Title: D.E.L.K. Insurance


1
D.E.L.K. Insurance
  • Expansion Plan

2
Group 4 Members
  • Derek Bredbenner
  • Ester Lopez
  • Laura Holley
  • Kevin Stoker

3
Old Regional Office Setup
  • 1512 sq ft.
  • 10 workstations
  • Locations
  • Houston
  • San Antonio
  • Lubbock
  • El Paso

4
Proposed Branch Office Setup
  • Want to expand to rural areas
  • Offices 525 sq. ft.
  • 4 workstations per office

5
Virtual Private Network
  • Southwestern Bell Internet Services
    Enterprise Virtual Private Network is a cost
    effective, high performance, packaged solution
    for business-critical intranets, WANs and
    extranets.
  • Included in the package
  • Secure Remote Access
  • WAN Connections Network
  • Security Internet Access
  • Service Level Agreements
  • Extranet Communications
  • One Integrated Bill
  • Customer Care

6
Laptop
  • Dell Latitude C840
  • P4 processor 1.6Ghz
  • 15" display
  • Win 2000 small business software
  • 512 MB 400mhz memory (upgradeable to 1024)
  • 64 MB video card 40 GB internal HD can upgrade to
    60 MB internal or second 20 GB removable HD
  • 24x CD (upgradeable to DVD, CD/RW drive, or
    combo)
  • True Mobile wireless PC card
  • 3 yr. onsite repairs and parts w/lifetime
    telephone support
  • Price per machine 2437

7
Wireless Access Point
  • True Mobile 1170
  • Upgrade capabilities as future radio technologies
    are developed.
  • Supports the latest wireless speeds of 11Mbps and
    up to 32 users.
  • Range of up to 525 ft at 11Mbps.
  • Works seamlessly with the Dell laptop wireless
    pc card.
  • Supports IEEE 802.11b security standards.
  • Price 899

8
Server
  • DELL Power Vault 100T
  • 4mm DAT
  • High data reliability
  • Additional level of Error Correction Code
  • Data Capacity 20 (native) to 40 GB (typical)
  • Transfer Rate (sustained) 20 (native) to 4.7
    MB/sec (typical)
  • Supported Formats DDS-4, DDS-3, DDS-2, DDS,
    DDS-DC and DCLZ
  • High Burst Transfer Rate 14 MB/sec
    Asynchronous, 40 MB/sec Synchronous
  • Supports Variable or Fixed Record Length
  • Quick Search Forward 115 times, Reverse 155
    times normal DDS-4 Read/Write speed
  • Dell Provides Technical Support
  • Cost 999.00

9
Router
  • EtherFast Wireless Access Point plus Cable/DSL
    Router with 4-Port Switch
  • Provides connection for high-speed broadband
    Internet connection and 10/100 Fast Ethernet
    backbone.
  • Configurable as a DHCP server for any existing
    network.
  • Acts as the only externally recognized Internet
    gateway on your (LAN).
  • Serves as an Internet NAT firewall against
    unwanted outside intruders.
  • Network monitoring, uplink, switching, 128-bit
    encryption, IP-routing, DHCP support, 128-bit
    WEP, manageable.
  • Network/Transport Protocol TCP/IP, PPTP.
  • Service/Support 1 year warranty.
  • Maximum Range Indoors/Outdoors 91 m/457 m.
  • Interoperable with IEEE 802.11b (DSSS) 2.4
    GHz-compliant equipment.
  • Provides roaming, best access point selection,
    load balancing, and network traffic filtering
  • Capable of up to 64-Bit WEP encryption.
  • Internal 4-port Switch dramatically speeds up
    your gaming and multimedia connections .
  • Cost 169.95

10
Switch
  • 3COM Office Connect Dual Speed Switch Perp and
    Port With Auto MDI/X
  • Communication Mode Half-duplex, Full-duplex
  • Compliant Standard IEEE 802.3-LAN, IEEE
    802.3U-LAN
  • Connectivity Technology Cable
  • Data Link Protocol Ethernet, Fast Ethernet
  • Data Transfer Rate 100 Mbps
  • Network Ports Quality 8 x Ethernet 10Base-T,
    Ethernet 100Base-TX
  • Service Support Lifetime Warranty
  • Switching Protocol Ethernet
  • Cost 129.95

11
Firewall
  • Barrier to keep destructive forces away from your
    property.
  • Filters the information coming through the
    Internet connection into your private network or
    computer system.
  • If an incoming packet of information is flagged
    by the filters, it is not allowed through.

12
McAfee Personal Firewall
  • Features
  • Protection of Personal InformationPlaces a
    barrier between hackers and your hard drive,
    helping to block hacker access to your personal
    and financial information
  • Immediate AlertsFeaturing advanced technologies,
    records potentially hostile Internet traffic and
    alerts you on clear response options for each
    noted activity
  • Detailed Event InformationRecords intrusion
    attempts and unsolicited traffic, letting you
    know what happens to your computer on a daily or
    weekly basis
  • Blocks Specified Internet SystemsAllows you to
    block specific computers and systems on-demand
  • Hackerwatch.org IntegrationProvides links to
    Hackerwatch.org (a Web site dedicated to
    monitoring hacker activities), which provides
    recommendations on how to respond to particular
    attack types
  • Automatic, 24x7 Online UpdatesChecks
    automatically for updates and upgrades, prompting
    you when new releases are available. Backed by
    McAfee.com's impressive infrastructure, never
    worry about out-of-date or obsolete versions
  • Multi-Layered Security Provides a comprehensive,
    multi-layered PC security solution when combined
    with VirusScan Online

13
Cost per Branch Office
  • Itemized Costs
  • 4 Dell C840 Laptops _at_ 2437 ea. 9748
  • 1 True Mobile 1170 Wireless Access Point 899
  • 4 McAfee Personal Firewall Licenses _at_ 25 ea.
    100
  • Total Cost 10,747

14
Cost for Regional Office Updates
  • Itemized Costs
  • 1 DELL Power Vault 100T 999
  • 1 Ether Fast Wireless Access Point 170
  • 1 3COM Office Connect Dual Speed Switch 130
  • Total Cost 1299
  • Other Costs 1000/mo. VPN access

15
How you will save
  • Virtual Private Network will eliminate leased
    line costs.
  • VPN allows branch offices to be built anywhere
    while monthly cost stays the same, whereas leased
    line would cost more the further branch offices
    were from regional offices.
  • Wireless systems in branch offices eliminate
    costs for wiring materials and installation.
  • Wireless systems make workers more efficient and
    mobile.
  • Reach more customers
  • Serve customers more efficiently and quickly
    gaining more business and keeping current
    customers.
  • By having less workers per building we reduce
    square footage, thus reducing building costs.
    This will allow us to build more branch offices.

16
Questions
