Recap

1
Recap
2
Instruction Set Architecture (ISA)

• The ISA is the interface between hardware and
  software.
• The ISA serves as an abstraction layer between
  the HW and SW
• Software doesnt need to know how the processor
  is implemented
• Any processor that implements the ISA appears
  equivalent
• An ISA enables processor innovation without
  changing software
• This is how Intel has made billions of dollars.
• Before ISAs, software was re-written/re-compiled
  for each new machine.

3
What is instruction set architecture (ISA)?

• Instruction set of a computer the portion of the
  computer visible to the assembly level programmer
  or to the compiler writer ISA
• Defines registers
• Defines data transfer modes (instructions)
  between registers, memory and I/O
• There should be sufficient instructions to
  efficiently translate any program
• Next, define instruction set format binary
  representation used by the hardware
• Variable-length vs. fixed-length instructions

4
Growth/Variations of Processors
5
Instruction Set Architectures

• There are 4 classes of ISA
• Stack
• Embedded processors
• Accumulator
• Embedded processors
• Register-memory
• Pentium
• Register-Register (Load-store)
• Sparc

6
Instruction Set Architecture

• For a general purpose high-performance computer
• Register-Register (Load-store) is the preferred
  choice
• CPI uniform for most instructions
• Better pipelining
• Fixed length instructions
• Simpler encoding
• The complier is more complicated

7
Important issues to consider for designing an ISA

• What are the different addressing modes that
  should be used
• What is the length of instructions
• What are the different instructions used
• What is the type and size of operands

8
Addressing Modes
9
85
75
10
Addressing Modes

• Register (direct) mode

op opcode rs first source register rt second
source register rd destination register
Example ADD r1, r2, r3
11
Addressing Modes

• Immediate mode

op opcode rs source register rt destination
register immed constant
Example ADDI r3, r1, 12
12
Addressing Modes

• Displacement mode

Example LOAD r1, 100(r2)
r2 150 100(r2) 88
13
Displacement and Immediate Values

• Important addressing modes Register, immediate,
  displacement, register indirect. Account for 88
  of workload.
• Through measurements, 12-16 bits are enough to
  cover the majority of cases for the value of
  immediate
• This will allow to have instruction sets of fixed
  size of 32 bits most microprocessors

14
Instruction Usage Example Top 10 Intel X86
Instructions
Rank
Integer Average Percent total executed
1
2
3
4
5
6
7
8
9
10
Observation Simple instructions dominate
instruction usage frequency.
15
Instruction Set Encoding

• Considerations affecting instruction set
  encoding
• To have as many registers and address modes as
  possible.
• The Impact of the size of the register and
  addressing mode fields on the average instruction
  size and on the average program.
• To encode instructions into lengths that will be
  easy to handle in the implementation. On a
  minimum to be a multiple of bytes.

16
Instruction Format

• Fixed
• Operation, address specifier 1, address specifier
  2, address specifier 3.
• MIPS, SPARC, Power PC.
• Variable
• Operation of operands, address specifier1, ,
  specifier n.
• VAX
• Hybrid
• Intel x86
• operation, address specifier, address field.
• Operation, address specifier 1, address specifier
  2, address field.
• Operation, address field, address specifier 1,
  address specifier 2.
• Summary
• If code size is most important, use variable
  format.
• If performance is most important, use fixed
  format.

17
Three Examples of Instruction Set Encoding
Operations no of operands
Address specifier 1
Address field 1
Address specifier n
Address field n
Variable VAX (1-53 bytes)

Operation
Address field 1
Address field 2
Address field3
Fixed DLX, MIPS, PowerPC, SPARC
Operation
Address field
Address Specifier
Address Specifier 1
Address Specifier 2
Operation
Address field
Address Specifier
Address field 2
Operation
Address field 1
Hybrid IBM 360/370, Intel 80x86
18
Summary ISA

• Use general purpose registers with a load-store
  architecture.
• Support these addressing modes displacement,
  immediate, register indirect.
• Support these simple instructions load, store,
  add, subtract, move register, shift, compare
  equal, compare not equal, branch, jump, call,
  return.
• Support these data size 8-,16-,32-bit integer,
  IEEE FP standard.
• Provide at least 16 general purpose registers
  plus separate FP registers and aim for a minimal
  instruction set.

19
Alternative Architectures

• Design alternative
• provide more powerful operations
• goal is to reduce number of instructions executed
• danger is a slower cycle time and/or a higher
  CPI
• Lets look (briefly) at IA-32

• The path toward operation complexity is thus
  fraught with peril. To avoid these problems,
  designers have moved toward simpler instructions

20
IA - 32

• 1978 The Intel 8086 is announced (16 bit
  architecture)
• 1980 The 8087 floating point coprocessor is
  added
• 1982 The 80286 increases address space to 24
  bits, instructions
• 1985 The 80386 extends to 32 bits, new
  addressing modes
• 1989-1995 The 80486, Pentium, Pentium Pro add a
  few instructions (mostly designed for higher
  performance)
• 1997 57 new MMX instructions are added,
  Pentium II
• 1999 The Pentium III added another 70
  instructions (SSE)
• 2001 Another 144 instructions (SSE2)
• 2003 AMD extends the architecture to increase
  address space to 64 bits, widens all registers
  to 64 bits and other changes (AMD64)
• 2004 Intel capitulates and embraces AMD64
  (calls it EM64T) and adds more media extensions
• This history illustrates the impact of the
  golden handcuffs of compatibility
• adding new features as someone might add
  clothing to a packed bagan architecture that
  is difficult to explain and impossible to love

21
IA-32 Overview

• Complexity
• Instructions from 1 to 17 bytes long
• one operand must act as both a source and
  destination
• one operand can come from memory
• complex addressing modes e.g., base or scaled
  index with 8 or 32 bit displacement
• Saving grace
• the most frequently used instructions are not too
  difficult to build
• compilers avoid the portions of the architecture
  that are slow
• what the 80x86 lacks in style is made up in
  quantity, making it beautiful from the right
  perspective
