CMPUT 301: Lecture 31 Out of the Glass Box

1
CMPUT 301 Lecture 31Out of the Glass Box

• Martin Jagersand
• Department of Computing Science
• University of Alberta

2
Overview

• Idea
• why only use the sense of vision in user
  interfaces?
• increase the bandwidth of the interaction by
  using multiple sensory channels, instead of
  overloading the visual channel

3
Overview

• Multi-sensory systems
• use more than one sensory channel in interaction
• e.g., sound, video, gestures, physical actions
  etc.

4
Overview

• Usable senses
• sight, sound, touch, taste, smell,
• Haptics, proprioception and accelerations
• each is important on its own
• together, they provide a fuller interaction with
  the natural world

5
Overview

• Usable senses
• computers rarely offer such a rich interaction
• we can use sight, sound, and sometimes touch
• Flight simulators and some games uses
  accelerations to create a multimodal immersion
  experience.
• we cannot (yet) use taste or smell

6
Overview

• Multi-modal systems
• use more than one sense in the interaction
• e.g., sight and sound a word processor that
  speaks the words as well as rendering them on the
  screen

7
Overview

• Multi-media systems
• use a number of different media to communicate
  information
• e.g., a computer-based teaching system with
  video, animation, text, and still images

8
Speech

• Human speech
• natural mastery of language
• instinctive, taken for granted
• difficult to appreciate the complexities
• potentially a useful way to extend human-computer
  interaction

9
Speech

• Structure
• phonemes (English)
• 40 (24 consonant and 16 vowel sounds)
• basic atomic units of speech
• sound slightly different depending on context

10
Speech

• Structure
• allophones
• 120 to 130
• all the sounds in the language
• count depends on accents

11
Speech

• Structure
• morphemes
• basic atomic units of language
• part or whole words
• formed into sentences using the rules of grammar

12
Speech

• Prosody
• variations in emphasis, stress, pauses, and pitch
  to impart more meaning to sentences
• Co-articulation
• the effect of context on the sound
• transforms phonemes into allophones

13
Speech Recognition

• Problems
• different people speak differently(e.g., accent,
  stress, volume, etc.)
• background noises
• ummm and errr
• speech may conflict with complex cognition

14
Speech Recognition

• Issues
• recognizing words is not enough
• need to extract meaning
• understanding a sentence requires context, such
  as information about the subject and the speaker

15
Speech Recognition

• Phonetic typewriter
• developed for Finnish(a phonetic language)
• trained on one speaker, tries to generalize to
  others
• uses neural network that clusters similar sounds
  together, for a character
• poor performance on speakers it has not been
  trained on
• requires a large dictionary of minor variations

16
Speech Recognition

• Currently
• single user, limited vocabulary systems can work
  satisfactorily
• no general user, general vocabulary systems are
  commercial successful, yet
• Current commercial examples
• Simple telephone based UI such as Train schedule
  information systems

17
Speech Recognition

• Potential
• for users with physical disabilities
• for lightweight, mobile devices
• for when users hands are already occupied with a
  manual task (auto mechanic, surgeon)

18
Speech Synthesis

• What
• computer-generated speech
• natural and familiar way of receiving information

19
Speech Synthesis

• Problems
• human find it difficult to adjust to monotonic,
  non-prosodic speech
• computer needs to understand natural language and
  the domain
• Speech is transient(hard to review or browse)
• produces noise in the workplace or requires
  headphones(intrusive)

20
Speech Synthesis

• Potential
• screen readers
• read a textual display to a visually impaired
  person
• warning signals
• spoken information especially for aircraft pilots
  whose visual and haptic channels are busy

21
Speech Synthesis

• Virtual newscaster (Ananova)

22
Uninterpreted Speech

• What
• fixed, recorded speech
• e.g., played back in airport announcements
• e.g., attached as voice annotation to files

23
Uninterpreted Speech

• Digital processing
• change playback speed without changing pitch
• to quickly scan phone messages
• to manually transcribe voice to text
• to figure out the lyrics and chords of a song
• spatialization and environmental effects

24
Non-Speech Sound

• What
• boings, bangs, squeaks, clicks, etc.
• commonly used in user interfaces to provide
  warnings and alarms

25
Non-Speech Sound

• Why
• fewer typing mistakes with key clicks
• video games harder without sound

26
Non-Speech Sound?

• Doh!

27
Non-Speech Sound

• Dual mode displays
• information presented along two different sensory
  channels
• e.g., sight and sound
• allows for redundant presentation
• user uses whichever they find easiest
• allows for resolution of ambiguity in one mode
  through information in the other

28
Non-Speech Sound

• Dual mode displays
• humans can react faster to auditory than visual
  stimuli
• sound is especially good for transient
  information that would otherwise clutter a visual
  display
• sound is more language and culture independent
  (unlike speech)

29
Non-Speech Sound

• Auditory icons
• use natural sounds to represent different types
  of objects and actions in the user interface
• e.g., breaking glass sound when deleting a file
• direction and volume of sounds can indicate
  position and importance/size
• SonicFinder
• not all actions have an intuitive sound

30
Non-Speech Sound

• Earcons
• synthetic sounds used to convey information
• structured combinations of motives (musical
  notes) to provide rich information

31
Non-Speech Sound

• Earcons

32
Handwriting Recognition

• Handwriting
• text and graphic input
• complex strokes and spaces
• natural

33
Handwriting Recognition

• Problems
• variation in handwriting between users
• variation from day to day and over years for a
  single user
• variation of letters depending on nearby letters

34
Handwriting Recognition

• Currently
• limited success with systems trained on a few
  users, with separated letters
• generic, multi-user, cursive text recognition
  systems are not accurate enough to be
  commercially successful
• Current applications e.g. pre-sorting of mail
  (but human has to assist with failures)

35
Handwriting Recognition

• Newton
• printing or cursive writing recognition
• dictionary of words
• contextual recognition
• fine tune spacing and letter shapes
• fine tune recognition speed
• learn handwriting over time

36
Handwriting Recognition

• Newton

37
End

• What did I learn today?
• What questions do I still have?
