E186 Enterprise Modeling for IT Managers

1
E186Enterprise Modeling for IT Managers

• David Dichmann
• PowerDesigner Product Manager
• eBusiness Division
• Dichman_at_sybase.com

2
Developing for the Business

• Automating the Business Processes
• Meeting the Business Requirements
• Controlling the IT Architecture
• Understanding Existing Systems
• Integration of Systems
• Maintenance of Systems
• Coordinating the Team
• Multi-discipline teams to manage n-tier
  architecture
• Multiple developers and DBAs working the same
  system
• Sensitive property must be secure

3
Business Analysis before technology

• eBusiness is about automating the way we conduct
  our business
• Intranet and Web enabled
• Business to business automating transaction
  processing
• If you cant document it you cant automate it
• If you cant automate it, you cant go to B2B
• Enterprise Application Integration (EAI)
  connecting systems that follow a process
• eCommerce automating order processing its a
  business process!

4
Business Process Modeling

• Describes the business logic and business rules
  from a business users point of view
• Independent of implementation details
• Describes the Flow of Control between tasks in a
  system
• A conceptual, hi-level view of processes, not
  limited by UML definition and notations
• Ensure system accurately automates the business
  practices

5
From Business to Systems Analysis

• Knowing the process is just the start
• We need to know the requirements and other
  details
• UML use case and sequence diagram to describe
  system scope and behavior
• Refines business processes UML activity diagram
• Non-graphical Business Rules throughout all
  elements
• Domain elements in Conceptual Data Models
• Defines what will create a successful system

6
UML use case diagrams

• Capture business and system requirements
• Implementation independent view of a Systems
  context
• Oriented towards analysis, drives design
• Actors are a System and map to one or more
  classes and interfaces
• Use Cases also map to multiple implementation
  classes and interfaces
• Actors, Use Cases, Business Rules,
  Generalizations, Dependencies

7
UML sequence diagrams

• Document interactions between high level and/or
  low level objects
• Actors or Class Instances
• Describe system behavior over time
• Takes Use Case analysis and leads to Design
  details
• Describe operations for classes and interfaces
• Actors, Object Instances, Lifelines, Messages,
  Business Rules

8
UML collaboration diagrams

• Document interactions between elements of a
  system or between the users and the system
• Timing element, but focus is more on structure
• Express same information as a Sequence, but is
  readable in a different way exposes how objects
  depend on each other vs. how they communicate

9
UML activity diagrams

• Describes the activities and the flow of control
• Technical view of the business processes
• Workflow Modeling
• Parallel Processing
• Dynamic analysis of a use case
• Behavior for an object
• Collaboration between objects
• Detailed dynamic view of the elements within a
  system (EJB, Class, etc.)

10
UML statechart diagrams

• Aka state diagram, state machine,
  state-transition diagram
• Defines possible behaviors depending on an
  objects state
• Defines how states change over the objects life
• Better understanding of complex objects
• May be decomposed into sub-statecharts (like a
  functional decomposition)

11
Data Modeling Conceptual Data Model

• Standard E/R modeling
• Business rules, Domains, Data Items, Entities,
  Relationships, Associations, Identifiers,
  Inheritance
• Supports one-to-many many-to-many relationships
• Automatic Physical Data Model generation

12
From Systems Analysis to Design

• We know WHAT to build, but now we need to express
  HOW to build it
• Business Logic needs to be part of
• A component like an EJB in an application server
• Some business logic class or component in a
  client application, using a language like VB or
  PowerBuilder
• eBusiness uses persistent data RDBMS
• Database elements are defined on a traditional
  RDBMS
• Business logic in triggers and procedures

13
From Systems Analysis to Design

• UML Techniques for Business Logic
• Refined use case, activity and sequence diagrams
  develop technical details from requirements
• UML class diagram and component diagram define
  static structures
• Class diagrams define 100 code structure
• Relational Database Design
• Physical Data Models define 100 database
  structures

14
UML class diagram

• Design your Class Structure
• Targets include Java, XML, C, VB.NET, WSDL,
  PowerBuilder, and more, for code generation
• Business Rules, Domains, Classes, Interfaces,
  Attributes, Identifiers, Operations,
  Associations, Realizations, Generalizations,
  Dependencies
• Integration with data modeling
• Round-trip engineering
• Integration with Code Editors and IDEs

15
UML object diagrams

• Object Diagrams give specific examples of classes
  (classifiers)

• More detailed analysis of the Classes
• More detailed explanation more meaning than a
  class diagram
• Instances of classes vs. Classes themselves

16
UML component diagrams

• Describes high level Black Box objects
• Abstract representation for Component Design
• Web Services (MS or Sun)
• J2EE/EJB
• nTier PowerBuilder
• Code Sharing and Reuse
• Documents interfaces to components you can
  easily see what you can use them for without
  reading code

17
UML deployment diagrams

• Documents where and how elements of code will be
  packaged and deployed
• Defines the nodes (server, workstation, database)
  and components (EJB, Web Service, etc) that are
  deployed to them
• Physical Implementation

18
Data Modeling Physical Data Model

• Graphical representation of the database
  structures
• All major relational databases supported
• Business Rules, Domains, Users, Tables, Columns,
  Physical Options, References, Index, Keys, Views,
  Abstract data types, Triggers, Stored Procedures
• Generate SQL DDL
• Reverse-engineering of existing databases

19
Object/Relational Impedance Mismatch or Two
Worlds Collide

• UML and OO is focused on Language
• Constructs organized best for use in Memory
• Data Modeling is Relational Databases
• Normalization for most efficient data expression
• Denormalized for RDBMS optimize performance
• These models cannot express the same system the
  same way!

20
Cant we just use UML for everything?

• UML is
• A technical modeling language for Object-Oriented
  systems
• A model for the business requirements and systems
  analysis
• The model for detailed design and can even map
  11 with deployed code (for code generation or
  reverse engineering)
• UML is NOT
• A Business Modeling technique in the true sense
  too technical for business analysis
• A Data Modeling technique it is Object-Oriented
  which is, in philosophy, incompatible with
  Relational structures

21
How do we manage multiple views?

• The Problem Domain is the Link
• Object Models (UML)
• Domain model Core Elements
• Complete defines all system behavior and logic
• Conceptual Data Models
• Defining core data elements and entities
• Normalized, implementation independent view
• Physical Data Model
• Completes database implementation specification

22
This Requires Teamwork

• Multiple disciplines must coordinate their
  efforts
• Business Analysts
• Systems designers and architects
• Database Professionals
• Same requirements, Same business, Different view
  of the solution
• Business Process Models
• Unified Modeling Language (UML) Models
• Entity/Relationship (E/R) Models

23
Link and Synch all models
Business Process Modelling
(Object Data Process)
TraditionalData Modelling (James Martin)
New Object Oriented(UML Techniques)
24
As the Effort Grows More Teamwork

• Multiple teams working on the same model
• Teams of data analysts and DBAs
• Teams of developers
• Multiple projects may be related or mutually
  exclusive
• Global view of all application elements
• Reuse of existing elements
• Understanding of existing databases

25
Teamwork and Model Management

• We need a good Metadata Repository
• Team development
• Security to protect elements, core, library, etc.
• Single source for all elements Find and Reuse
• Model Management
• Versioning
• Branching
• Compare/Merge
• Reporting

26
The RepositoryArchitecture
27
Reporting Report Generator

• Powerful Report generator
• Multi-model
• Customisable
• Template based
• Easy to use drag-and-drop interface
• Generates RTF or HTML

28
Conclusion

• Enterprise Modeling for modern business systems
• Object oriented analysis and design with UML for
  Java, J2EE, WebServices, and much more
• Formal Data Analysis and Design with
  Entity/Relationship modeling
• Getting results
• An integrated toolset that drives design from
  analysis
• Round-trip engineering to keep Design,
  Development and Run Time in synch
• Control of the Architecture
• Model management and enterprise class repository

29
Sybase Developer Network (SDN)

• Additional Resources for Developers/DBAs
• Single point of access to developer software,
  services, and up-to-date technical information
• White papers and documentation
• Collaboration with other developers and Sybase
  engineers
• Code samples and beta programs
• Technical recordings
• Free software
• Join today www.sybase.com/developer or visit
  SDN at TechWaves Technology Boardwalk

30
