Chapter 4 Hardware Applications for Education

1
Chapter 4Hardware Applications for Education
2
CHAPTER 4 PRIMARY OBJECTIVES

• Describe the system unit
• Define a bit and describe how a series of bits
  are used to represent data
• Identify the major components in the system unit
  and explain their functions
• Explain how the CPU uses the four steps of a
  machine cycle to process data

3
CHAPTER 4 PRIMARY OBJECTIVES (cont.)

• Describe the four types of input and input
  devices
• List the characteristics of a keyboard and
  identify various types of keyboards
• Identify various types of pointing devices
• Differentiate between the four types of output

4
CHAPTER 4 PRIMARY OBJECTIVES (cont.)

• Identify the different types of output devices
• Explain the differences among various types of
  printers
• Differentiate between storage and memory
• Identify types of storage media and devices

5
CHAPTER 4 PRIMARY OBJECTIVES (cont.)

• Explain how data is stored on floppy and hard
  disks
• Differentiate between CD-ROMs and DVD-ROMs

6
THE SYSTEM UNIT

• System unit
• Box-like case that houses the electronic
  components of the computer that are used to
  process data

7
DATA REPRESENTATION

• Analog vs. Digital
• Digital
• Two states
• Binary number system
• Combination of ones and zeroes represent
  characters
• ASCII
• Converting a keyboard stroke into a byte

Click to see Figure 4-2
Click to see Figure 4-3
Click to see Figure 4-4
8
THE COMPONENTS OF THE SYSTEM UNIT

• The Motherboard
• Contains many of the electronic components
• Chip
• A small piece of semiconducting material on which
  one or more integrated circuits are etched

Click to see Figure 4-5
9
THE COMPONENTS OF THE SYSTEM UNIT

• CPU and Microprocessor
• Interprets and carries out the basic instructions
  that operate a computer
• Microprocessor contains the CPU in a PC

10
CPU AND MICROPROCESSOR

• The Arithmetic/Logic Unit
• Performs the execution part of the machine cycle
• Arithmetic (addition, subtraction,
  multiplication, division)
• Comparison (greater than, equal to, less than)
• Logical (AND, OR, NOT)

11
CPU AND MICROPROCESSOR

• The System Clock
• Synchronizes all computer operations
• Each tick is called a clock cycle
• Faster clock means more instructions the CPU can
  execute each second
• Speed measured in megahertz (MHz)
• One million ticks of the system clock

12
CPU AND MICROPROCESSOR

• Memory
• Used to store data, instructions, and information
• The operating system and other system software
• Application programs
• Data being processed by application programs
• Bytes are stored at specific locations or
  addresses

13
CPU AND MICROPROCESSOR

• Memory
• Size of memory is measured by the number of bytes
  available
• Kilobyte - 1,024 bytes
• Megabyte - one million bytes

Click to see Figure 4-11
14
CPU AND MICROPROCESSOR

• Random Access Memory (RAM)
• The memory chips in the system unit
• When the computer starts, operating system files
  are loaded from a hard disk into RAM
• Dynamic RAM (DRAM)
• Static RAM (SRAM)

15
CPU AND MICROPROCESSOR

• Random Access Memory (RAM)
• RAM Chips
• Smaller in size than processor chips
• Packaged on circuit boards called single inline
  memory modules (SIMMs) or dual inline memory
  modules (DIMMs)

16
CPU AND MICROPROCESSOR

• Random Access Memory (RAM)
• Configuring RAM
• The more RAM, the more programs and files a
  computer can work on at once
• Software usually tells you how much RAM is
  required
• Necessary RAM depends on what type of work the
  computer is used for

Click to see Figure 4-13
17
CPU AND MICROPROCESSOR

• Read-Only Memory (ROM)
• Cannot be modified
• Contents not lost when the computer is turned off

18
CPU AND MICROPROCESSOR

• Expansion Slots and Expansion Cards
• Expansion slot
• An opening, or socket, where a circuit board can
  be inserted into the motherboard
• Add new devices or capabilities to the computer
• Common expansion cards
• Video card
• Sound card
• Internal modem
• Plug and Play

19
CPU AND MICROPROCESSOR

• Ports and Connectors
• Port
• Point of attachment to the system unit
• Usually on the back of the computer
• Connectors
• Used to plug into ports

Click to see Figure 4-15
20
SUMMARY OF THE SYSTEM UNIT

• Identify the major components of the system unit
• How do the major components of the system unit
  operate

21
INPUT

• Any data or instructions you enter into the
  memory of a computer
• Any hardware component that allows you to enter
  data, programs, commands, and user responses into
  a computer

22
WHAT ARE INPUT DEVICES?

• Optical Scanner
• Electronically captures an entire page of text or
  images
• Converts text or image into digital data than can
  be stored and used
• Cardscan video

Click to view video
23
WHAT ARE INPUT DEVICES?

• Optical Readers
• Uses light to read characters, marks, and codes
  and then converts them into digital data that can
  be processed by a computer
• Optical character recognition (OCR)
• Reads character printed in OCR font
• Optical mark recognition (OMR)
• Bar code

24
WHAT ARE INPUT DEVICES?

• Input Devices for Challenged Students
• Americans with Disabilities Act (ADA)
• Keyguard
• Touch window
• Pointing devices

Click to see Figure 4-27
25
WHAT IS OUTPUT?

• Text
• Graphics
• Audio
• Video

26
WHAT ARE OUTPUT DEVICES?

• Monitors
• Screen housed in a plastic or metal case
• Variety of sizes
• Cathode ray tube (CRT)
• Pixels
• LCD (liquid crystal display) monitors

Click to see Figure 4-30
Click to see Figure 4-31
27
WHAT ARE OUTPUT DEVICES?

• Monitor Quality
• Resolution (sharpness and clarity)
• Expressed as number of columns and rows
• 640 x 480
• Most modern monitors can display 600x800 or
  1024x768
• Dot pitch
• Refresh rate
• ENERGY STAR

28
WHAT ARE OUTPUT DEVICES?

• Printers
• An output device that produces text and graphics
  on a physical medium such as paper or
  transparency film
• Hard copy (printout)
• Portrait vs. landscape
• Printing requirements vary

29
WHAT ARE OUTPUT DEVICES?

• Impact Printers
• Printing mechanism strikes paper, ribbon and
  character together
• Noisy
• Not usually high quality
• Dot matrix printers
• Continuous form paper

Click to see Figure 4-33
30
WHAT ARE OUTPUT DEVICES?

• Nonimpact Printers
• Do not strike paper
• Much quieter
• Ink-jet printers
• Spray tiny drops of ink onto the paper
• Both black-and-white and color

Click to see Figure 4-34
31
WHAT ARE OUTPUT DEVICES?

• Nonimpact Printers
• Laser printers
• High-speed, high-quality nonimpact printer
• Very high quality resolution - 300dpi to 1,200
  dpi

Click to see Figure 4-35
32
WHAT ARE OUTPUT DEVICES?

• Data Projectors
• Allows an audience to view output
• LCD projectors
• Digital light processing (DLP) projector

33
WHAT ARE OUTPUT DEVICES?

• Facsimile (Fax) Machine
• Used to transmit and receive an image of a
  document over a phone line
• Stand-alone
• Fax modem

34
WHAT ARE OUTPUT DEVICES?

• Output Devices for Challenged Students
• Display instead of sound for hearing impaired
• Change color and magnification on screen
• Braille printer

35
WHAT IS STORAGE?

• The media on which data, instructions, and
  information are kept
• The devices that record and retrieve data,
  instructions, and information
• Like a filing cabinet

Click to see Figure 4-42
36
WHAT IS STORAGE?

• Storage Media and Devices
• Storage medium
• Physical material
• Storage device
• Mechanism used to record and retrieve
• Capacity measured in megabytes or gigabytes

37
WHAT IS STORAGE?

• Floppy Disks
• storage medium consisting of a thin circular
  flexible film enclosed in a square shaped plastic
  shell
• Characteristics of a Floppy Disk
• Uses magnetic patterns to store data
• Formatting
• Track
• Sector

Click to see Figure 4-43
Click to see Figure 4-44
Click to see Figure 4-45
38
WHAT IS STORAGE?

• High-Capacity Disk Drives (Zip Drive)
• Capacities greater than 100 MB
• Many uses
• Graphics, audio, or video
• Transporting files
• Backups
• Zip drive

39
WHAT IS STORAGE?

• Hard Disks
• Provide large storage capacity and high speed
  data access
• Sizes range from 2 GB to 12 GB
• Consists of several inflexible, circular disks,
  called platters
• Magnetic storage device
• Formatting

Click to see Figure 4-47
40
WHAT IS STORAGE?

• Compact Discs
• Used to distribute software
• Compact disc (CD)
• Laser reads pits on the surface
• Used on multimedia computers
• Several types
• CD-ROM
• DVD-ROM

41
WHAT IS STORAGE?

• CD-ROM
• Compact disc read-only memory
• Can contain text, graphics, video, as well as
  sound
• Can hold 650 MB of data
• Used for todays complex software

42
WHAT IS STORAGE?

• DVD-ROM
• Digital video disc read-only memory
• Can store from 4.7 GB to 17 GB
• High quality
• DVD-ROM drives
• May replace CDs, VCRs, and VHS tapes

43
DATA REPRESENTATION
Go Back
44
DATA REPRESENTATION
Go Back
45
DATA REPRESENTATION
Go Back
46
THE COMPONENTS OF THE SYSTEM UNIT
Go Back
47
CPU AND MICROPROCESSOR
Go Back
48
CPU AND MICROPROCESSOR
Go Back
49
CPU AND MICROPROCESSOR
Go Back
50
WHAT ARE INPUT DEVICES?
Go Back
51
WHAT ARE INPUT DEVICES?
Go Back
52
WHAT ARE OUTPUT DEVICES?
Go Back
53
WHAT ARE OUTPUT DEVICES?
Pixel
Go Back
54
WHAT ARE OUTPUT DEVICES?
Go Back
55
WHAT ARE OUTPUT DEVICES?
Go Back
56
WHAT ARE OUTPUT DEVICES?
Go Back
57
WHAT IS STORAGE?
Go Back
58
WHAT IS STORAGE?
Go Back
59
WHAT IS STORAGE?
Go Back
60
WHAT IS STORAGE?
Go Back
61
WHAT IS STORAGE?
Go Back
