Cluster Network Architecture (UCLA-WAM
IS)

• Concept
• create a cluster based TDM infrastructure which
• (a) enables guaranteed bandwidth for voice/video
• (b) can support instant deployment and mobility
• Approach
• distributed clustering algorithm
• time division slotting within each cluster
• slot reservation for real time traffic
• virtual circuits for real traffic datagrams
  for data
• code separation across clusters
• slot synchronization
• Combines cellular radio and traditional packet
  radio features.

3
Lowest-ID cluster-head election
5
2
10
8
1
6
9
3
4
7
4
Distributed Cluster algorithm (lowest-ID)

• Each node is assigned a distinct ID.
• Periodically, the node broadcast the list of
  nodes that it can hear.
• ClusterHead hears only nodes with ID higher
  that itself (unless lower ID specifically gives
  up its role as CH) ? A,B,C
• Gateway hears two or more CHs ? G,H
• Ordinary node otherwise ?
• Properties
• No cluster heads are directly linked.
• In a cluster, any two nodes are at most two-hops
  away, since the CH is directly linked to any
  other node in the cluster.
• RE Emphremides, et al A Design Concept for
  Reliable Mobile Radio Networks with Frequency
  Hopping Signaling Proceedings of IEEE, Vol. 75,
  No.1, 1987

5
Cluster network architecture

• Dynamic, distributed clustering alg. Partitions
  the system into cluster.
• Code separation among clusters.
• Local coordination provided within a cluster.
• Clusterheads act as local coordinator to
• resolve channel scheduling
• provide power measurement/control
• support virtual circuit setup for real time
  (voice and video) traffic
• maintain synchronization
• Dynamic adaptation (via periodic updates.)
• mobility
• failures
• Interference
• bandwidth requirements (B/W alloc.--TDMA slot
  assgn.)

6
Channel Access
Within each cluster time-slotted frame

• Control Phase
• clustering algorithm
• routing
• power measurement and power
• code and slot assignment
• VC setup
• acknowledgments

• Data Phase
• voice/video (PRMA)
• data (Random Access)

7
Virtual Circuit support in WAMIS

• Multimedia Traffic (eg, voice, video)
• connection oriented
• QoS based admission control
• VC based bandwidth allocation
• We need
• robust, QoS enabled routing
• elastic, reconfigurable VCs

8
VC reconfiguration in Mobile Environment

• Conventional VC setup does not work (path breaks
  up too frequently)
• Proposed approach Fast Reservations, like in
  PRMA (Packet Reservation Multi Access)

• Packet follow shortest path
• First packet reserves the slot(s) along the path
• When path changes, first packet competes again
  for slots on new path (voice/video rate reduced
  by low priority pkt drop)
• If no path, packet is dropped
• reservation released if slot is unused

9
Case study compare Random Access and TDMA in
Multimedia

• C. Richard Lin and Mario Gerla
• Computer Science Department
• University of California, Los Angeles

10
CSMA DARPA PRNET (1970s)

• Single channel
• Spatial reuse
• CSMA
• Implicit ACK (echo ACK)
• Retransmission (for datagrams only)
• Duct routing (for voice traffic)
• Based on Bellman-Ford routing
• Alternate routing multiple paths used to carry
  multiple copies of a real-time packet to improve
  reliability
• Carrier sense will limit the fan-out

11

• Limitation of PRNET
• no bandwidth reservations no access control (for
  voice)
• hidden terminal problem
• Enter Cluster TDMA (1994)
• different codes in each cluster
• TDMA type MAC access in each cluster
• QoS routing bdw reservation access control
• Fast VC set up (soft state)

12

• Problems of CLUSTER TDMA cost and complexity
• global slot synchronization
• multiple codes
• initialization
• Enter MACA/PR (1996)
• (Multiple Access Collision Avoidance/Packet
  Reservations)
• no clustering single code easy initialization
• RTS/CTS dialog(to prevent hidden terminal
  problems)
• Packet Reservations (to support real time
  traffic)
• QoS routingp standby routs (for dynamic
  rerouting)

13
MACA/PR (contd)
14
Real Time Traffic Support Bandwidth Reservation

• 1st packet is treated as a datagram packet
• After successfully transmitting piggyback
  reservation is honored for subsequent packets
• Bounded delay and no collision
• Real -time Traffic and datagram traffic are
  interleaved (with datagram deferring to real-time
  traffic)

15
Performance Comparison (parameters)

• A 100X100 feet area
• Number of radio station20
• Frame size 100ms
• Tx range 40 feet
• VC end-to-end hop distance3
• Maximum speed8 feet/sec
• Data rate800kbps
• Pkt size4kbits pkt acquisition500bits
• Multiple VCs,datagram background traffic
• Tx rate 1pkt/frame
• Call duration180 seconds.

16
Performance Comparison of Various Schemes
Synchronous
Asynchronous
17
Overall Performance Comparison

• PRNET
• No bandwidth reservation
• No acceptance control
• In heavy load duct routing generates excessive
  number of
• requests for alternate routes ( congestion)
• MACA/PR
• total VC throughput limited by lack of
  cluster/code separation
• Cluster TOKEN and TDMA
• high end to end delay due to token/TDMA latency

18
Channel Propagation Models

• Radio channel propagation is characterized by
  three main parameters
• Attenuation free space loss, absorption by
  foliage, partitions
• Shadowing obstacles between transmitter and
  receiver
• Multipath due to the different phases on
  different paths

19
Simulator MAISIE Channel Model

• Channel Fading Model in Maisie Simulator
• the Simulator utilizes the SIRCIM impulse
  response parameters to characterize the radio
  propagation model, i.e. multipath, shadowing
  effect, spatial correlation

20
Radio Channel Simulation
21
VC Performance free space vs fading model
22
More MAC Layer protocols

• Bluetooth Piconet a polling/TDMA scheme
• HomeRF a hybrid random access and TDMA scheme
• Hiperlan2 a connection oriented, TDMA on demand
  scheme

23
More TDM type MAC Layer protocols

• Bluetooth Piconet a polling/TDMA scheme
• HomeRF a hybrid random access and TDMA scheme
• Hiperlan2 a connection oriented, TDMA on demand
  scheme

24
What does Bluetooth do for you?
25
Example...
26
Bluetooth Piconet

• Page - scan protocol
• to establish links with nodes in proximity

27
Piconet MAC protocol Polling
FH/TDD
f1
f3
f4
f5
f2
f6
m
s1
s2
625 ?sec
1600 hops/sec
28
Multi slot packets
FH/TDD
f1
f4
f5
f6
m
s1
s2
625 µsec
Data rate depends on type of packet
29
Physical Link Types

• Synchronous Connection Oriented (SCO) Link
• slot reservation at fixed intervals

• Asynchronous Connection-less (ACL) Link
• Polling access method

m
s1
s2
30
Home RF

• No new wires
• Simple to Install
• Easy to Use
• Low Cost 200 for 2 PCs
• Bandwidth To Support Common
• Home Applications
• Industry Standards

31
HomeRF Working Group Mission Statement

• To enable the existence of a broad range of
  interoperable consumer devices, by establishing
  an open industry specification for unlicensed RF
  digital communications for PCs and consumer
  devices anywhere, in and around the home.

32
Enabling the Vision
USB
Printer
Camera
Game Pad
1394
Stereo
Camcorder
VCR
TV
Multimedia (e.g. 1394)
HomePNA
33
The SWAP Network
SWAP-CA Shared Wireless Access Protocol -
Cordless Access
Internet
USB
34
HomeRF Origins
DECT Uses TDMA Good for Voice
802.11 Uses CSMA/CA Good for Data
SWAP TDMA CSMA/CA Good for Voice
Data Optimized for small networks (in
home) Simplified radio protocol to reduce cost
Both voice and data are important for home RF
35
Device Types
36
Hybrid MAC layer
SWAP Frame
37
PHY Features

• Nominal 100 mW transmit power
• Minimum receiver sensitivity of -76 dBm (2FSK)
• range gt50 m in typical homes/yards
• -85 dBm sensitivity typical
• Cost effective filter requirements
• Use MAC to reduce PHY cost
• Makes single-chip integration simpler

38
MAC Features

• MAC provides good support for voice and data
• Leverages existing DECT technology for voice
• Excellent integration with TCP/IP networking
  protocols
• easy integration with Ethernet
• Supports broadcast, multicast and fragmenting
• Data security - Basic/Enhanced levels of
  encryption
• Basic 24-bit Network ID and Frequency Hopping
• Enhanced Basic LFSR algorithm
• Extensive power management for ultra-portable
  devices

Optimizes existing technology for home use
39
Voice Robust clarity
40
Data transmission
Service Slot
B
D3
D4
D4
D2
D3
D1
Contention period
D2
D3
D1
Hop
Hop
CSMA/CA access mechanism
U4
U3
U2
U1
U3
U4
U3
U2
U1
Superframe - 20ms
CFP 2
CFP 1
Contention free periods

• CSMA/CA during the contention period
• Efficient for small networks
• Tolerant of interference
• Data for entire frame if no voice

41
Hiperlan2

• 5 GHz technology, up to 54 Mbit/s
• Generic architecture supportingEthernet, IEEE
  1394, ATM, 3G etc
• Connection-oriented with QoS per conn.
• Security - authentication encryption
• Plug-and-play radio network using DFS
• Optimal throughput scheme

42
H2GF - The vision
Local Area WLAN Datacom
Airport
Home
Hotel Conference
Roaming
Train station
Public space
Wide area Cellular Datacom
43
HiperLAN2 Global Forum

• A consortium of 50 companies
• Launched September 1999
• Marketing and education
• Interoperability on system level
• Protect and harmonize spectrum worldwide
• http//www.hiperlan2.com

44
H2GF - The Mission

• Drive the adoption of HiperLAN2 as the global
  broadband wireless technology in 5 GHz band,
  providing untethered connectivity for mobile
  devices in corporate, public and home environments

45
When?

• Commercial products on market late 2001/early
  2002
• Interoperable products mid 2002
• Enterprise market first, soon followed by
  operator, and the home

46
Key Goals

• H/2 will support all existing and planned
  applications in enterprise, public, and homegt
  address the combined WLAN market!
• Smooth interworking with 3G
• Affordable technology

47
HiperLAN2 Technologies

• MAC scheduler at AP
• Centralised control
• Supports uniform traffic load
• Inter Intra system interference mitigation
• Dynamic Frequency Selection (DFS)
• Link Adaptation
• Transmit Power Control (TPC)
• Support of smart (sectored) AP antennas

48
H/2 MAC Layer

• Access Point centralized control
• Time Division Duplex - TDMA
• Up and Down link slots allocated dynamically
  based on need
• Data (up/down) transmitted in dedicated slots
• Contention allowed in random access slots

49
MAC Layer

MAC frame fixed duration 2ms BCH broadcast ch
(info on pwr levels, FCH RCH lengths, etc) FCH
Frame ctr ch (describes resource allocations in
this MAC frame) DL/UL user data trains (dn/up)
of multiple 54 byte payloads ACH access
feedback channel feedback on previous RCH
attempts RCH random access ch to request MAC
resources (high priority Res Requests for UL/DL
allocation, low pr RRs to initiate handover)
50
MAC Layer (cont)

• Logical channels built on top of MAC channels
• SBCH slow broad ch, dwnlk only, coveys contr
  signals (eg MAC-ID assign, encrypt seed)
• DCCH Dedicated cntr ch, signaling between AP
  and MT(Mobile Terminal)
• UDCH User data channel ARQ optional
• Connection uniquely identified by MAC and DLC IDs
• Connection set up does not imply immediate
  resource assignment
• Capacity requested by MT on demand via RR packets

51
Spectrum Allocation in 5 Ghz
