Initial Distribution System Evaluation IDSE

1
Initial Distribution System Evaluation (IDSE)

• Julie W. Roney
• Technical Assistance and Outreach
• Drinking Water Branch
• Division of Water

2
Purpose of IDSE

• Comprehensive evaluation of a water systems
  distribution system
• Determine areas of elevated THMs and HAAs
• Improve THM and HAA monitoring
• Most importantly, protect public health
• Covers a 1-year period with increased monitoring
• Approximately 2 times the number of compliance
  sites
• Sampled more frequently
• In addition to Stage 1 monitoring

3
Applicability of IDSE

• Applies to community water systems that use a
  disinfectant or deliver water that contains a
  disinfectant
• Covers ground water, surface water and purchasing
  systems
• Each water system will do their own IDSE, even
  the purchasers

4
IDSE Options

• Standard Monitoring Plan (SMP)
• System-Specific Study (SSS)
• 40/30 Waiver
• Very Small System Waiver (VSS)

5
Stage 2 Timeline
6
Very Small System Waiver (VSS)

• For systems serving less than 500 in population
  with small, uncomplicated distribution systems
• Must have taken THM and HAA samples
• If as if under Stage 1 DBP Rule
• 1 sample per year at maximum point in warmest
  month
• Operational data is acceptable
• Some purchasing VSSs may not have THM and HAA data

7
Very Small System Waiver (VSS)

• Waiver is effective immediately
• Is only a waiver from the IDSE, not the Stage 2
  compliance monitoring
• If begin Stage 1 THM/HAA monitoring then must
  continue until Stage 2 takes effect
• Waiver assumes that the 1 site is representative
  of the highest levels of THMs and HAAs

8
Very Small System Waiver (VSS)

• State/EPA can deny the VSS Waiver
• No data
• Site sampled not representative of high THM and
  HAAs
• High DBP levels
• If denied, then the system must do either a
  Standard Monitoring Plan or a System Specific
  Study

9
40/30 Certification

• Eligible systems must have taken all required
  Stage 1 THM and HAA samples
• For 8 consecutive quarters
• No single, individual sample can exceed
• 0.040 mg/L for THMs
• 0.030 mg/L for HAAs
• No THM or HAA MR violations
• States can allow operational data to be used
• Equivalent to Stage 1 data
• Certified lab, adequate number of samples,
  appropriate sample locations

10
40/30 Certification Time Frames
11
40/30 Certification

• 40/30 Certification Letter submitted to EPA/State
• Most likely will require submittal of 40/30 data
  and a schematic
• May also include sites selected for Stage 2
• This is only a waiver from the IDSE, not the
  Stage 2 compliance sites
• Must continue to comply with Stage 1 requirements

12
40/30 Certification

• EPA/State may deny the 40/30 certification
• Data not under 40 ug/L for THMs or 30 ug/L for
  HAAs
• Stage 1 sites not representative or inadequate to
  be used to select Stage 2 sites
• 2 year time frame is not representative of normal
  operating conditions

13
40/30 Certification

• If the 40/30 certification is denied, must do a
  Standard Monitoring Plan or System Specific Study
• If the submitted data is close to the 40/30
  limits, EPA/state may ask that a SMP or SSS be
  done anyway

14
40/30 Certification

• Recordkeeping requirements
• Maintain 40/30 waiver and data for 10 years
• Make 40/30 Certification and any EPA/State
  correspondence available to the public

15
System-Specific Study

• Can be done 2 ways
• Existing monitoring results
• High number of samples taken before the IDSE
  compliance date (5 years prior)
• Example 10,000-49,999 must have had 24 sites
  that result in 144 THMs and 144 HAAs
• Wont see any of this type of SSS
• Modeling
• Extended period water quality model with
  specifics outlined in rule and Guidance Manual
• Does include 1 round of monitoring outlined in
  the Standard Monitoring Plan
• Will go beyond what most systems currently have
  as an hydraulic model
• Will see some of these

16
System-Specific StudyModeling

• Specific modeling criteria set forth in the
  regulation and in the IDSE Guidance Manual
• Minimum requirements
• Simulate 24 hour variation in demand and show a
  consistently repeating 24 hour pattern of
  residence time
• Includes
• 75 of pipe volume
• 50 of pipe length
• All pressure zones
• All 12 diameter pipe and larger
• All 8 diameter pipe and larger that connect
  different zones of pressure or source water,
  storage tanks, pumps control valves
• All 6 diameter pipe or larger that connect
  remotes areas to the main system
• All storage facilities, pump stations and control
  valves

17
System-Specific StudyModeling

• Must be a calibrated model for the current
  distribution system configuration for the highest
  THM and HAA formation potential time period
• Must contain timing and number of THM and HAA
  samples for at least 1 monitoring period at
  locations required under SMP during the peak high
  historical month

18
Standard Monitoring Plan

• Most systems will use this option
• Process for timing, selection of sites and number
  of sites is set by EPA in the regulation
• EPA is developing a Web-based IDSE Tool
• Should be available in March/April 2006

19
Stage 2 Timeline
20
Standard Monitoring Plan

• Required components of a SMP
• Distribution schematic
• Entry points, sources, storage facilities
• Locations and dates of current Stage 1 monitoring
• Locations and dates of proposed Stage 2
  monitoring
• Population served
• Source water type
• Justification of Standard Monitoring sites
• Include a summary of data used to justify the
  sites such as chlorine residuals, TCR data,
  operational samples, etc

21
Standard Monitoring Plan

• Issue with security for distribution schematics
• Not considered Confidential Business Information
  by Feds so subject to FOIA
• Can get around this in 1 of 2 ways
• Schematic of pipes that indicate entry points,
  tanks and monitoring locations with no landmarks
  noted on map
• City road map without pipes that only indicate
  boundaries, entry points, tanks and monitoring
  sites

22
Consecutive System
WTP
WTP
23
Standard Monitoring Plan

• Requirements
• What, Where, How Often monitoring is conducted
• Must be dual sample sets (THM and HAA sampled
  together)
• Monitoring locations
• High THM
• High HAA
• Average
• Entry point
• Number of sites
• Based on population and source water (not number
  of plants)
• Frequency of monitoring
• Every 60 days, 90 days or annually at each site

24
Standard Monitoring Plan

• Requirements (continued)
• Must sample once in the peak high historical
  month based on
• High THMs
• High HAAs or
• Month of warmest water
• If sampling more than once per year, must base
  sampling schedule around this time frame

25
TTHM and HAA5 Standard Monitoring(1)

• For Surface Water and systems that purchase
  Surface water

26
Standard Monitoring Plan

• Factors affecting THM and HAA formation in
  Distribution systems
• TOC (precursor) concentration
• Type and dose of disinfectant
• Water chemistry and temperature
• Residence time
• HAA biodegradation

27
Standard Monitoring Plan

• Tools to use to help select sites for SMP
• Distribution system maps and operating data
• Water flow (pump runs, billing records, tracer
  study)
• Tank impacts
• Booster chlorination impacts
• Water use
• Entry points and sources
• Key components (tanks, boosters)
• Water quality data
• Source water quality
• DBPs
• Disinfectant residuals
• Bacts and HPCs

28
Standard Monitoring Plan

• Selecting Near Entry Point sites
• Not the plant tap (after treatment and close to
  the 1st distribution system customer)
• If more entry points than needed for SMP
• Use entry points with highest flow
• If fewer entry points than needed for SMP
• Replace required entry point samples with
  alternating high THM then high HAA samples

29
Standard Monitoring Plan

• Selecting Average Residence sites
• Use flow and population weighted analyses
• Distribution maps and operational data
• Hydraulic model or tracer study
• Pump run times, metered flow
• Distribution water quality data
• Average disinfectant residuals

30
Standard Monitoring Plan

• Selecting High THM sites
• High residence times
• Downstream of tanks
• Close to dead ends
• Hydraulic dead ends and mixing zones
• Downstream of booster chlorination
• Areas where it is difficult maintaining chlorine
  residuals
• Low water use
• High historic THMs
• Avoid
• Actual dead ends
• Upstream of booster chlorination

31
Standard Monitoring Plan

• Selecting High HAA sites
• High residence times but consider possible
  biodegradation
• Downstream of booster chlorination
• Sites with low but detectable chlorine residuals
• High historic HAAs
• Others such as tanks, before dead ends, hydraulic
  dead ends and mixing zones, low water use
• Avoid
• Areas with known biofilms (such as high HPCs)
• Areas where it is difficult to maintain a
  chlorine residual

32
Standard Monitoring Plan

• Submit the proposed monitoring plan to EPA/state
• Have 1 to approve/disapprove
• Conduct the 1 year of monitoring
• Submit an IDSE report
• 3 months after completing IDSE
• Identify new Stage 2 THM and HAA sites
• Include a compliance monitoring plan
• Wont have to do this later
• Begin Stage 2 monitoring per water system
  schedule

33
Standard Monitoring Plan

• Recordkeeping
• Keep copy of SMP and EPA/State approval or
  modifications for 10 years
• Must be available for review by EPA, state or
  public
• CCR for a given calendar year during which IDSE
  monitoring occurred must include those results
• Range of values

34
Review of the Standard Monitoring Plans Form
35
Walk Through Example SM Form

• System Information
• Population served 8,000
• Sources
• One surface water source produces 1 MGD
• Two wells produce 0.5 MGD each
• One consecutive connection draws 0.1 MGD
• Wholesale system serves 1 million people
• Compliance dates based on Schedule 1
• Wholesale systems schedule

36
I. General Information
37
I. General Information
38
II. IDSE Requirements
39
III. Selecting IDSE Standard Monitoring Sites
40
IV. Justification Of IDSE Monitoring Sites
41
IV. Justification Of IDSE Monitoring Sites


42
IV. Justification Of IDSE Monitoring Sites


43
IV. Justification Of IDSE Monitoring Sites


44
IV. Justification Of IDSE Monitoring Sites


45
V. Peak Historical Month
46
V. Standard Monitoring Dates
47
VI. Stage 1 DBPR Monitoring Dates
48
VII. Distribution System Schematic
49
VII. Distribution System Schematic
Booster
TP
4
1
2
A
B
3
Connection
50
VIII. Attachments
Next
51
QUESTIONS??? COMMENTS???

• Julie W. Roney, Supervisor
• Technical Assistance and Outreach
• Drinking Water Branch
• 502/564-3410
• Julie.Roney_at_ky.gov
• www.epa.gov/safewater
