1PULMONARY EMBOLISM

1
All you wanted to know about Pulmonary embolus
but were Afraid to Ask
Dennis Bowie
2
OBJECTIVES

• To synthesize information from a of sources
• To stimulate interest
• Learn about diagnosis and Treatment of Pulmonary
  Embolism
• Use probabilities to solve problem
• Tell you what you must know, Should know, could
  know

3
Case I Mrs. P.E.

• 72 yr. Old female
• CC SOB Weakness
• 4-5 days ago noted weakness sudden onset of
  SOB Aggrevated by exertion lying flat

4
Case I Mrs. P.E.

• Noted increased swelling of legs
• unable to ambulate because of weakness and
  dizzyness
• No cough, fever or chest pain

5
Case I Mrs. P.E.

• Past Hx Hypertension Osteoarthritis
  Goitre on a diuretic Total Hip
  repair 2.5 wks. ago
• O/E Pulse 104 irregular irreg. RR 22,
  B.P. 116/ 60 Temp. 38.1

6
Case I Mrs. P.E.

• ? Peripheral cyanosis
• coarse crackles L anterior chest
• breath sounds both bases
• JVP 6 cm. With inspiration
• ?S4, Increased P2
• Liver increased 19 cm

7
Case I Mrs. P.E.

• ABGs pH 7.48 PaO2 52 PaCO2 29
• ECG S1 Q3 T3non specific Twave ST changes
• Chest X-ray decrease lung volumes with some
  atelectasis at bases

8
A WORD OF ADVICE FROM A FELLOW-ANGEL
9
PULMONARY EMBOLISM

• 30 Mortality for untreated Pulmonary embolism
• 50,000 - 100,000 individuals die prematurely per
  year in U.S.
• Diagnosis crosses most Specialties

10
DIAGNOSIS

• Based on
• Relevant SYMPTOMS SIGNS
• Associated RISK FACTORS
• Probability of ALTERNATIVE Diagnosis
• OBJECTIVE Confirmation

11
PULMONARY EMBOLISM

• What are the risk factors for pulmonary embolism
  and or DVT

12
Risk factors in those with Acute DVT / PE

• Obesity
  37.8
• Hx venous thromboembolism 26.0
• Cancer
  22.3
• Bed rest gt 5 days
  12.0
• Major Surgery
  11.2

• Risk factor n 1231

• Age gt 40 years
  88.5

Anderson FA et. Al J Vasc Surg 1992
13
Risk factors in those with Acute DVT / PE

• Risk factor n 1231
• CHF
  8.2
• Varicose veins 5.8
• Fracture hip or leg 3.7
• Estrogen 2.0
• Stroke
  1.8

Anderson FA et. Al J Vasc Surg 1992
14
Risk factors in those with Acute DVT / PE

• Multiple trauma 1.1
• childbirth
  1.1
• Myocardial infarction 0.7
• one or more risk factors 96.3
• two or more risk factors 76.0
• Three or more risk factors 39.0

Anderson FA et. Al J Vasc Surg 1992
15
PULMONARY EMBOLISM

• 90 of clinically important PE results from leg
  DVT
• 96 of patients with DVT or PE have one or more
  risk factors
• The risk increases in proportion to the of risk
  factors

16
Proportion of patients clinically suspected DVT
in whom Dx. Was confirmed increases with the of
risk factors

• of DVT risk factors Confirmed DVT()
• 0
  11
• 1
  24
• 2
  36
• 3
  50
• 4 or more 100

Arch Surg 1982
17
RISK FACTORS (uncommon)

• Deficiencies Protein C or S Antithrombin
  III deficiency
• Resistance to protein C activating
• Factor V Leiden polymorphism
• Homocystinuria
• Polycythemia rubra vera
• SLE, Béchets, nephrotic syn.

18
PULMONARY EMBOLISM

• What are the SYMPTOMS and SIGNS of Pulmonary
  embolism?

19
PULMONARY EMBOLISM SYMPTOMS

• Chest Pain 88 - pleuritic
  74 -non pleuritic 14
• Dyspnea 85

20
PULMONARY EMBOLISM SYMPTOMS

• Apprehension 59
• Cough 53
• Hemoptysis 30
• Syncope 13

21
PULMONARY EMBOLISM SIGNS

• Tachypnea 92
• Crackles 58
• Tachycardia 44
• Fever 43
• Increased P2 53
• Phlebitis 32

22
FREQUENCY of SX. Signs

• Proven PE
• Dyspnea 73
• Pleuritic pain 66
• Cough 37
• Leg pain 26
• Hemoptysis 13

No PE
72
59
36
24
8
23
FREQUENCY of SX. Signs
No PE
Proven PE
68

• Tachypnea 70
• Tachycardia 35
• Temperature gt 38.5 7
• Signs DVT 11
• A-a difference 86

24
12
11
78
24
ECG FINDINGS

• Sinus Tachycardia 43
• T wave inversion 40
• ST segment depression 33
• Low voltage 16
• L axis 12
• S1 Q3 T3 11
• ST elevation 11
• R Bundle Branch Block 11


25
X-RAY FINDINGS

• Diaphragm elevation 41
• Consolidation 40
• Pleural effusion 28
• Distended prox. Pulm art. 23
• Atelectasis 20
• Oligemia 15

26
Diagnosis P.E. predictive score

• Clin. Symptoms of DVT 3.0
• No alternative diagnosis 3.0
• Heart rate gt 100 1.5
• immob. Or Surg. In lt 4 wks 1.5
• Previous DVT/ PE 1.5
• Hemoptysis 1.0
• Malignancy 1.0

Wells, Anderson, Rodger, Ginsberg,
Kearon,Gent,Turpie Bormanis, WeitzChamberlain,Bowi
e,Barnes,Hirsh Thromb.Haemost. 2000 416
27
Diagnosis P.E. predictive score

• Low probability lt 2.0Moderate Prob. 2 -
  6High gt 6
• Patients with lt 4 had 7.8 incid. PE
• lt 4 and a negative D dimer 1.7 - 2.2 This
  combination was in 46 of population studied.

Wells, Anderson, Rodger, Ginsberg,
Kearon,Gent,Turpie, Bormanis, Weitz,
Chamberlain, Bowie,Barnes,Hirsh Derivation of a
simple clinical model to categorize patients
probability of pulmonary embolism increasing the
models utility with the SimpliRED D-dimer
Thromb.Haemost. 2000 416
28
Geneva Score
29
Geneva Score
30
DIAGNOSIS

• Based on
• Relevant SYMPTOMS SIGNS
• Associated RISK FACTORS
• Probability of ALTERNATIVE Diagnosis
• OBJECTIVE Confirmation

31
DIFFERENTIAL DIAGNOSIS

• CHF
• Asthma / COPD exacerbation
• Pneumothorax
• Pneumonia
• Shock
• Pleural disease
• Chest wall Pain

32
DIFFERENTIAL DIAGNOSIS

• Myocardial infarction
• Pericarditis
• 1 or metastatic ca.
• Hyperventilation syndrome
• Infradiaphragmatic processe.g. cholecystitis,
  splenic infarction

33
Diagnosis Pulmonary Embolism

• How do you confirm the diagnosis?

34
Diagnosis Objective Confirmation

• Documentation of clot in the leg by Compression
  Ultrasound or Impedance Platysmography or
  Intravenous Venogram
• 1st Test Compr. Ultrasound

35
Diagnosis Objective Confirmation

• Since the treatment for DVT and PE is the same,
  the demonstration of clot in the leg is
  sufficient for the diagnosis of Pulmonary
  Embolism

36
Diagnosis Objective Confirmation

• Pulmonary Angiogram(GOLD STANDARD)
• expensive
• Technically more difficult requiring skilled
  personnel
• More risk for side effects
• Not always available

37
VENTILATION / PERFUSION SCANS

• Normal lung scan means
• no perfusion defects
• the perfusion matches the ventilation scan

38
VENTILATION / PERFUSION SCANS

• High Probability lung scan
• gt 1 lung segmental or greater perfusion defects
  with normal ventilation
• or gt 2 large subsegmental defects (gt75 of a
  segment) with normal ventilation

39
CAUSES OF ABNORMAL V/Q SCANS

• INTRALUMINAL
• Clots
• Fat emboli
• Tumor
• Vasculitis or vascular stenosis
• Parasites
• Fungi

40
CAUSES OF ABNORMAL V/Q SCANS

• EXTRA LUMINAL
• Tumor
• Adenopathy
• Vascular structures
• REGIONAL HYPOXIC VASOCONSTRICTION
• Reactive airways
• Mucous plugs or Foreign body
• VASCULAR RESISTANCE
• CHF
• Pneumonia

41
VENTILATION / PERFUSION SCANS

• Non-High Probability
• Ventilation -perfusion defects that did not
  qualify as high or normal

42
DIAGNOSTIC PROCESS
No Treatment
Treatment
Test threshold
Treatment threshold
43
GENERAL RULES

• CONSIDER WITH EACH PATIENT
• Risk OF MISSING Diagnosis
• Risk OF PROCEDURE or COST
• Risk OF TREATMENT

44
DIFFERENTIAL DIAGNOSIS

• CHF
• Asthma / COPD exacerbation
• Pneumothorax
• Pneumonia
• Shock
• Pleural disease
• Chest Pain

45

46

47

48

49
D-dimer

• A degradation product of of crosslinked fibrin
• High number of conditions that activate
  coagulation fibrinolysis e.g. Surgury,
  inflammation, cancertrauma.
• Has a high negative predictive value R/O PE in
  low clinical probability

50
(No Transcript)
51
or V/Q scan
Angiogram
52
Data to define Test Treatment Thresholds

• Mortality Untreated 30
  Treated 8
• Angiography Sensitivity 90
  Specificity 95
  Mortality 0.5
  Morbidity 3
• Anticoagulent Mortality 1.4
  Morbidity 16

53
Role of Spiral CT Scan

• Easily done non invasive test with few
  complications
• Requires proper equipment and experienced readers
• Rarely cannot perform e.g. allergy, SVC syn.
  Renal insufficiency, Approximately 10-13
• Sensitivity 90, specificity 95, with
• multidetector CT in experienced hands

54
Perfusion/Ventilation Lung Scanning (V/Q scan)

• There are 3 V/Q lung scan patterns
• 1. A normal perfusion scan rules out PE.
• 2. Most patients with a high probability
  scan (defined as one or more, segmental or
  larger, perfusion defects with relatively
  preserved ventilation) have PE and they can
  generally be treated without further testing.

55
Perfusion/Ventilation Lung Scanning (V/Q scan)

• There are 3 V/Q lung scan patterns
• 3. All other lung scan patterns (which,
  unfortunately, includes 60 of all the scans) are
  nondiagnostic. These nondiagnostic patterns
  include
• low probability, non high probability,
  intermediate probability, and
• indeterminate probability,
• Further testing is required in patients with this
  V/Q scan pattern.

56
Advantages of V/Q Lung Scans include

• 1. a normal V/Q scan rules out PE
• 2. the radiation dose is low
• 3. iodine-based contrast is not used

57
Limitations of V/Q Lung Scans include

• 1. the majority of V/Q scans are nondiagnostic
• 2. V/Q scans do not help to identify an
  alternate diagnosis in the large proportion of
  patients who dont have PE.
• 3. high cost

58
Spiral/Helical CT (SCT)

• There are 3 SCT patterns
• 1. No PE seen and an alternate diagnosis is
  found. This group does not require any further
  investigation for VTE.
• 2. Definite PE is detected in a segmental
  or larger pulmonary artery.
• 3. Patients with normal SCT, technically
  inadequate scans, and scans that report
  subsegmental PE are all considered
  nondiagnostic. Further testing is required in
  patients with these SCT patterns.

59
Advantages of SCT include

• 1.ability to directly visualize emboli
• 2.high accuracy for large emboli (segmental or
  larger)
• 3.potential to provide the alternate diagnosis
  in patients who dont have PE

60
Limitations of SCT include

• 1.Filling defects confined to subsegmental
  vessels are not diagnostic
• 2.Contrast must be given (problematic in
  patients with renal insufficiency or a history of
  contrast allergy)
• 3.A normal SCT does not rule-out small PE
• 4.Significant radiation (equivalent to 500 chest
  x-rays)

61
Venous Imaging in Suspected PE

• Since almost all pulmonary emboli arise from DVT,
  a useful strategy in some patients with suspected
  PE is to look for the presence of DVT using
  Duplex ultrasound (DUS).
• If the DUS of the proximal veins is positive, the
  patient requires treatment (the treatment of
  proximal DVT and PE is the same).
• If the DUS is negative, the risk of recurrent PE
  in the short term is very low.
• Repeating the DUS testing in 5-7 days and 12-14
  days is a safe strategy in suspected PE with
  nondiagnostic lung imaging.

62
1.Should I start with lung imaging (V/Q scan,
SCT) or with DUS?

• Start with Lung Imaging
• 1.No leg symptoms
• 2.Lung test likely to be normal
• 3.Lung test likely to be positive

• Start with DUS
• 1. Leg symptoms /signs compatible with DVT
• 2.Recent leg injury/surgery
• 3.Pregnancy

63
2. If I start with lung imaging, should it be a
P/V scan or spiral CT?

• Choose V/P Scan
• 1.Normal CXR
• 2.Patient is otherwise healthy
• 3.SCT is contraindicated(because of contrast
  allergy or renal failure)

• Choose SCT
• 1.Abnormal CXR
• 2.Respiratory disease
• 3.Critical care patient
• 4.Suspect massive PE

64
TREATMENT of PULMONARY EMBOLISM

• Both Pulmonary embolism and DVT are treated the
  same
• An adequate level of anticoagulation is
  essentional
• Patients will have variable effect of
  anticoagulents
• Treatment requires monitoring

65
TREATMENT of PULMONARY EMBOLISM

• Bolus of 5-10,000 units of (unfractionated)
  HEPARIN maintenance dose with heparin nomogram
• Low Molecular Weight Heparin if patient is
  hemodynamically stable

66
Heparin Nomogram
67
Treatment of Pulm. Embolism

• Various manufacturers of PTT testing reagents
  and lots from same company may have different
  therapeutic ranges

68
TREATMENT of PULMONARY EMBOLISM

• Start oral anticoagulants in 24 -72 hrs. with ? 5
  day crossover with heparin
• Duration - 3 - 6 months if correctable cause
  e.g. surgery - indefinitely if no known cause
  or recurrent or ongoing risk e.g cancer

69
TREATMENT of PULMONARY EMBOLISM

• Side effects of heparin
• abnormal bleeding especially if predisposed e.g.
  peptic ulcer disease
• Heparin induced trombocytopenia which is
  associated with increased clotting

70
TREATMENT of PULMONARY EMBOLISM

• Low Molecular Weight Heparin
• increased half life
• Increased bioavailability
• low frequency of bleeding
• administered once a day
• less monitoring
• More Expensive

71
TREATMENT of PULMONARY EMBOLISM

• THROMBOLYTIC THERAPY
• More rapid in effect
• Indicated in patients hemodynamically compromised
• No evidence to date it improves clinical outcomes
• increased bleeding.

72
Case I Mrs. P.E.

• 72 yr. Old female
• CC SOB Weakness
• 4-5 days ago noted weakness sudden onset of
  SOB Aggrevated by exertion lying flat

73
Case I Mrs. P.E.

• Noted increased swelling of legs
• unable to ambulate because of weakness and
  dizzyness
• No cough, fever or chest pain

74
Case I Mrs. P.E.

• Past Hx Hypertension Osteoarthritis
  Goitre on a diuretic Total Hip
  repair 4 wks. ago
• O/E Pulse 104 irregular irreg. RR 22,
  B.P. 116/ 60 Temp. 38.1

75
Case I Mrs. P.E.

• ? Peripheral cyanosis
• coarse crackles L anterior chest
• breath sounds both bases
• JVP 6 cm. With inspiration
• ?S4, Increased P2
• Liver increased 19 cm

76
Case I Mrs. P.E.

• ABGs pH 7.48 PaO2 52 PaCO2 29
• ECG S1 Q3 T3non specific Twave ST changes
• Chest X-ray decrease lung volumes with some
  atelectasis at bases

77
Summary Approach to P.E.

• Asses pretest probability based on
• 1. RISK factors
• 2. Symptoms and signs (SOB, Chest Pain,
  syncope)
• 3. ECG and X-RAY Findings
• 4. Likelihood of ALTERNATIVE Dx. Consider
  WELLs criterion

78
Summary Approach to P.E.

• CONFIRM DIAGNOSIS by
• Demonstration of DVT by US, Venogram
• High probability V/Q scan / CT scan
• Angiogram
• Treatment as untreated Mortality 30
• Heparin Regular or LMW heparin.

79
Pulmonary Embolism

• Thrombosis Interest Group
• of Canada

http//www.tigc.org/english.htm
80

• Thats all folks

Remember Everyone is entitled to MY OPINION
BONNE JOURNEE
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
Pulmonary Embolism visuals

• Dennis Bowie

85
P.E. atelectasis
86
P.E. effusion
87
P.E. Hamptons Hump
88
P.E. subsegmental defect
89
Normal V/Q Scan
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of P.
E. Virtual Hospitalhttp//www.vh.org/Providers
90
High Probability V/Q Scan
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of
P. E. Virtual Hospital http//www.vh.org /Provid
ers
91
Pulm. Embolism CT
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of P.
E. Virtual Hospitalhttp//www.vh.org/Providers
92
Pulm. Embolism CT
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of P.
E. Virtual Hospital http//www.vh.org/Providers
93
Pulmonary Arteriogram
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of P.
E. Virtual Hospital http//www.vh.org/Providers
94
Pulmonary embolism
J. Galvin, M.D. J.Choi, B.S. The Diagnosis of P.
E. Virtual Hospitalhttp//www.vh.org/Providers
95
OKAY EVERYBODY. TEA-TIME!!!
96
Wells Score
97
Diagnosis P.E.

• Dyspnea, Chest Pain, Fainting
• R.V. overload on ECG S1Q3,S1S2S3 ,T wave
  inversion R leadsTransient RBBB,
  Pseudoinfarction
• Chest X-ray changes, Oligemia, Prominent R hilar
  artery, Peripheral consolidation1 symptom plus
  1 other sign Found in 81 with PE 7 without

M. Miniati et al. Accuracy of Clinical assessment
in the diagnosis of Pulmonary Embolism Am. J.
Respir. Crit. Care Med. 159 864
98
TYPICAL CLINICAL SIGNS AND SYMPTOMS

• SOB, CHEST PAIN, HEMOPTYSIS
• Pleural Rub, Signs Sx. Of DVT
• Typical X-ray
• SpO2 lt 92, HRgt 90 Temp 37.8 - 38.6 C0
• No other Diagnosis for X-ray

99
ATYPICAL SIGNS/SYMPTOMS

• Does not have the typical signs/symptoms except
  SOB
• Confusion without B.P.
• New tachyarrhythmias
• New wheezing
• LVF

100
SEVERE SIGNS/SYMPTOMS

• Typical symptoms / signs
• Syncope
• B.P. lt 90, H.R. gt 100
• Resp. failure, intubated, SpO2 lt 92 on gt 40
  FiO2
• New R heart failureS1 Q3 T3, RBBB

101
PRE TEST LIKELIHOOD OF PE
102
The weather will get better
BONNE JOURNEE
103
Symptoms Signsof Pulmonary Embolism in 2110
patients
of patients
Goldhaber SZ et al. Lancet 3531386
1999
