Waterside Site Assessment

1
Waterside Site Assessment
2
Waterside Generating Station, Circa 1906
3
Waterside Facility Today
4
Waterside Facility Relocations

• Relocate Reconfigure
• Substations
• Transformers
• Circuits

• Relocate
• Transmission System Control Center
• Telecommunications Facilities
• Operations IT Security Personnel

Relocate Reconfigure Gas Facilities
5
Relocation Costs and Schedule

• Reimbursable Costs ( millions)
• Relocate and Reconfigure Substation
  Facilities 60.0
• Additional Relocation Projects 3.1
• Distribution Circuit Work
• Substation Operations and IT Employees
• Gas Facilities
• Total 63.1
• LGE Costs
• Transmission System Control Center 11.0
• Replacement of 26 MW Peaking Capacity N/A
• Schedule
• 24 months from Funding Authorization and
  Regulatory Approval
• Property Value of 14.75 million, which includes
  west side of 3rd Street, is not included.

6
Future View of Substation
7
Substation in Downtown Chicago
8
Arena Rendering
9
Current Status

• Supporting Consultants Retained by State to
  Perform Environmental Study
• Reviewed Historical Records and Drawings with
  Consultants in Preparation for Environmental
  Study
• Prepared Site Access Agreement with State and
  Consultants to Enable Sampling of Soil, Paint,
  Insulation, etc.
• Prepared Confidentiality Agreements with State
  and Consultants
• Providing Site Access and Information as Needed
  to Support State
• Initiated Internal Processes in Anticipation of
  Arena Funding Approval
• Procurement
• Regulatory
