and its
  applications by running under a full complement
  (full load) of transactions or users. Most
  commonly refers to tests that model varying loads
  and activities that the application is expected
  to encounter when delivered to real users.
  Focuses on how much the application handle.
• Stress Test Tests application under a load for
  a period of time to discover the ability of the
  application to handle workload. No standard
  definition. Most commonly refers to tests that
  model varying loads and activities under more
  stressful conditions than the application is
  expected to encounter when delivered to real
  users. Sub categories may include
• Spike testing (short burst of extreme load)
• Peak load testing (load test with maximum
  concurrent users)
• Volume Test Any test focused on how much
  instead of how fast. Commonly related to
  database testing. The distinction between
  "volume" and "load" is that volume focuses on
  high volume and does not need to represent "real"
  usage.
• Performance Bottleneck An activity or area that
  slows down progress such that the next activity
  must wait on the bottleneck to clear. The
  critical bottleneck is the single bottleneck
  that will keep the overall process from getting
  faster, no matter what other bottlenecks are
  resolved. Also called the Critical Path
  Bottleneck.

5
Terms and Definitions

• Workload Distribution a transaction mix of the
  functions performed by a user community on a
  system. There may be more than one user
  community. For example, during the course of a
  day on a retail-based website, most users are
  shopping, some are searching for a specific
  product, some are finalizing purchases and
  checking out, while a single administrator may be
  updating product prices. A workload
  distribution is based on a percentage of users
  performing a specific function over a given
  period of time. Using the above example a
  workload distribution could be

6
Terms and Definitions

• Concurrent Users Users that are simultaneously
  accessing the same system. A number associated to
  this term is often misleading many factors come
  into play.
• Ramp-up/Ramp-down Simply the time between the
  first user access and the time the target load is
  achieved, as illustrated below.

7
Terms and Definitions

• Scalability The expansion capability of a
  system or architecture. The term by itself
  implies a positive capability.
• Vertical Scaling Adding system resources
• Horizontal Scaling Adding nodes or autonomous
  systems
• Linear Scalability The holy grail of system
  architecture Not fully achievable

8
Terms and Definitions

• Longevity or Stability Testing Testing designed
  to validate that performance degradation over
  time is not realized.
• Performance Degradation The condition a system
  suffers when system resource levels are bled.
• Think Time The average amount of time a user
  would spend between doing something. For example,
  the amount of time a user spends filling out a
  form before clicking on the Save button.
• End User Experience Performance as perceived by
  a human user. For example, the amount of elapsed
  time between a button click on Submit Order and
  the display of the Thank You page.
• Response Time Amount of elapsed time between a
  server request and server response. For example,
  the elapsed time delta of an HTTP request header
  timestamp and the corresponding HTTP response
  header timestamp.

9
Terms and Definitions

• Virtual User A simulated, computer-generated
  user. Virtual users are a concept used by
  performance simulation tools to generate
  realistic system transactions on the SUT.
• SUT System Under Test aka AUT Application
  Under Test.
• TPS Transactions Per Second. This metric is
  often used to measure the performance of
  components without user-interaction.
• Batch Processes Also termed back-end-processes
  . Any system process or program that is triggered
  by a non-human initiated event, such as a system
  clock or computational trigger.
• Business Process AKA Scenario. Lacks a
  standard definition. Typically refers to a suite
  of human-initiated business transactions (units
  of work), grouped together to complete a specific
  task.
• Test Case Shares a one-to-one or one-to-many
  relationship with Business Process.
• Performance Baseline AKA performance
  profiling A technique that simulates a single
  user under steady/controlled conditions, used to
  establish a best-case benchmark.

10
Performance Plan Sections

• The next 7 slides describe the key Performance
  Test Plan sections

11
Test Objectives

• Clearly state your high-level test objectives,
  from a business perspective For example

The objective of this document is to be a single
point of reference for all LP S2S Performance
Validation planning. It will serve as a
communication tool and reference between the
performance validation team and the managers of
the project/system undergoing performance
validation. This test plan will serve the
following, specific purposes To ensure that the
new System-System design is able to handle the
projected LP volume levels, and to ensure current
LP Classic, LP Inside and LP.com browser
application performance are not impacted by the
new Pricing service, and to verify the
established LP performance has not been
negatively impacted by the introduction of
System-System design.
12
Scope

• It is imperative to clearly delineate what is in
  and what is specifically out of scope in context
  for the test. For example

• This test plan encompasses the following LP
  functional areas. All other functional areas are
  explicitly not in scope for this test.
• LoanProspector.com
• Volume
• Direct Entry
• Loan Search
• Import
• LP Post Close
• File Format (TBD)

13
Performance Requirements

• Non-functional, performance-specific requirements
  must be gathered, clearly documented and
  agreed-upon before further test planning. Some
  examples of non-ambiguous, testable performance
  requirements

• 80 of all page responses shall be lt 5 seconds
• 100 of all page responses shall be lt 8 seconds
• XYZ Batch Process shall complete in 8 hours
• ABC Batch Process shall yield 2,500 TPS under
  nominal load
• AUT shall support 500 concurrent users under
  nominal load
• AUT shall support 1,000 concurrent users under
  peak load
• All performance requirements shall be met with a
  1 year data volume load

14
Performance Requirements

• Elicit requirements from Business Analysts
• Ask the right questions
• Education issue lack of experience in the
  business community
• Conduct a training class teach them
• Without unambiguous, explicit requirements, no
  Exit Criteria can be met!
• Some BAs just dont want to bother or be
  responsible for something new
• Some examples
• Please define the user types (actors) for this
  application/component.
• Nominally, how many concurrent users are
  anticipated for this release? Peak? Please break
  down per application component if applicable.
• Nominally, how many concurrent users are
  anticipated six months into production? Twelve
  months?
• What type of User Experience do you require?
  Response times Please be specific.
• How many total users will the application
  support? (total user base)
• What is the maximum database size(s) for the
  target system?
• How much bandwidth will the application be
  allotted? (WAN, LAN, etc)

15
Test Environment

• Production Architecture
• If it doesnt exist, develop it

16
Test Environment

• Test Environment
• A mirror or, most likely, a subset of Production

17
Tools and Market

• A review of performance test tools and the tools
  job market

18
Performance Test Tools

• Simulation tools (LoadRunner, SilkPerformer,
  QALoad, Rational/VU, etc)
• Packet capture/sniffing tools (Ethereal,
  TracePlus, Network Packet Analyzer, EtherPeek,
  etc)
• Monitoring tools (SiteScope, Topaz, FarSight Web,
  SilkCentral, Vantage, etc)
• Diagnostic tools (DeepDiagnostics, OneSight Web,
  PerformaSure, etc)

19
Test Simulation Market
20
Simulation - tools

• 6 Leading Tools
• LoadRunner (Mercury)
• SilkPerformer (Segue)
• QALoad (CompuWare)
• Rational Robot/VU (IBM)
• Empirix
• RadView

21
Simulation - market

• 2004 Estimated over 850M market
• Mercury now has gt 80 of world performance tool
  market

22
Performance Test - market
23
Performance Testing Jobs
24
Performance Jobs - Modeling
25
Performance Jobs - Combo
26
Performance Jobs - Simulation
