The Compressor: Concurrent, Incremental and Parallel Compaction.

1
The Compressor Concurrent, Incremental and
Parallel Compaction.

• Haim Kermany and Erez Petrank
• Technion Israel Institute of Technology

2
The Compressor

• The first compactor with one heap pass.
• Fully compacts all the objects in the heap.
• Preserves the order of the objects.
• Low space overhead.
• A parallel version and a concurrent version.

3
Garbage collection

• Automatic memory management.
• User allocates objects
• Memory manager reclaims objects which are not
  needed anymore. In practice unreachable from
  roots.

4
Modern Platforms and Requirements

• High performance and low pauses.
• SMP and Multicore platforms
• Use parallel collectors for highest efficiency
• Use concurrent collectors for short pauses.

5
Main Streams in GC

• Mark and Sweep
• Trace objects.
• Go over the heap and reclaim the unmarked
  objects.
• Reference Counting
• Keep the number of pointers to each object.
• When an object counter reaches zero, reclaim the
  object.
• Copying
• Divide the heap into two spaces.
• Copy all the objects from one space to the other.

6
Compaction - Motivation

• MS and RC face the problem of fragmentation.
• Fragmentation unused space between live objects
  due to repeated allocation and reclaiming.
• Allocation efficiency decreases.
• May fail to allocate large objects.
• Cache behavior may be harmed.
• Compaction move all the live objects to one
  place in the heap.
• Best practice keep order of objects for best
  locality.

7
Traditional Compaction

• Go over the heap and write the new location of
  every object in its header (install a forwarding
  pointer).
• Update all the pointers in the roots and the
  heap.
• Move the objects

Stack

• Three Heap Passes

8
Agenda

• Introduction garbage collection, servers,
  compaction.
• The Compressor
• Basic technique
• Obtain compaction with a single heap pass.
• The parallel version.
• The concurrent version.
• Measurements
• Related Work.
• Conclusion

9
Compressor - Overview

• Compute new locations of objects
• Fix root pointers
• Move objects fix their pointers

Stack

• One Heap Passplus one pass over the (small)
  mark-bits table.

10
Compute new locations

• Computing new locations and saving this info
  succinctly
• Heap partitioned to blocks (typically, 512
  bytes).
• Start by computing and saving for each block the
  total size of objects preceding that block (the
  offset vector).

11
Computing A New Address

• Assume a markbit vector which reflect the heap
• First and the last bits of each object are set.
• A new location of an object is computed from the
  markbit and the offset vectors
• for object 5, at the 4th block the new location
  is
• 1000 125 50 1175.

12
Computing Offset Vector

• Computed from the markbit vector.
• Does not require a heap pass

13
Properties

• Single heap pass.
• Plus one pass over the markbit vector.
• Small space overhead.
• Does not need a forwarding pointer.
• Single threaded.
• Stop-the-world.
• Next
• A parallel stop-the-world (STW) version.
• A concurrent version.

14
Parallelization First Try

• Had we divided the heap to two spaces
• The application uses only one space.
• The Compressor compacts the objects from one
  space (from-space) to the other (to-Space).
• Advantage objects can be moved independently.
• Problem space overhead.

15
Eliminating Space Overhead

• Initially, to-space is not mapped to physical
  pages.
• It is a virtual address space.
• For every (virtual) page in to-space (a parallel
  loop)
• Map the virtual page to physical memory.
• Move the corresponding from-space objects and fix
  the pointers.
• Unmap the relevant pages in from-space.

roots
0
1
2
3
4
6
7
8
9
5
4
6
7
8
9
5
0
2
3
1
0 1 2 3 4 5 6 7 8 9
16
Properties

• All virtues of basic Compressor
• Single heap pass, small space overhead.
• Easy parallelization each to-space page can be
  handled independently.
• Stop-The-World.

17
What about Concurrency?

• Problem two copies appear when moving objects
  during application run.
• Sync. problems between compaction and
  application.
• Solution (Baker style) Application can only
  access moved objects (in to-space).

18
Concurrent Version

• Stop application
• Fix roots to new locations in to-space.
• Read-protect to-space and let application resume.
• When application touches a to-space page a trap
  is sprung.
• Trap handler moves relevant objects into the page
  and unprotect the page.

roots
0
1
2
3
4
6
7
8
9
5
4
6
7
8
9
5
19
Implementation Measurements

• Implementation on the Jikes RVM.
• Compressor added to a simple modification of the
  Jikes mark-sweep collector (main modification
  allocation via local-caches).
• Compressor invoked once every 10 collections.
• Benchmarks SPECjbb, Dacapo, SPECjvm98.
• In the talk we concentrate on SPECjbb
• Compared collectors
• no compaction algorithms on the Jikes RVM.
• Some comparison to mark-sweep (MS) and an Appel
  Generational collector (GenMS).

20
SPECjbb Throughput
CON Concurrent Compressor, STW Parallel
Compressor
21
SPECjbb pause time (ms)
22
SPECjbb - Allocations per time
23
Dacapo - Allocations per time
24
Previous Work on Compaction

• Early works Two-finger, Lisp2, and the threaded
  algorithm Jonkers and Morris are single
  threaded and therefore create a large pause time.
• Flood et al. 2001 first parallel compaction
  algorithms. But has 3 heap passes and creates
  several dense areas.
• Abuaiadh et al. 2004 Parallel with two heap
  passes, not concurrent.
• Ossia et al. 2004 execute the pointer fix-up
  part concurrently.

25
Related Work

• Numerous concurrent and parallel garbage
  collectors.
• Copying collectors Cheney 70 compact objects
  during the collection but require a large space
  overhead and do not retain objects order.
• Savings in space overhead for copying collectors
  Sachindran and Moss 2004
• Bacon et al. 2003, Click et al. 2005 propose an
  incremental compaction. But it uses a read
  barrier, and does not keep the order of objects.

26
Complexity Comparisons
27
Conclusion

• The Compressor
• The first compactor that passes over the heap
  only once.
• Plus one pass over the mark-bits vector.
• Fully compacts all the objects in the heap.
• Preserves the order of the objects.
• Low space overhead.
• Uses memory services to obtain parallelism.
• Uses traps to obtain concurrency.

28
