SL45i

1
Product Positioning
Market Introduction 3rd Quarter 2001
The most advanced mobile phone offering new
dimensions of Personlisation Entertainment
System / Standards
Dual Band EGSM 900 / GSM 1800 GSM Phase 2 / Phase
2
Technical Profile

• Dimensions 105 x 42 / 46 x 17 mm (L x W x H)
• Volume 69 cm³
• Weight 88 g
• Standby time 60 - 200 h (standard battery)
• Talk time 1- 4 h (standard battery)
• mp3-play time Approx. 3 hours 30 min.
• Battery Li-Polymer 680mAh
• Charging time 2 h for 100
• Antenna fixed helix
• Speech Codec Triple Rate Vocoder
• SIM Plug-in (3V)

Actual performance is dependent on network
environment Approx. Mp3-play time (GSM standby)
Key Features
Innovative Smart Phone Features

• Self Programming via Unique Wireless
• JavaTM Implementation
• Very Big High Quality Display on an Ultra
  Small Phone Amber display illumination for
  extremely high contrast. 7 lines x 16
  characters, (101x 80 pixels)
• Built-in MP3-Player
• Designed Stereo Headset with Remote Voice
• Control - Top Audio Performance !
• Professional Digital Voice Recorder
• Exchangeable MultiMediaCardTM
• (32MB in Standard package)
• Call Answering Message Function

• 15 short-cut keys (9 programmable)
• Possibility to exchange songs and data between
  the personal computer an the SL45
• Exchangeable MultiMediaCardTM
• - 100rds of phone numbers
• - 500 contacts with 14 fields each
• - 100rds of SMS messages
• - new display pictures and ringer melodies
• - MultiMediaCardTM Explorer
• - 100rds of Java Applications (Midlets)
• The included SyncStation also works as desktop
  charger
• Sync of calendar entries and contacts with MS
  Outlook TM
• Voice Commands Voice Dialing (up to 20
  entries)
• Intelligent Typing (T9)
• Built-in Modem
• Infrared Interface (IrDA)
• Silent Alert
• 4-way Control Key

2
Self-Programmable via Wireless JavaTM

• Unique enhancement of Standardized
• Java2ME MIDP platform
• Over the Air download of applications
• SMS send/receive integration
• Addition User-centric extensions
• Access to MultiMediaCardTM
• Special Game API
• Siemens specific Software Development Kit
• Documentation of Siemens Extensions
• PC Emulator
• The following applications have been selected
• for the first release of SL45i
• GAMES
• Bricks, Worm, Black Jack, i-Skiing
• LEISURE
• Cocktail manager, Chess
• BUSINESS

Digital Voice Recorder
MP3 Player

• Storage media MultiMediaCardTM
• Size of Multimediacard 32 MB (included)
• Playtime (32 MB) 35 min at 128kbit/s
• 45 min at 96 kbit/s
• Play time Approx. 3 hours 30 min.
• Frequency range 20 Hz - 20 kHz
• Power output signal 2x 7,5 mW
• Shuffle, repeat, next track, last track, play,
• stop and pause
• Stereo Headset with top audio quality and
• remote control functionality -
• Holder for both ear pieces included
• Approx. Mp3-play time (GSM standby)
• mp3-function could be started from the remote
  control

• Storage media MultiMediaCardTM
• Size of Multimediacard 32 MB (included)
• Recording 10 min per 1 MB
• Recording time (32 MB) approx. 5 hours
• Continuos recording time 20 minutes
• Easy recording of incoming call (record total
  conversation)
• Voice recorder could be started from the remote
  control

Address book

• Storage media MultiMediaCardTM
• Max number of contacts 500
• Each contact total of 14 fields
• Easy sync with MS Outlook via the included
  SyncStation and the
• included sync-SW (Siemens Quick Sync)

3
Original Accessories
Supported Supplementary Services

• ALS Alternate Line Service
• AOCC Advice of Charge Charging. Display
• of units with Cost Conversation
• AOCI Advice of Charge Information Control
• of Units used with preset Limit
• CAI Display of Charge Advice Information
• CB Call Barring (all GSM options)
• CF Call Forwarding
• CH Call Hold
• CLIP Calling Line Identification Presentation
• CLIR Calling Line Identification Restriction
• CPHS 4.2 Common PCN Handset Specification
• CT Call Transfer
• CUG Closed User Group
• CW Call Wait
• FDN Fixed Dialing Numbers
• HZI Home Zone Indicator
• LND Last Number Dialing
• MTPY Multiparty Conference

• Li-Ion Battery 540 mAh (standard)
• Li-Ion Battery 1000 mAh
• MultiMediaCardTM Reader/Writer
• MultiMediaCardTM 32MB
• Travel Charger (100 - 240 V)
• Headset with PTT key
• Car Charger
• Car Kit Portable
• Car Kit Comfort
• Car Kit Professional Voice
• Data Cable
• Jet Case
• Phone Adapter Professional
• Car Handset
• Adapter Kit Professional
• Adapter Cable VDA
• with data support

Standard Package
Data Services

• Mobile Internet Access (WAP 1.1)
• Data Services _at_ 9.6 kbps
• Fax _at_ 9.6 kbps Fax class 2
• Built-in modem
• IrDA (Infrared) Interface
• Remote Control (via AT Cellular commands)
• SMS Management (MT, MO, CB)
• CD-ROM
• - Data Exchange Software
• - Siemens Quick Sync SW for MS OutlookTM

• SL45 Handset including 32 MB MultiMediaCardTM
• Standard Battery 680 mAh
• Stereo Headset with PTT-button/remote functions
• SyncStation
• Data Cable
• CD-ROM with software
• Light Weight Charger
• User Guides Quick Start

SIM Functionality / Security Controls
Colour Variants ( May vary by country )

• SIM Application Toolkit (class 3)
• SIM Lock, various levels
• PIN 12 Control
• Ciphering A5.1 and A5.2

Silver
The manufacturer reserves the right to modify the
specifications of the product without prior notice
