Java EE Enterprise Archive (EAR)

1
Java EE Enterprise Archive (EAR)
2
Goals

• Understand the purpose for an EAR
• Be able to construct an EAR for developed Java EE
  components

3
Objectives

• EAR Purpose
• EAR Format

4
Class Loaders

• Arranged in a parent/child relationship
• Requests for a class are first delegated to the
  parent class loader
• May access classes/resources loaded by local and
  parent class loader
• Do not have access to classes/resources loaded by
  sibling class loaders

5
Separate EJB/WAR Deployment

• Classes loaded by EJB Application Class Loader
  not seen by Web Application
• Shared implementations must be placed in both
  applications
• WEB-INF/lib
• causes difficulty when passing object between
  applications that have loaded the same class

6
J2EE Enterprise Application Deployment
Application Server Class Loader
EAR Class Loader
EJB interfaces and dependent classes identified
by EJB manifests loaded by EARs classloader
EAR Class Loader

• All EJBs are loaded by a single class loader
• may also include web dependent classes identified
  through manifest entries to promote singleton
  loading of classes across web applications

EJB App Class Loader
Web App 2 Class Loader
Web App 1 Class Loader
Servlets/JSPs and lib.jars loaded by isolated
classloaders
7
Enterprise Application Archive (EAR)

• WAR(s)
• directory or archive
• EJB(s)
• directory or archive
• Client JAR(s)
• client applications
• Utility Classes(s)
• directory or archive
• supplies external source utility classes
• referenced through MANIFESTs
• Resource Adapters(s)
• custom resource drivers

8
Directory and Archive Forms

• Exploded Directory Form
• ability to modify static files (html/jsp) without
  redeploying
• separate server serves up content in exploded
  form
• simpler build environment
• consistent with build environment of free
  versions of IDEs (Forte, JBuilder, etc.)
• Archive File Format
• easy form of distribution

9
application.xml
application
icon
display-name
description?
module
security-role
small-icon
large-icon
description?
ejbconnectorjavaweb
alt-dd
role-name
web-uri
context-root
10
Element Definitions

• Application
• Declares the overall enterprise application
• Deployment Tool Info
• icon, display-name, description
• Modules
• ejb EJBs (Ex. EJB1.jar)
• web web applications
• java - client applications
• connector JCA resource adapters

11
Element Definitions (Cont)

• Web applications
• web-uri (ex. webapp1.war)
• context-root
• Name of web apps context
• May be empty if only one webapp in the
  application
• alt-dd
• Can override the deployment descriptor found in
  the module
• security-role
• Define application-level security roles

12
application.xml Example

• lt?xml version"1.0" encoding"UTF-8"?gt
• lt!DOCTYPE application PUBLIC
• "-//Sun Microsystems, Inc.//DTD J2EE
  Application 1.3//EN"
• "http//java.sun.com/dtd/application_1_3.d
  td"gt
• ltapplicationgt
• ltdisplay-namegtejbsessionBankEARlt/display-namegt
• ltdescriptiongtExample Session Bean Bank
  Applicationlt/descriptiongt
• ltmodulegt
• ltwebgt
• ltweb-urigtejbsessionBankWAR.warlt/web-urigt
• ltcontext-rootgt/ejbsessionBankWARlt/context-ro
  otgt
• lt/webgt
• lt/modulegt
• ltmodulegt
• ltejbgtejbsessionBankEJB-1.0.2007.2-SNAPSHOT.jar
  lt/ejbgt
• lt/modulegt

13
Example Project with EAR

• ejbsessionBankgt jar tf ejbsessionBankEAR/target/ej
  bsessionBankEAR-1.0.2007.2-SNAPSHOT.ear
• META-INF/
• META-INF/MANIFEST.MF
• ejbsessionBankImpl-1.0.2007.2-SNAPSHOT.jar
• ejbsessionBankWAR.war
• ejbsessionBankEJB-1.0.2007.2-SNAPSHOT.jar
• META-INF/application.xml
• EJB META-INF/MANIFEST.MF
• Manifest-Version 1.0
• Archiver-Version Plexus Archiver
• Created-By Apache Maven
• Built-By StaffordJ
• Build-Jdk 1.5.0_17
• Class-Path commons-logging-1.0.4.jar
  ejbsessionBankImpl-1.0.2007.2-SNAPSHOT.jar

14
Example Project with EAR source tree

• ejbsessionBankgt tree .
• -- ejbsessionBankImpl
• ...
• -- ejbsessionBankEAR
• -- pom.xml
• -- ejbsessionBankEJB
• ...
• -- ejbsessionBankTest
• ...
• -- ejbsessionBankWAR
• ...
• -- pom.xml

15
Example Project with EAR root pom.xml

• lt?xml version"1.0" encoding"UTF-8"?gt
• ltproject xmlns"http//maven.apache.org/POM/4.0.0"
  xmlnsxsi"http//www.w3.org/2001/XMLSchema-insta
  nce" xsischemaLocation"http//maven.apache.org/P
  OM/4.0.0 http//maven.apache.org/maven-v4_0_0.xsd"
  gt
• ltmodelVersiongt4.0.0lt/modelVersiongt
• ltgroupIdgtejava.javaee.ejblt/groupIdgt
• ltartifactIdgtejbsessionBanklt/artifactIdgt
• ltpackaginggtpomlt/packaginggt
• ltnamegtSession Beanlt/namegt
• ltversiongt1.0-SNAPSHOTlt/versiongt
• ltdescriptiongt
• This project is the root project for the
  core session bean example.
• lt/descriptiongt
• ltmodulesgt
• ltmodulegtejbsessionBankImpllt/modulegt
• ltmodulegtejbsessionBankEJBlt/modulegt
• ltmodulegtejbsessionBankWARlt/modulegt
• ltmodulegtejbsessionBankEARlt/modulegt
• ltmodulegtejbsessionBankTestlt/modulegt
• lt/modulesgt
• lt/projectgt

16
Example Project with EAR ear pom.xml

• ltmodelVersiongt4.0.0lt/modelVersiongt
• ltgroupIdgtejava.javaee.ejblt/groupIdgt
• ltartifactIdgtejbsessionBankEARlt/artifactIdgt
• ltpackaginggtearlt/packaginggt
• ltnamegtSession Bank EARlt/namegt
• ltversiongt1.0-SNAPSHOTlt/versiongt
• ltdependenciesgt
• ltdependencygt
• ltgroupIdgtpom.groupIdlt/groupIdgt
• ltartifactIdgtejbsessionBankEJBlt/artifac
  tIdgt
• ltversiongtpom.versionlt/versiongt
• lttypegtejblt/typegt
• lt/dependencygt
• ltdependencygt
• ltgroupIdgtpom.groupIdlt/groupIdgt
• ltartifactIdgtejbsessionBankWARlt/artifac
  tIdgt
• ltversiongtpom.versionlt/versiongt
• lttypegtwarlt/typegt
• lt/dependencygt

17
Example Project with EAR excluding unwanted
dependencies

• ltdependencygt
• ltgroupIdgtpom.groupIdlt/groupIdgt
• ltartifactIdgtejbsessionBankEJBlt/artifac
  tIdgt
• ltversiongtpom.versionlt/versiongt
• lttypegtejblt/typegt
• ltexclusionsgt
• ltexclusiongt
• ltgroupIdgtcommons-logginglt/grou
  pIdgt
• ltartifactIdgtcommons-logginglt/a
  rtifactIdgt
• lt/exclusiongt
• lt/exclusionsgt
• lt/dependencygt

18
Example Project with EAR ear plugin

• ltbuildgt
• ltpluginsgt
• ltplugingt
• ltgroupIdgtorg.apache.maven.pluginslt
  /groupIdgt
• ltartifactIdgtmaven-ear-pluginlt/arti
  factIdgt
• ltconfigurationgt
• ltdescriptiongt
• Example Session Bean Bank
  Application
• lt/descriptiongt
• ltmodulesgt
• ltwebModulegt
• ltgroupIdgtpom.groupIdlt/g
  roupIdgt
• ltartifactIdgtejbsessionBank
  WARlt/artifactIdgt
• ltcontextRootgtejbsessionban
  klt/contextRootgt
• lt/webModulegt
• lt/modulesgt
• lt/configurationgt
• lt/plugingt
• lt/pluginsgt

19
Example EAR Project build output

• gt tree.
• -- pom.xml
• -- target
• -- application.xml
• -- ejbsessionBankEAR-1.0.2007.2-SNAPSHOT
• -- META-INF
• -- application.xml
• -- ejbsessionBankImpl-1.0.2007.2-SNAPSHOT
  .jar
• -- ejbsessionBankEJB-1.0.2007.2-SNAPSHOT.
  jar
• -- ejbsessionBankWAR-1.0.2007.2-SNAPSHOT.
  war
• -- ejbsessionBankEAR-1.0.2007.2-SNAPSHOT.ear

20
Example EAR Project deploying EAR with cargo
(Test/pom.xml)

• ltplugingt
• ltgroupIdgtorg.codehaus.cargolt/groupIdgt
• ltartifactIdgtcargo-maven2-pluginlt/artifactIdgt
• ltconfigurationgt
• ltcontainergt
• ltcontainerIdgtjboss4xlt/containerIdgt
• lttypegtremotelt/typegt
• lt/containergt
• lt/configurationgt
• ltexecutionsgt
• ltexecutiongt
• ...
• lt/executiongt
• lt/executionsgt
• lt/plugingt

21
Example EAR Project deploying EAR with cargo
(Test/pom.xml)

• ltexecutiongt
• ltidgtdeploy-componentlt/idgt
• lt!-- jump into a phase before
  surefire runs tests --gt
• ltphasegttest-compilelt/phasegt
• ltgoalsgt
• ltgoalgtundeploylt/goalgt
• ltgoalgtdeploylt/goalgt
• lt/goalsgt
• ltconfigurationgt
• ltconfigurationgt
• lttypegtruntimelt/typegt
• ltpropertiesgt
• ltcargo.remote.usernamegt
  jboss.userlt/cargo.remote.usernamegt

• ltcargo.remote.passwordgt
  jboss.passwordlt/cargo.remote.passwordgt
• lt/propertiesgt
• lt/configurationgt
• ...

22
Example EAR Project deploying EAR with cargo
(Test/pom.xml)

• ...
• ltdeployergt
• lttypegtremotelt/typegt
• ltdeployablesgt
• ltdeployablegt
• ltgroupIdgtpom.groupId
  lt/groupIdgt
• ltartifactIdgtejbsession
  BankEARlt/artifactIdgt
• lttypegtearlt/typegt
• lt/deployablegt
• lt/deployablesgt
• lt/deployergt
• lt/configurationgt
• lt/executiongt

23
Example EAR Project deploying EAR with cargo
(Test project output)

• Test output
• INFO Building Session Bank Test
• INFO task-segment install
• INFO -------------------------------------------
  ---------------------------------
• ...
• INFO cargoundeploy execution
  deploy-component
• INFO cargodeploy execution
  deploy-component
• Server Console
• 233850,173 INFO EARDeployer Undeploying J2EE
  application, destroy step file/home/jcstaff/proj
  /ejava-javaee/working/ejbsessionBank/ejbsessionBan
  kEAR/target/ejbsessionBankEAR-1.0.2007.2-SNAPSHOT.
  ear
• 233850,174 INFO EARDeployer Undeployed J2EE
  application file/home/jcstaff/proj/ejava-javaee/
  working/ejbsessionBank/ejbsessionBankEAR/target/ej
  bsessionBankEAR-1.0.2007.2-SNAPSHOT.ear
• 233850,272 INFO EARDeployer Init J2EE
  application file/home/jcstaff/proj/ejava-javaee/
  working/ejbsessionBank/ejbsessionBankEAR/target/ej
  bsessionBankEAR-1.0.2007.2-SNAPSHOT.ear

24
Example EAR Project undeploying EAR with cargo
(EAR/pom.xml)

• ltplugingt
• ltgroupIdgtorg.codehaus.cargolt/groupIdgt
• ltartifactIdgtcargo-maven2-pluginlt/artifactIdgt
• ltconfigurationgt
• ltcontainergt
• ltcontainerIdgtjboss4xlt/containerIdgt
• lttypegtremotelt/typegt
• lt/containergt
• lt/configurationgt
• ltexecutionsgt
• ltexecutiongt
• ltidgtundeploy-earlt/idgt
• ltphasegtpre-cleanlt/phasegt
• ltgoalsgt
• ltgoalgtundeploylt/goalgt
• lt/goalsgt
• ltconfigurationgt
• ltconfigurationgt
• lttypegtruntimelt/typegt

25
Example EAR Project undeploying EAR with cargo
(EAR/pom.xml)

• ...
• ltpropertiesgt
• ltcargo.remote.usernamegtjboss
  .userlt/cargo.remote.usernamegt
• ltcargo.remote.passwordgtjboss
  .passwordlt/cargo.remote.passwordgt
• lt/propertiesgt
• lt/configurationgt
• ltdeployergt
• lttypegtremotelt/typegt
• ltdeployablesgt
• ltdeployablegt
• ltgroupIdgtpom.groupId
  lt/groupIdgt
• ltartifactIdgtpom.arti
  factIdlt/artifactIdgt
• lttypegtearlt/typegt
• lt/deployablegt
• lt/deployablesgt
• lt/deployergt
• lt/configurationgt
• lt/executiongt
• lt/executionsgt

26
Example EAR Project undeploying EAR with cargo
(EAR project output)

• Build output
• gt mvn clean -Pundeploy
• ...
• INFO Building Session Bank EAR
• INFO task-segment clean
• INFO -------------------------------------------
  ---------------------------------
• INFO cargoundeploy execution undeploy-ear
• INFO cleanclean
• ...
• Server console
• 234858,499 INFO EARDeployer Undeploying J2EE
  application, destroy step file/home/jcstaff/proj
  /ejava-javaee/working/ejbsessionBank/ejbsessionBan
  kEAR/target/ejbsessionBankEAR-1.0.2007.2-SNAPSHOT.
  ear
• 234858,500 INFO EARDeployer Undeployed J2EE
  application file/home/jcstaff/proj/ejava-javaee/
  working/ejbsessionBank/ejbsessionBankEAR/target/ej
  bsessionBankEAR-1.0.2007.2-SNAPSHOT.ear

27
Summary

• EARs provide a standard deployment package to the
  application server
• Application server class loader(s) are designed
  to provide efficient sharing of resources defined
  within the EAR
• EAR is a deployment package, cannot be unit
  tested
• requires deployment
• requires functional testing that incorporates
  application server
