Jerome Fink

1
Airmux 400

• Presented by
• Jerome Fink

2
Airmux-400 in Brief

• Airmux-400 is a point-to-point radio solution for
  combined Ethernet and TDM traffic over license
  free frequencies

TDM supported in version 2.2
3
Target Markets

• The Airmux-400 series is targeting the global
  markets of Cellular Backhaul, WiMAX and ISP
  Backhaul, Broadband Access and Private and
  Government Networks
• All these markets require higher bandwidth (TDM
  ETH) with longer range, robustness while keeping
  the best price performance

4
Cellular Backhaul Applications
Temporary Backhaul
Rural Area Deployment
Urban Area Deployment
NLOS Backhauling
Intermediate Backhaul
Access Service
Backhaul to Low ARPU Areas
Backup to Wired Backhaul
TDM supported in version 2.2
5
Cellular Backhaul Applications

• Alternative to Leased Lines
• Complementing existing networks in Rural Areas
• Remote communities locations
• Low ARPU communities
• Hard to reach locations and NLOS scenarios
• Overlay to network coverage in Urban Areas
• Enhance coverage and capacity
• Providing service to low-ARPU locations in the
  city
• Hard to reach locations Problematic trenching
  or N-LOS scenarios
• NLOS scenarios
• Addressing peak hours requirements and temporary
  events
• 3G ramp-up (More base stations More capacity per
  site Street-level locations)
• Intermediate backhaul
• Backup

6
Broadband Access

• Expand broadband data and voice to rural and
  underserved markets
• Eliminate costly rollout investments and speed
  time to market
• Telco grade Long range High capacity (x 10
  more than leased line)

TDM and collocation supported in version 2.2
7
Airmux-400 Benefits

• High bandwidth with longer range 50Mbps full
  duplex net throughput reaching up to 120km
• Combined Native TDM Native Ethernet services
  on one platform
• Competitive prices higher Ethernet TDM
  capacity for lower prices
• Applicable to nLOS, over-water deployments and
  high capacity over extended range with improved
  robustness thanks to the OFDM, MIMO and
  antenna polarization features.
• Flexible product usage ( stock reduction)
  of the single configurable ODU.
• Fast and easy deployments via installation
  and alignments tools

TDM supported in version 2.2
8
Performance
9
TDM Performance
Typical performance assuming availability of
99.99
10
Spatial Multiplexing MIMO

• MIMO Multiple Input Multiple Output
• A high rate signal is split into multiple lower
  rate streams and each stream is transmitted from
  a different transmit antenna in the same
  frequency channel.

Lower rate streams
Streams merged into one signal
High rate signal
TX
RX
11
Benefits of MIMO-OFDM

• MIMO achieves significant increases in capacity,
  range and reliability without additional
  bandwidth or transmit power
• Increased range and reliability
• The Ethernet data stream is split into two lower
  rate chains.
• These chains can be transmitted in lower rates,
  achieving longer ranges and higher reliability
• Increased capacity and improved spectral
  efficiency
• Each radio (chain) carries the full OFDM channel
  capacity
• Both radios use the same 20MHz channel
• Thus doubled capacity per the same channel
  bandwidth
• Improved availability
• The streams arrive at the receivers in different
  quality. MIMO chooses the best stream available
• Paths in poor quality are thus eliminated and
  availability increased

12
Product Elements

• ODU
• Integrated dual polarization antenna
• Connectors 2 x N type for external antennas, 1
  IDU-ODU, 1 multi p-t-p synch

• IDUE
• Ethernet support
• 19 1U
• PoE device supported
• Management
• Common NMS for Airmux-200 and Airmux-400

13
Competition
Motorola Canopy 600(previously Orthogon)150
Mbps full duplex Bands 2.5, 5.4, 5.8GHz using
MIMOApprox. price per link (list) gt 20,000
Redline AN80 45 Mbps full duplex Bands 5.4
and 5.8GHz No MIMOApprox. price per link
(list) 15,000
Exalt EX-I55 Mbps full duplex Bands 2.4,
4.9GHz, 5.x No MIMOApprox. price per link
(list)8,000
14
Roadmap
Product
Phase
New Features
Ready for GA
Airmux-400
2.1

• Service Ethernet only (50Mbps)
• Radio Multi Bands and regulations
• 5.8GHz band for FCC/IC, India (WPC) and China,
  4.9, 5.3, 5.4, 5.8, 5.9 GHz Universal

11/08
Airmux-400
2.2

• Service Ethernet TDM (16 E1/T1 ports)
• Radio Multi Bands and regulations
• 2.4, 4.9, 5.3, 5.4 GHz FCC/IC band
• 2.4, 5.3, 5.4, 5.8GHz ETSI band
• 2.3-2.5GHz Universal
• Integrated SW upgrade tool

Q2 09
Note Single configurable ODU HW for 2.3 2.5
GHz, 4.9GHz - 5.9GHz for FCC and Universal
markets by phase 2.2
15
Roadmap Future Plan
Product
Phase
New Features
Airmux-400
2.3
HSS Co Location Support Support Hot Stand-by
11 Spectrum Viewer
Airmux-400
2.4
Support asymmetric 100Mbps _at_ 20MHz channel BW
(fixed configuration Ethernet TDM (16 E1/T1
ports)
16
Airmux 400Ver 2.2

• Presented by
• Jerome Fink

17
Airmux-400 Products Catalog - IDUs
Note All IDUs supporting both Airmux-200 and
Airmux-400. For Airmux-200 the 8 and 16 E1/T1
will support up to 4E1/T1
18
Product Spec IDU (1)
19
Product Spec IDU (2)
20
Product Spec - ODU
21
Product Spec Antennas
22
