The Upper Limb

1
The Upper Limb

• Viroj Mitranonda

Department of Anatomy Faculty of Science Mahidol
University
2
Parts of the upper limb

• Shoulder or Scapular region
• Arm
• Forearm
• Hand

3
Bones

• Shoulder Scapula, Clavicle
• Arm Humerus
• Forearm Radius, Ulna
• Hand 8 carpal bones,
• 5 metacarpal bones,
• 14 phalanges
• carpal bones
• trapezium, trapezoid, capitate, hamate
• scaphoid, lunate, triquetrum, pisiform

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Superficial structures of the upper limb

• Cutaneous nerves
• Superficial veins
• Lymph vessels

8
Cutaneous nerves of the upper limb

• Shoulder
• Lateral branches of the supraclavicular
  n.(c.3,4)
• Arm
• Upper lateral cutaneous nerve of arm (axillary
  n.)
• Lower lateral cutaneous nerve of arm (radial
  n.)
• Medial cutaneous nerve of arm (medial cord)
• Posterior cutaneous nerve of arm (radial n.)
• Intercosto-brachial nerve (T.2)

9
Cutaneous nerves of the upper limb (continued)
Forearm

• Lateral cutaneous nerve of forearm (from
  musculocutaneous n.)
• Medial cutaneous nerve of forearm (from
  medial cord)
• Posterior cutaneous nerve of forearm (from
  radial n.)

10
Cutaneous nerves of the upper limb (continued)
Hand

• Lateral 3 1/2
• of the palm Cutaneous branches of the median
  n.
• of the dorsum Cutaneous branches of the radial
  n
• Medial 1 1/2
• of the palm Cutaneous branches of the ulnar
  n.
• of the dorsum Cutaneous branches of the ulnar
  n.
• Distal part of the dorsum of the lateral 3 1/2
  fingers
• Cut. br. of the median n.

11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Superficial veins of the upper limb

• Digital veins
• Dorsal venous arch
• Cephalic vein
• Basilic vein
• Median cubital vein
• Median veins of forearm
• (Median cephalic vein)
• (Median basilic vein)

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
The lymph vessels

• Accompanied the superficial veins
• The medial side
• drains to the lateral group of the axillary node
• The lateral side
• drains to the delto-pectoral node

20
(No Transcript)
21
Muscles found in the shoulder (scapular) region

• Axillary nerve
• Suprascapular nerve
• Suprascapular nerve
• Axillary nerve
• Upper and Lower subscapular nerves
• Lower subscapular nerve

• Deltoideus muscle
• Supraspinatus muscle
• Infraspinatus muscle
• Teres minor muscle
• Subscapularis muscle
• Teres major muscle

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
The rotator cuff muscles
Consists of

• Supraspinatus m.
• Infraspinatus m.
• Teres minor m.
• Subscapularis m.

26
(No Transcript)
27
(No Transcript)
28
Deltoideus muscle

• Origin Lateral 1/3 of clavicle,
• Acromion, Spine of scapula
• insertion Humerus, deltoid tuberosity
• Action Arm Flexion, medial rotation,
• Abduction, extension, lateral rotation
• nerve Axillary nerve

29
(No Transcript)
30
Supraspinatus muscle

• Origin Scapula, supraspinous fossa
• Insertion Upper facet of greater tuberosity of
  Humerus
• Action Abduction
• Nerve Suprascapular nerve

31
Infraspinatus muscle
Origin Scapula, infraspinous
fossa Insertion Middle facet of greater
tuberosity of the Humerus Action Lateral
rotation Nerve Suprascapular nerve
32
Teres minor muscle
Origin Scapula, superior 2/3 Lateral
margin Insertion Lower facet of greater
tuberosity of the Humerus Action Lateral
rotate nerve Axillary nerve
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Subscapularis muscle

• Origin Scapula, subscapular fossa
• Insertion Lesser tuberosity of the Humerus
• Action Medial rotation
• Nerve Upper and lower subscapular nerve

37
Teres major muscle

• Origin Inf. 1/3 lat. margin of scapula
• Insertion Humerus, crest of lesser tubercle
• Action Adduction,medial rotate, extension
• Nerve Lower subscapular nerve

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
The arm
Flexor muscles of the arm

• Musculocutaneous n.
• Musculocutaneous n.
• Musculocutaneous radial nn.

• Coracobrachialis m.
• Biceps brachii m.
• Brachialis m.

Extensor muscle of the arm

• Triceps brachii m.

• Radial n.

44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
Biceps brachii muscle

• Origin Short head Coracoid process
• Long head Supraglenoid tubercle
• Insertion Radial tuberosity, bicipital
  aponeurosis
• Action Supination, flexes elbow
• Nerve Musculocutaneous nerve

51
(No Transcript)
52
Coracobrachialis muscle

• Origin Coracoid process
• Insertion Humerus, middle of body,medial
• Action Flexion (flexes shoulder)
• Nerve Musculocutaneous nerve

53
(No Transcript)
54
Brachialis muscle

• Origin Humerus, ant. surface distal 1/2
• Insertion Ulna, coronoid process,
• ulnar tuberosity
• Action Flexes elbow
• Nerve Musculocutaneuos n. radial n.

55
(No Transcript)
56
Cubital fossa
Boundaries

• Base Imaginary line between the condyles
  of the humerus
• Laterally Brachioradialis muscle
• Medially Pronator teres muscle
• Apex Brachioradialis m. overlapped
  Pronator teres m.
• Roof Skin, superficial fascia veins,
  bicipital aponeurosis
• Floor Brachialis m.,Supinator m.
• Contents Tendon of Biceps brachii m. Brachial
  a. and its
• terminal branches(radial a. and
  ulnar a.) Median n., fat

57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
Triceps brachii muscle

• Origin Long headScapula, infraglenoid
  tubercle
• Lateral head Humerus, post.
  surface
• above groove for radial
  nerve
• Medial head below groove for
  radial n.
• Insertion Ulna,olecranon process
• Action Extends elbow
• Nerve Radial nerve

63
The forearm
Flexor muscles of forearm
Superficial layer

• Pronator teres muscle
• Flexor carpi radialis muscle
• Palmaris longus muscle
• Flexor carpi ulnaris muscle

Median nerve Median nerve Median nerve Ulnar
nerve
64
(No Transcript)
65
Flexor muscles of forearm (continued)
Intermediate layer

• Flexor digitorum superficialis (sublimis) muscle

Median nerve
Deep layer

• Flexor pollicis longus muscle
• Flexor digitorum profundus muscle
• Pronator quadratus muscle

Median nerve MedianUlnar nn. Median nerve
66
(No Transcript)
67
(No Transcript)
68
Pronator teres muscle

• Origin Medial epicondyle of humerus,
• Coronoid process of ulna
• Insertion Midlateral surface of radius
• Action Pronation
• Nerve Median nerve

69
Flexor carpi radialis muscle

• Origin Medial epicondyle of humerus
• Insertion Base of 2nd and 3rd metacarpal bones
• Action Flexes and abducts wrist (hand)
• Nerve Median nerve

70
Palmaris longus muscle

• Origin Medial epicondyle of humerus
• Insertion Palmar aponeurosis
• Action Flexes wrist
• Nerve Median nerve

71
Flexor carpi ulnaris muscle

• Origin Medial epicondyle of humerus,
• Upper dorsal border of ulna
• Insertion Pisiform bone
• ( base of 5th metacarpal bone)
• Action Flexes wrist, adduct wrist (hand)
• Nerve Ulnar nerve

72
(No Transcript)
73
Flexor digitorum superficialis muscle

• Origin Medial epicondyle of humerus,
• Coronoid process of ulna,
• Oblique line of radius
• Insertion Middle phalanges of medial four
  fingers
• Action Flexes middle phalanges of each
  finger,
• Flexion of MP PIP joints
• Nerve Median nerve

74
(No Transcript)
75
Flexor pollicis longus muscle

• Origin Radius, ant. surface middle 1/2
• Insertion Distal phalanx of thumb
• Action Flexes thumb
• Nerve median nerve

76
Flexor digitorum profundus muscle

• Origin Ulna, prox. 2/3 ant. and medial
  surfaces
• Insertion Bases of distal phalanges of medial
  four fingers
• Action Flexes distal phalanges of each
  finger (DIP joints)
• Flexes MP IP joints (PIP joints)
• Nerve Median and ulnar nerves
• (lateral 1/2 median nerve, medial 1/2
  ulnar nerve)

77
(No Transcript)
78
Pronator quadratus muscle

• Origin Ulna, ant. surface distal 1/4
• Insertion Radius, ant. surface distal 1/4
• Action Pronation. Holds radius to ulna
• Nerve Median nerve

79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
THE HAND
Viroj Mitranonda
Department of Anatomy Faculty of Science Mahidol
University
86
Muscles of the hand
3 Thenar muscles

• Abductor pollicis brevis m.
• Flexor pollicis brevis m.
• Opponens pollicis m.

• Median n.
• Median n.
• Median n.

• Adductor pollicis m.

• Ulnar n.

87
Muscles of the hand (continued)
3 Hypothenar muscles

• Abductor digiti minimi m.
• Flexor digiti minimi m.
• Opponens digiti minimi m.

• Ulnar n.
• Ulnar n.
• Ulnar n.

• 3 Palmar interossei mm.
• 4 Dorsal interossei mm.
• 4 Lumbricales mm.

• Ulnar n.
• Ulnar n.
• 1st and 2nd Median n.
• 3rd and 4th Ulnar n.

Palmaris brevis m.
Ulnar n.
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
(No Transcript)
107
(No Transcript)
108
(No Transcript)
109
(No Transcript)
110
(No Transcript)
111
Extensor muscles of forearm
Superficial group

• Brachioradialis m.
• Extensor carpi radialis longus m.
• Extensor carpi radialis brevis m.

Laterally
Posteriorly

• Extensor digitorum m.
• Extensor digiti minimi m.
• Extensor carpi ulnaris m.
• Anconeus m.

Radial nerve deep branch of
radial nerve
112
(No Transcript)
113
Extensor muscles of forearm (continued)
Deep group

• Supinator m.
• Abductor pollicis longus m.
• Extensor pollicis brevis m.
• Extensor pollicis longus m.
• Extensor indicis m.

Nerve supply Deep branch of radial nerve
or posterior interosseous nerve
114
(No Transcript)
115
(No Transcript)
116
Brachioradialis muscle

• Origin Humerus, lateral supracondylar line
• Insertion Radius, base of styloid process
• Action Flexes elbow
• Nerve Radial nerve

117
(No Transcript)
118
Extensor carpi radialis longus muscle

• Origin Humerus, lateral supracondylar line
• Insertion Base of second metacarpal bone
• Action Extends wrist, abduct hand
• Nerve Radial nerve

119
Extensor carpi radialis brevis muscle

• Origin Humerus, lateral epicondyle
• Insertion Base of third metacarpal bone
• Action Extends wrist, abduct hand
• Nerve Deep branch of the radial nerve

120
Extensor carpi ulnaris muscle

• Origin Lateral epicondyle of humerus,
• posterior border of ulna
• Insertion Base of fifth metacarpal bone
• Action Extends wrist, adduct hand
• Nerve Deep branch of radial nerve

121
(No Transcript)
122
Extensor digitorum muscle

• Origin Humerus, lateral epicondyle
• Insertion Middle and distal phalanges,
• extensor expansion
• Action Extends phalanges
• Nerve Deep branch of radial nerve

123
(No Transcript)
124
Extensor digiti minimi muscle

• Origin Humerus, lateral epicondyle
• Insertion Extensor expansion of fifth digit
• Action Extends fifth digit
• Nerve Deep branch of radial nerve

125
(No Transcript)
126
Anconeus muscle

• Origin Lateral epicondyle of humerus
• Insertion Proximal 1/3 lat. surface of ulna
• Action Holds ulna to radius, extends
  elbow
• Nerve Radial nerve

127
Supinator muscle

• Origin Humerus, lateral epicondyle
• Ulna, supinator crest
• Insertion Proximal 1/3 of radius
• Action Supination
• Nerve Deep branch of radial nerve

128
(No Transcript)
129
(No Transcript)
130
Abductor pollicis longus muscle

• Origin Radius and ulna distal to supinator
  m.
• Insertion Base of first metacarpal bone
• Action Abducts thumb
• Nerve Deep branch of radial nerve
• (Posterior interosseous nerve)

131
Extensor pollicis brevis muscle

• Origin Radius, posterior surface
• Insertion Base of proximal phalanx of thumb
• Action Extends thumb
• Nerve Deep branch of radial nerve
• (Posterior interosseous nerve)

132
Extensor pollicis longus muscle

• Origin Middle 1/3 post. surface of ulna
• Insertion Distal phalanx of thumb
• Action Extends thumb
• Nerve Deep branch of radial nerve
• (Posterior interosseous nerve)

133
Extensor indicis muscle

• Origin Ulna, posterior surface
• Insertion Extensor expansion
• Action Extends index
• Nerve Deep branch of radial nerve
• (Posterior interosseous nerve)

134
Out cropping muscles

• Abductor pollicis longus m.
• Extensor pollicis brevis m.
• Extensor pollicis longus m.

Bounded the anatomical snuff box
135
(No Transcript)
136
(No Transcript)
137
(No Transcript)
138
(No Transcript)
139
(No Transcript)
140
Tendon of the muscles in the fascial tunnels

• 2 Abductor pollicis longus and extensor
  pollicis brevis
• 3 Extensor carpi radialis longus and brevis
• 1 Extensor pollicis longus
• 5 Extensor digitorum and extensor indicis
• 6 Extensor digiti minimi
• 4 Extensor carpi ulnaris

141
(No Transcript)
142
Arthrology (Study of joint)
1. According to the movement
1.1 Immovable or synarthrosis eg. suture
143

• 1.2 Slightly movable or amphi(ar)throsis
• Fibrous tissue lies between the bones
  (syndesmosis) eg. Intermediate
  radio-ulnar jt.
• Cartilage joins the bones (synchondrosis) eg.
  Pubic symphysis, intervertebral disc,
  sterno-costal joint

144

• 1.3 Freely movable (diarthrosis)
• have joint cavity, joint capsule eg.
  Shoulder joint, elbow joint

145
2.According to the structures found in the joint

• 2.1. Fibrous joint
• there are fibrous tissue in the joint eg.
  Suture, radio-ulnar joint, tibio-fibular joint

• 2.2. Cartilagenous joint
• there are cartilage in the joint eg. Pubic
  symphysis, sterno-costal joint

146
2.3. Synovial joint
General patterns of synovial joint

• There are at least 2 bones
• Its articular surfaces lied with hyaline
  cartilage (articular cartilage)
• It has articular or joint capsule
• It has joint cavity
• Inner surface of the joint capsule lied with
  synovial membrane which secrete the synovial
  fluid or synovia

147
(No Transcript)
148
Classification of the synovial joint
Classified into 7 types
1. The ball and socket type

• For example shoulder joint
• Bones humerus and scapula
• Ball the head of the humerus
• Socket primary socket is the glenoid
  cavity of the scapula
  secondary socket is the coraco-acromial
  ligament

149
The ball and socket type (continue)

• Movement multiaxial - flex, extend,
  adduct,abduct and circumduct
• Joint capsule thin fibrous membrane
• Ligaments coraco-humeral, superior, middle
  and inferior gleno-humeral ligaments

150
(No Transcript)
151
(No Transcript)
152
(No Transcript)
153
(No Transcript)
154
(No Transcript)
155
(No Transcript)
156
(No Transcript)
157
(No Transcript)
158
(No Transcript)
159
(No Transcript)
160
2. Hinge type

• For example the elbow joint
• Bones humerus, ulna and radius
• Movement around horizontal axis flex and
  extend
• Joint capsule thin at the anterior and
  posterior sides thicken at medial and lateral
  sides
• Ligaments medial or ulnar collateral
  ligament lateral or radial collateral ligament

161
(No Transcript)
162
(No Transcript)
163
(No Transcript)
164
(No Transcript)
165
(No Transcript)
166
3. Pivot type

• For example proximal radio-ulnar joint
• Bones radius and ulna
• Movement around the vertical axis
  medial and lateral rotation
• Ligament annular ligament

167
(No Transcript)
168
4. Ellipsoidal type

• For example wrist or radio-carpal joint
• Bones distal end of radius, scaphoid,
  lunate and triquetrum
• Movement modified hinge type flex,
  extend, adduct and abduct
• Ligaments medial or ulnar collateral
  ligament lateral or radial collateral ligament

169
(No Transcript)
170
(No Transcript)
171
5. Plane or gliding type

• For example intercarpal joints
• Bones carpal bones
• Movement gliding
• Ligaments interosseous ligaments

172
6. Saddle type

• For example 1st carpometacarpal joint
• Bones 1st metacarpal bone and
  trapezium
• Movement flex, extend, adduct, abduct
  and circumduct

173
(No Transcript)
174
7. Condyloid type

• For example metacarpophalangeal joint
  (MP) interphalangeal joint (IP)
• Bones metacarpal bone, phalanges
• Movement flex and extend, (adduct,
  abduct)
• Ligaments medial and lateral collateral
  ligaments

175
(No Transcript)
176
Joints of the upper limb

• Sternno-clavicular joint
• Coraco-acromial joint
• Coraco-clavicular joint
• Acromio-clavicular joint
• Shoulder joint
• Elbow joint

177
Joints of the upper limb (continue)

• Radio-ulnar joints (prox.,middle and distal)
• Wrist or radio-carpal joint
• Intercarpal joints
• Carpometacarpal joints
• Intermetacarpal joints
• Metacarpophalangeal joints (MP joint)
• Interphalangeal joints (IP joint)

178
(No Transcript)
179
NERVE LESIONS OF UPPER LIMBS
BY
VIROJ MITRANONDA Department of Anatomy Faculty
of Science, Mahidol University
180
(No Transcript)
181
(No Transcript)
182
(No Transcript)
183
(No Transcript)
184
(No Transcript)
185
(No Transcript)
