The following MATLAB program, MAT33.m is used to
design a 33-coefficient FIR bandpass filter.
MAT33.M FIR BANDPASS WITH 33 COEFFICIENTS USING
MATLAB Fs10 kHz nu0 0.1 0.15 0.25 0.3 1)
normalized frequencies mag0 0 1 1 0
0 magnitude at normalized frequencies cremez(
32,nu,mag) invoke remez algorithm for 33
coeff bp33c coeff values transposed save
matbp33.cof bp33 -ascii save in ASCII file
with coefficients h,wfreqz(c,l,256)
frequency response with 256 points plot(5000nu
,mag,W/pi,abS(h)) plot ideal magnitude response
3
The bandpass filter is represented with 3 bands

• The first band (stopband) has normalized
  frequencies between 0 and 0.1 (0-500 Hz), with
  corresponding magnitude of 0.
• The second band (passband) has normalized
  frequencies between 0.15 and 0.25 (750-1,250 Hz),
  with corresponding magnitude of 1.
• The third band (stopband) has normalized
  frequencies between 0.3 and the Nyquist frequency
  of 1 (1500-5000 Hz), with corresponding
  magnitude of 0.

4
The magnitude response of the ideal desired
filter
5

• Note that the frequencies 750 and 1250 Hz
  represent the passband frequencies with
  normalized frequencies of 0.15 and 0.25,
  respectively, and associated magnitudes of 1.
• The frequencies 500 and 1500 Hz represent the
  stopband frequencies with normalized frequencies
  of 0.1 and 0.3, respectively, and associated
  magnitudes of 0.

6

• The instructions,
• cremez(32,nu,mag)
• and
• save a\matbp33.cof bp33 -ascii ,
• create a file of coefficients for the FIR
  filter.
• Note for the FIR filter, the coefficients repeat
  themselves.
• That is, the first 16 coefficients match the last
  16 coefficients.
• Thus, if you folded, the coefficients in the
  middle the coefficients would fold onto their
  corresponding coefficient.

7
(No Transcript)
8

• To have a more realistic simulation, a composite
  signal may be created and filtered in MATLAB.
• Consider a composite signal consisting of three
  sinusoids created by the following MATLAB code

9
Fs10e3 Ts1/Fs Ns512 t 0TsTs(Ns-1) f1
1000 f22500 f33000 x1sin(2pif1t) x2sin(
2pif2t) x3sin(2pif3t) xx1x2x3 plot(t,
x), grid
3 frequencies
composite
10
xx1x2x3
11

• The signal frequency content can be plotted by
  using the MATLAB fft function.

12
One-dimensional fast Fourier transform
Syntax y fft(x) y fft(x,n)
13
Description
fft computes the discrete Fourier transform of a
vector or matrix. This function implements the
transform given by where WN e-j(2/N) and N
length(x). Note that the series is indexed as n
1 and k 1 instead of the usual n and k because
MATLAB vectors run from 1 to N instead of from 0
to N-1.
14
Example
A common use of the Fourier transform is to find
the frequency components of a time-domain signal
buried in noise. Consider data sampled at 1000
Hz. Form a signal consisting of 50 Hz and 120 Hz
sinusoids and corrupt the signal with zero-mean
random noise
t 00.0010.6 x sin(2pi50t)
sin(2pi120t) y x 2randn(1,length(t))
plot(y(150))
15
(No Transcript)
16
It is difficult to identify the frequency
components by studying the original signal.
Convert to the frequency domain by taking the
discrete Fourier transform of the noisy signal y
using a 512-point fast Fourier transform (FFT)
Y fft(y,512)
17
Graph the first 256 points (the other 256 points
are symmetric) on a meaningful frequency axis
f 1000(0255)/512 plot(f,Pyy(1256))
18
(No Transcript)
19
Sometimes it is useful to normalize the output of
fft so that a unit sinusoid in the time domain
corresponds to unit amplitude in the frequency
domain. To produce a normalized discrete-time
Fourier transform in this manner, use Pn
abs(fft(x))2/length(x)
20
Back to our lab

• Three spikes should be observed at 1000 Hz, 2500
  Hz, and 3000 Hz.
• The frequency leakage observed on the plot is due
  to windowing caused by the finite observation
  period.

21
The Program
X(abs(fft(x,Ns))) yX(1length(X)/2) f(11len
gth(y)) plot(fFs/Ns,y) grid on
22
(No Transcript)
23

• A bandpass filter is designed to filter out all
  frequencies less than 750 Hz and greater than
  1250 Hz.
• We use the following code to verify that the FIR
  filter is actually able to filter the 2.5 kHz and
  3 kHz signals.

24
nu0 0.1 0.15 0.25 0.3 1 normalized
frequencies mag0 0 1 1 0 0 magnitude at
normalized frequencies cremez(32,nu,mag) invok
e remez algorithm for 33 coeff a1 freqz(c,a)
grid on subplot(3,1,1) va_fft(x,1024,10000) sub
plot(3,1,2) grid on h,wfreqz(c,1,256) freq
uency response with 256 points plot(w/(2pi),10lo
g(abs(h))) subplot(3,1,3) grid
on yfilter(c,a,x) va_fft(y,1024,10000)
25
(No Transcript)
26
The following MATLAB code allows one to visually
inspect the filtering.
n128 subplot(2,1,1) plot(t(1n),x(1n)) grid
on xlabel('time(s)') ylabel('Amplitude') title(
'Original and Filtered Signal') subplot(2,1,2) g
rid on plot(t(1n),y(1n)) grid
on xlabel('times(s)') ylabel('Amplitude')
27
(No Transcript)
28

• Looking at the plots, we see that the filter is
  able to remove the desired frequency components
  of the composite signal.
• Observe that the time response has an initial
  setup time causing a few data samples to be
  inaccurate.
