Traveler Information Standards The Last Big
Update!

Information Forum Showcase ITS America Annual
Meeting May 8, 2006

• Joel Markowitz, Chair, SAE ATIS Committee
• Metropolitan Transportation Commission
• Oakland, CA

2
WARNING!
ACRONYM
SDO C2C TCIP XML SOAP ITE AASHTO NEMA
ATIS ITS IM TMDD NTCIP APTA ITIS LRMS
ZONE
IEEE ASTM DSRC ADUS WSDL ISO
3
US National ITS Architecture
4
US National ITS Architecture
5
Each SDO Assigned a Functional Area

• Traffic Devices (NTCIP) NEMA, ASSHTO, ITE
• Traveler Data (ATIS) SAE
• Transit Data (TCIP) APTA
• Traffic Management (TMDD) AASHTO,ITE
• Incident Management (IM) IEEE
• Archived Data (ADUS) ASTM
• DSRC ASTM,
  IEEE, SAE

6
Major ATIS Accomplishments

• Completed all assigned standards development
• First ITS standard to develop XML schema
• Successful demo at 2005 World Congress Mitretek
• First ITS standard to apply NTCIP 2306 rules for
  Web services (WSDL) message dialogues
• Developed working repository for cross-standards
  coordination used by other SDOs

7
ATIS Standards Portfolio

8
The SAE J2354 ATIS Message

• Events
• Incidents
• Links
• Routes
• Weather
• Parking

• Preference settings
• Directory services
• Flights schedules
• Mayday
• Reduced bandwidth

9
J2540/2 ITIS Main Groups

• Group Network Conditions
• 1 Traffic Conditions
• 2 Accidents Incidents
• 3 Closures (Road and Lane)
• 4 Roadwork
• 5 Obstructions
• 6 Delays, Status, And Cancellations
• 7 Unusual Driving
• 8 Mobile Situation
• 9 Device And Equipment Status
• 10 Restrictions
• 11 Incident Response Status
• Group Events Affecting Travel
• 12 Disasters
• 13 Disturbances
• 14 Sporting Events
• 15 Special Events
• 16 Parking Information
• 17 Information System

• Group Travel Environment
• 18 Weather Conditions
• 19 Precipitation
• 20 Winds
• 21 Visibility Air Quality
• 22 Temperature
• 23 Pavement Conditions
• 24 Winter Driving Restrictions Recommendations
• 25 Winter Driving Index
• Group Advice
• 26 Suggestion Advice
• 27 Warning Advice
• 28 Instructions (Recommendations)
• 29 Instructions (Mandatory)
• Group Qualifiers
• 31 Generic Locations
• 32 Lane / Roadway Descriptions
• 33 Alternate Route
• Group Groups Affected / Involved

10
ITIS picker screen shot

• One of several small utilities created
  fortraining

11
ITIS Is Everywhere

• ITIS codes are central to ATIS, IM, TMDD and TCIP
  messages
• ITIS codes can be freely mixed with text
• ITIS sub-groupings can be used for message
  filtering
• ITIS is a national code list, but allows local
  codes to be easily added in a consistent way

12
An Example of Cross SDO Integration
The IM message road work uses the ATIS message
event which in turn uses the IM lane
description which in turn uses several TMDD
codes, some of which come from ITIS codes.
IEEE IM Standards
SAE ATIS Standards
Road Work Message
which uses...
EventMessage
which uses...
LaneDescription
ITIS Codes
which uses...
TMDD Items
which uses...
13
Facilitate Center Coordination
City Traffic
State DOT
Emergency Dispatch
14
The Next 6 Months

• All major development work accomplished ?
  maintenance mode
• Finish ballot process for J2354 revision
• Finish user guide based on final balloted
  standard
• Finito!

15
...And beyond

• Continue coordination with TMDD, TCIP, Incident
  Management, and DSRC standards
• Ensure cross-use and harmonization of messages
  and data elements

• Support
• Deployments
• Including 511
• Testing
• DOT Initiatives
• VII, DSRC
• Corridor
• Weather
• Emergency
• Sec. 1201 program

16
For further Information

• General www.sae.org
• The ITS Standards Discussion Board
• For postings on-going technical discussions of
  all things ATIS (as well as other key standards)
  www.itsstandards.org
• Register on-line to receive current information
  and join in the deployment discussions.
• The tools and links mentioned in this briefing
  can all be obtained at the above.

17
(No Transcript)
18
For further Information

• SAE Advanced Traveler Information Systems
  Standards Committee
• New members are always welcome!
• Chairman Joel Markowitz jmarkowitz_at_mtc.ca.gov

• Consultant David Kelley
  davidkelley_at_itsware.net
• Standards Forum
• www.itsstandards.org
