The Evolution of ESnet Joint Techs Summary

1
The Evolution of ESnetJoint Techs Summary

• William E. Johnston ESnet Manager and Senior
  Scientist
• Lawrence Berkeley National Laboratory
• (wej_at_es.net, www.es.net)

2
What Does ESnet Provide?

• The purpose of ESnet is to support the science
  missions of the Department of EnergysOffice of
  Science, as well as other parts of DOE (mostly
  NNSA). To this end ESnet provides
• Comprehensive physical and logical connectivity
• High bandwidth access to DOE sites and DOEs
  primary science collaborators the Research and
  Education institutions in the US, Europe, Asia
  Pacific, and elsewhere
• Full access to the global Internet for DOE Labs
  (160,000 routes from 180 peers at 40 peering
  points)
• An architecture designed to move huge amounts of
  data between a small number of sites that are
  scattered all over the world
• Full ISP services

3
ESnet Provides High-Speed Internet Connectivity
toDOE Facilities and Collaborators, Summer 2005
ESnet Science Data Network (SDN) core
SEA HUB
ESnet IP core
CHI-SL HUB
QWEST ATM
MAE-E
SNV HUB
Equinix
PAIX-PA Equinix, etc.
DC HUB
42 end user sites
Office Of Science Sponsored (22)
NNSA Sponsored (12)
International (high speed) 10 Gb/s SDN core 10G/s
IP core 2.5 Gb/s IP core MAN rings ( 10
G/s) OC12 ATM (622 Mb/s) OC12 / GigEthernet OC3
(155 Mb/s) 45 Mb/s and less
Joint Sponsored (3)
Other Sponsored (NSF LIGO, NOAA)
ESnet IP core Packet over SONET Optical Ring and
Hubs
Laboratory Sponsored (6)
commercial and RE peering points

SND core hubs
IP core hubs
SNV HUB
high-speed peering points with Internet2/Abilene
4
DOE Office of Science Drivers for Networking

• The large-scale science that is the mission of
  the Office of Science is dependent on networks
  for
• Sharing of massive amounts of data
• Supporting thousands of collaborators world-wide
• Distributed data processing
• Distributed simulation, visualization, and
  computational steering
• Distributed data management
• These issues were explored in two Office of
  Science workshops that formulated networking
  requirements to meet the needs of the science
  programs (see refs.)

5
Evolving Quantitative Science Requirements for
Networks
6
Observed Drivers for the Evolution of ESnet
ESnet is Currently Transporting About 530
Terabytes/mo.and this volume is increasing
exponentially
ESnet Monthly Accepted Traffic Feb., 1990 May,
2005
TBytes/Month
7
Observed Drivers for the Evolution of ESnet
ESnet traffic has increased by 10X every 46
months, on average, since 1990
Dec., 2001
Jul., 1998
42 months
TBytes/Month
57 months
Oct., 1993
Aug., 1990
39 months
8
ESnet Science Traffic

• The top 100 ESnet flows consistently account for
  25 - 40 of ESnets monthly total traffic
  these are the result of DOEs Office of Science
  large-scale science projects
• Top 100 are 100-150 Terabytes out of about 550
  Terabytes
• The other 60-75 of the ESnet monthly traffic is
  in 6,000,000,000 flows
• As LHC (CERN high energy physics accelerator)
  data starts to move, the large science flows will
  increase a lot (200-2000 times)
• Both LHC, US tier 1 data centers are at DOE Labs
  Fermilab and Brookhaven
• All of the data from the two major LHC
  experiments CMS and Atlas will be stored at
  these centers for analysis by groups at US
  universities

9
Source and Destination of the Top 30 Flows, Feb.
2005
DOE Lab-International RE
Lab-U.S. RE (domestic)
12
SLAC (US) ? RAL (UK)
Lab-Lab (domestic)
Fermilab (US) ? WestGrid (CA)
Lab-Comm. (domestic)
10
Terabytes/Month
8
SLAC (US) ? IN2P3 (FR)
LIGO (US) ? Caltech (US)
6
SLAC (US) ? Karlsruhe (DE)
Fermilab (US) ? U. Texas, Austin (US)
SLAC (US) ? INFN CNAF (IT)
LLNL (US) ? NCAR (US)
Fermilab (US) ? Johns Hopkins
Fermilab (US) ? Karlsruhe (DE)
Fermilab (US) ? UC Davis (US)
Fermilab (US) ? SDSC (US)
Fermilab (US) ? U. Toronto (CA)
IN2P3 (FR) ? Fermilab (US)
U. Toronto (CA) ? Fermilab (US)
Fermilab (US) ? MIT (US)
LBNL (US) ? U. Wisc. (US)
4
Qwest (US) ? ESnet (US)
DOE/GTN (US) ? JLab (US)
NERSC (US) ? LBNL (US)
CERN (CH) ? Fermilab (US)
NERSC (US) ? LBNL (US)
NERSC (US) ? LBNL (US)
NERSC (US) ? LBNL (US)
BNL (US) ? LLNL (US)
NERSC (US) ? LBNL (US)
BNL (US) ? LLNL (US)
CERN (CH) ? BNL (US)
BNL (US) ? LLNL (US)
BNL (US) ? LLNL (US)
2
0
10
DOE Science Requirements for Networking

• Network bandwidth must increase substantially,
  not just in the backbone but all the way to the
  sites and the attached computing and storage
  systems
• A highly reliable network is critical for science
  when large-scale experiments depend on the
  network for success, the network must not fail
• There must be network services that can guarantee
  various forms of quality-of-service (e.g.,
  bandwidth guarantees) and provide traffic
  isolation
• A production, extremely reliable, IP network with
  Internet services must support the process of
  science

11
Strategy For The Evolution of ESnet

• A three part strategy for the evolution of ESnet
• 1) Metropolitan Area Network (MAN) rings to
  provide
• dual site connectivity for reliability
• much higher site-to-core bandwidth
• support for both production IP and circuit-based
  traffic
• 2) A Science Data Network (SDN) core for
• provisioned, guaranteed bandwidth circuits to
  support large, high-speed science data flows
• very high total bandwidth
• multiply connecting MAN rings for protection
  against hub failure
• alternate path for production IP traffic
• 3) A High-reliability IP core (e.g. the current
  ESnet core) to address
• general science requirements
• Lab operational requirements
• Backup for the SDN core
• vehicle for science services

12
Strategy For The Evolution of ESnetTwo Core
Networks and Metro. Area Rings
CERN
Asia-Pacific
GEANT (Europe)
Science Data Network Core (SDN) (NLR circuits)
Seattle
Chicago
Australia
New York
Sunnyvale
Washington, DC
IP Core (Qwest)
Atlanta
LA
Aus.
Albuquerque
San Diego
El Paso
MetropolitanArea Rings
IP core hubs
Production IP core Science Data Network
core Metropolitan Area Networks Lab
supplied International connections
SDN/NLR hubs
Primary DOE Labs
New hubs
13
First Two Steps in the Evolution of ESnet

• 1) The SF Bay Area MAN will provide to the five
  OSC Bay Area sites
• Very high speed site access 20 Gb/s
• Fully redundant site access
• 2) The first two segments of the second
  national10 Gb/s core the Science Data Network
  will be San Diego to Sunnyvale to Seattle

14
ESnet SF Bay AreaMAN Ring (Sept., 2005)
IP core to Chicago (Qwest)
SDN to Seattle (NLR)

• 2 ?s (2 X 10 Gb/s channels) in a ring
  configuration, and delivered as 10 GigEther
  circuits
• 10-50X current site bandwidth
• Dual site connection (independent east and
  west connections) to each site
• Will be used as a 10 Gb/s production IP ring
  and2 X 10 Gb/s paths (for circuit services) to
  each site
• Qwest contract signed for two lambdas 2/2005 with
  options on two more
• Project completion date is 9/2005

10 Gb/soptical channels
Joint Genome Institute
LBNL
?1 production IP
?2 SDN/circuits
NERSC
?3 future
?4 future
SF Bay Area
LLNL
SNLL
SLAC
ESnet MAN ring (Qwest circuits)
Qwest /ESnet hub
Level 3hub
DOE Ultra Science Net(research net)
ESnet hubs and sites
SDN to San Diego
NASAAmes
IP core to El Paso
15
SF Bay Area MAN Typical Site Configuration
Site LAN
0-10 Gb/sdrop-offIP traffic
site
Site
West ?1 and ?2
nx1GEor 10GEIP
ESnet
6509
SF BAMAN
1 or 2 x 10 GE (provisioned circuitsvia VLANS)
East ?1 and ?2
0-20 Gb/sVLAN traffic
0-10 Gb/spass-throughVLAN traffic
0-10 Gb/spass-throughIP traffic
24 x 1 GE line cards
4 x 10 GE line cards (using 2 ports max.
percard)
16
Evolution of ESnet Step OneSF Bay Area MAN
and West Coast SDN
CERN
Asia-Pacific
GEANT (Europe)
Science Data Network Core (SDN) (NLR circuits)
Seattle
Chicago
Australia
New York
Sunnyvale
Washington, DC
IP Core (Qwest)
Atlanta
Aus.
LA
San Diego
Albuquerque
El Paso
MetropolitanArea Rings
IP core hubs
Production IP core Science Data Network
core Metropolitan Area Networks Lab
supplied International connections
SDN/NLR hubs
Primary DOE Labs
In service by Sept., 2005 planned
New hubs
17
Evolution Next Steps

• ORNL 10G circuit to Chicago
• Chicago MAN
• IWire partnership
• Long Island MAN
• Try and achieve some diversity in NYC by
  including a hub at 60 Hudson as well as 32 AoA
• More SDN segments
• Jefferson Lab via MATP and VORTEX

18
New Network Services

• New network services are also critical for ESnet
  to meet the needs of large-scale science
• Most important new network service is dynamically
  provisioned virtual circuits that provide
• Traffic isolation
• will enable the use of high-performance,
  non-standard transport mechanisms that cannot
  co-exist with commodity TCP based transport(see,
  e.g., Tom Dunigans compendium http//www.csm.ornl
  .gov/dunigan/netperf/netlinks.html )
• Guaranteed bandwidth
• the only way that we have currently to address
  deadline scheduling e.g. where fixed amounts of
  data have to reach sites on a fixed schedule in
  order that the processing does not fall behind
  far enough so that it could never catch up very
  important for experiment data analysis

19
OSCARS Guaranteed Bandwidth Service

• Testing OSCARS Label Switched Paths (MPLS based
  virtual circuits)
• (update in the panel discussion)
• A collaboration with the other major science RE
  networks to ensure compatible services (so that
  virtual services can be set up end-to-end across
  ESnet, Abilene, and GEANT)
• code is being jointly developed with Internet2's
  Bandwidth Reservation for User Work (BRUW)
  project part of the Abilene HOPI (Hybrid
  Optical-Packet Infrastructure) project
• Close cooperation with the GEANT virtual circuit
  project(lightpaths Joint Research Activity 3
  project)

20
Federated Trust Services

• Remote, multi-institutional, identity
  authentication is critical for distributed,
  collaborative science in order to permit sharing
  computing and data resources, and other Grid
  services
• Managing cross site trust agreements among many
  organizations is crucial for authentication in
  collaborative environments
• ESnet assists in negotiating and managing the
  cross-site, cross-organization, and international
  trust relationships to provide policies that are
  tailored to collaborative science
• The form of the ESnet trust services are driven
  entirely by the requirements of the science
  community and direct input from the science
  community

21
ESnet Public Key Infrastructure

• ESnet provides Public Key Infrastructure and
  X.509 identity certificates that are the basis of
  secure, cross-site authentication of people and
  Grid systems
• These services (www.doegrids.org) provide
• Several Certification Authorities (CA) with
  different uses and policies that issue
  certificates after validating request against
  policy
• This service was the basis of the first routine
  sharing of HEP computing resources between US and
  Europe

22
ESnet Public Key Infrastructure

• Root CA is kept off-line in a vault
• Subordinate CAs are kept in locked, alarmed racks
  in an access controlled machine room and have
  dedicated firewalls
• CAs with different policies as required by the
  science community
• DOEGrids CA has a policy tailored to accommodate
  international science collaboration
• NERSC CA policy integrates CA and certificate
  issuance with NIM (NERSC user accounts management
  services)
• FusionGrid CA supports the FusionGrid roaming
  authentication and authorization services,
  providing complete key lifecycle management

ESnet root CA
DOEGrids CA
NERSC CA
FusionGrid CA
CA
23
DOEGrids CA (one of several CAs) Usage Statistics
Report as of Jan 11,2005
FusionGRID CA certificates not included here.
24
DOEGrids CA Usage - Virtual Organization Breakdown

DOE-NSF collab.
25
North American Policy Management Authority

• The Americas Grid, Policy Management Authority
• An important step toward regularizing the
  management of trust in the international science
  community
• Driven by European requirements for a single Grid
  Certificate Authority policy representing
  scientific/research communities in the Americas
• Investigate Cross-signing and CA Hierarchies
  support for the science community
• Investigate alternative authentication services
• Peer with the other Grid Regional Policy
  Management Authorities (PMA).
• European Grid PMA www.eugridpma.org
• Asian Pacific Grid PMA www.apgridpma.org
• Started in Fall 2004 www.TAGPMA.org
• Founding members
• DOEGrids (ESnet)
• Fermi National Accelerator Laboratory
• SLAC
• TeraGrid (NSF)
• CANARIE (Canadian national RE network)

26
Federated Crypto Token Services

• Strong authentication is needed to reduce the
  risk of identity theft
• Identity theft was the mechanism of the
  successful attacks on US supercomputers in spring
  2004
• RADIUS Authentication Fabric pilot project (RAF)
• For enabling strong, cross-site authentication
• Cryptographic tokens (e.g. RSA SecurID cards) are
  effective, but every site uses a different
  approach
• ESnet has developed a federation service for
  crypto tokens (SecurID, CRYPTOCard, etc.)

27
ESnet RADIUS Authentication Fabric

• What is the RAF?
• Access to an application (e.g. system login) is
  based on authentication info. provided by the
  token and the user's home site identity
• Hierarchy of RADIUS servers that
• route authentication queries from an application
  (e.g. a login process) at one site to a One-Time
  Password (OTP) service at the users home site
• the home site can then authenticate the user
• outsourcing the routing reduces inter site
  connection management from O(n2) to O(n)
• A collection of cross site trust agreements

28
References DOE Network Related Planning
Workshops

• 1) High Performance Network Planning Workshop,
  August 2002
• http//www.doecollaboratory.org/meetings/hpnpw
• 2) DOE Science Networking Roadmap Meeting, June
  2003
• http//www.es.net/hypertext/welcome/pr/Roadmap/ind
  ex.html
• 3) DOE Workshop on Ultra High-Speed Transport
  Protocols and Network Provisioning for
  Large-Scale Science Applications, April 2003
• http//www.csm.ornl.gov/ghpn/wk2003
• 4) Science Case for Large Scale Simulation, June
  2003
• http//www.pnl.gov/scales/
• 5) Workshop on the Road Map for the
  Revitalization of High End Computing, June 2003
• http//www.cra.org/Activities/workshops/nitrd
• http//www.sc.doe.gov/ascr/20040510_hecrtf.pdf
  (public report)
• 6) ASCR Strategic Planning Workshop, July 2003
• http//www.fp-mcs.anl.gov/ascr-july03spw
• 7) Planning Workshops-Office of Science
  Data-Management Strategy, March May 2004
• http//www-conf.slac.stanford.edu/dmw2004
