LE Series

1
(No Transcript)
2
V8 Series

• Cast Iron Sectional Assembly
• Components
• Burner
• Positioning

3
Cast Iron Heat Exchanger

• New Front Section
• New Intermediate
• New Rear Section
• Optimized for Steam
• Other Improvements

4
New Front Section

• Set up for 1 piece swing door
• Wider waterways
• Wider water leg

5
Intermediate Section

• Wider water leg
• Upgraded cast iron fins
• Wider crown sheet
• More radius in water leg
• Redesigned flue openings

6
Rear Section

• Tapping for indirect on steam

7
Optimized for Steam

• More water volume
• Larger crown sheet
• Fired at lower firing rate

8
Other Improvements

• Iron thickness
• Steel nipples on bottom nipple ports
• Redesigned flue openings

9
Components

• Jacket
• Swing Door
• Hardware

10
Jacket

• New Design
• New attachment method
• Threaded knobs for access without tools
• Lift-off side panel
• Easy twist-off knobs

11
Swing Door

• Full size burner swing door
• Swing door retention shelf
• Double pivoting hinge
• Inspection port
• Alignment stud added to door closure

12
Swing Door

• Opens 100 Degrees

13
Inspection Port

• Cast Iron Inspection Port Cover

14
Hardware

• Knobs on side panel

15
Cleanout Plates

• New design for cleanout cover plates

16
Side Outlet Boiler Drain

• Exits 90 degrees from burner

17
Coils

• 222 and V1

18
Controls

• L8148A used without tankless
• L8124C used with tankless
• L4006A on steam

19
Burner

• Cover
• Carlin Control
• PSC motor
• Solenoid valve
• Additional Components

20
Cover

• Noise reduction

21
Cover

• Easy removal
• Now with access to the reset button

22
Cover

• Fresh air kit

23
Carlin Control

• Carlin 60200
• Proven reliability
• Standard features

24
Burner Motor

• PSC burner motor from Beckett
• Permanent Split Capacitor

25
Solenoid Valve

• France 14000 volt igniter

26
Additional Components

• Extended tube - 7
• M head - V1/L1 tube

27
Positioning

• Ratings
• Water and Steam

28
Ratings
29
Water

• Two firing rates for V83 - V86
• AFUE goes up
• Lower rate meets ENERGY STAR - 86
• Heating capacities are very similar or
  identical to the V7

30
Steam

• Fired only at lower rate
• V83 - V86 meet ENERGY STAR - 85

31
