Variant Indexes

1
Variant Indexes
2
Specialized Indexes?

• Data warehouses are large databases with data
  integrated from many independent sources.
• Queries are often complex.
• Updated in a batch fashion.
• Goal develop specialized indexes to speed up
  query evaluation.

3
Bitmap Indexes

• Value-list index same row may appear under many
  key values in index
• RID-list list a key value once at head, which
  is followed by a long list of RIDs for rows with
  this key value.
• Bitmap alternate form for representing
  RID-lists in a Value-list index
• Bitmaps are more space efficient than RID-lists
  when the number of key values is low (1)

4
Creating Bitmap Index

• For n rows of T r1,,rn, do 1-1 mapping from
  T to ZM, the 1st M positive integers.
• For a given row r with row j, the table page
  number accessed to retrieve row r is j/p and the
  page slot is jp.

5

• A Bitmap B is a sequence of M bits. Each row r
  with row j that has property P, we set bit j in
  B to 1, all other bits are zero.
• A Bitmap index for a column C with values v1,,vk
  is a B tree with entries having these key values
  and associated data portions that contain Bitmaps
  for the properties Cv1,,Cvk.

6

• Dense Bitmaps if the proportion of 1-bits in
  the Bitmap is large.
• A Bitmap index for a column with 32 values will
  have average density 1/32. Space needed for
  Bitmap is comparable to disk space needed for
  RID-list index, which requires 32 bits for each
  RID present.
• For a column index with a very small of values,
  the Bitmaps will have high densities and disk
  savings is enormous.

7

• Boolean operations are extremely fast.
• Can use a bunch of for loops to execute. For long
  Bitmaps, take fragments out from disk. (2)
• Loops for Bitmap AND, OR, NOT, or COUNT are
  extremely fast compared to loop operations on RID
  lists. (3)

8
Segmentation

• To optimize Bitmap index access, can be broken
  into fragments of equal sizes
• RIDs can be small bytes in length, they specify
  position in segment. At beginning, high order
  bits can be specified. (4)
• If one of predicate indexes has no pointer to a
  Bitmap Fragment for a segment, then the segment
  fragments for the other indexes can be ignored as
  well, can save a lot of I/O.

9

• Bitmap representations and RID-list
  representations are interchangeable, when Bitmap
  representations are dense, Bitmaps are much more
  efficient than RID-lists, for storage use and
  Boolean operations. When too sparse, Bitmap index
  can contain RID-list.

10
Projection Indexes

• Say C is a column of a table T then the
  Projection index on C consists of a stored
  sequence of column values from C, in order by row
  number in T from which the values are extracted.

11

• Projection index very efficient when column
  values must be retrieved from all rows of a found
  set.
• For example, say column values are 4 bytes in
  length, 1000 values will fit on a 4KB page. Say
  each row is 200 bytes, then using index requires
  1/20 I/0s of getting whole rows.

12

• Like vertical partitioning, good when small of
  columns are retrieved by most SELECT statements,
  bad when most queries retrieve most of the
  columns. (5)

13
Bit-Sliced Indexes

• A Bit-Sliced index stores a set of Bitmap
  slices which are orthogonal to the data held in
  a Projection index. Good for calculating
  aggregates in a found set.
• Each individual Bitmap Bi is called a Bit-slice
  of the column. There is one Bitmap for Bnn for
  not null and one Bitmap for Bn for null (6)

14
Comparing Indexes for Aggregate Evaluation

• SELECT SUM (dollar_sales)
• FROM SALES
• WHERE condition

15

• Say found set Bf (2 million rows) is already
  determined.
• SALES table has 100 million rows, which are each
  200 bytes in length, stored 20 rows on a 4KB disk
  page.

16
Query Plan 1

• Direct access to rows to calculate SUM
• Each disk page contains 20 rows, have 5,000,000
  disk pages occupied by SALES table (100 millon
  rows / 20 rows). Since Bf represents only 1/50
  rows of SALES table, disk pages occupies is
  5,000,000(1 e-2,000,000/5,000,000)
  1,648,4000.

17

• This means that, if one disk arm retrieves 100
  disk pages per second, you will need 4 hours of
  disk arm use! (1,648,400/100 16,484 seconds 4
  hours)

18
Query Plan 2

• Get SUM with Projection Index
• The dollar_sales Projection index has 1000 values
  per 4KB disk page. Requires 100,000 disk pages.
  This equals 1000 seconds (17 minutes)

19
Query Plan 3

• Get SUM with Value-list index on dollar_sales.
• Can calculate SUM(dollar_sales) for our Foundset
  by ranging through all possible values in the
  index and determining the rows with each value,
  the determining how many rows with each value are
  in the Foundset, and finally multiplying that
  count by the value and adding to the SUM.

20

• IF (COUNT (Bf AND Bnm) 0)
• Return null
• SUM 0.00
• For each non-null value v in index for C
• Designate set of rows with value v as Bv
• SUM v COUNT(Bf AND Bv)
• return SUM

21

• Good if entire Bitmaps are in memory.
• Value-list index evaluation of SUM ( C ) requires
  10,000 Bitmap ANDs and 10,000 COUNTS.
• Requires 103,125 I/Os and a loop of length
  100,000,000.
• Requires 1,340,640 disk pages

22
Query Plan 4

• Get SUM with Bit-Sliced index
• IF (COUNT (Bf AND Bnn) 0)
• Return null
• SUM 0.00
• For I 0 to N
• SUM 2 (i power) COUNT (Bi AND Bf)
• return SUM

23

• Perform 21 ANDs and 21 COUNTs of 100,000,000 bit
  Bitmaps. Each Bitmap is 12.5 Mbytes in length,
  requiring 3125 I/Os, but we assume that Bf can
  remain in memory. Thus need to read 22 Bitmaps
  from disk 223125 68,750 I/Os. For CPU, need
  to AND 21 pairs of Bitmaps, total of loop
  passes 21(100,000,000/32) 65,625, 000. Need
  to perform 21 COUNTs, with 131,250,000 passes.

24
Comparing Algorithm Performance METHOD
I/0 CPU contributions Add from
rows 1,342 K I/O 2M(25 ins) Projection
index 100 K I/O 2M(10 ins) Value-List
index 103 K I/O 100M(10 ins) Bit-Sliced
index 69 K I/O 197M(1 ins)
25
Aggregate Functions Index Types for
Evaluation Aggregate
Value-List Projection Bit-Sliced COUNT Not
needed Not needed Not needed SUM Not
Bad Good Best AVG (SUM/COUNT) Not
Bad Good Best MAX MIN Best Slow Slow MEDIAN,
N-TILE Best No Sometimes Column-Product Slow
Best Slow
26
Range Predicates

• Consider
• SELECT target-list FROM T
• WHERE C-range AND ltconditiongt
• Want to further restrict Foundset Bf so that the
  compound predicate C-range AND ltconditiongt
  holds. This will be represented by BF.

27
Using Projection Index

• Can create BF by accessing each C value in the
  index corresponding to a row number in BF and
  testing whether it lies within the specified
  range.

28
Value-List Index

• Br the empty set
• For each entry v in the Index for C that
  satisfies the range specified
• Designate the set of rows with the value v as
  Bv
• Br Br OR Bv
• BF Bf AND Br
• (Br needs to be in memory all times for
  efficiency)

29
Bit-Sliced Index

• The algorithm is efficient, it comprises a bunch
  of Boolean operations for each bit-slice of a
  column C.

30
Range Evaluation Performance by Index Type

• Range Evaluation Value-List Projection Bit-Sliced
• Narrow Range Best Good Good
• Wide Range Not Bad Good Best

31
Join Indexes

• A Join index is an index on one table for a
  quantity that involves a column value of a
  different table through a commonly encountered
  join.
• Join indexes can be used to avoid actual joins of
  tables, or to greatly reduce the volume of data
  that must be joined, by performing restrictions
  in advance.

32
Calculating Groupset Aggregates

• Once the Foundset has been computed from the
  Where clause, the bits in Foundset must be
  partitioned into Groupsets. Any aggregate
  functions are then evaluated separately over
  these different Groupsets.
• How to compute Groupset aggregates using our
  different index types.

33
Projection Indexes

• Assume Projection indexes exist for each of the
  group-by columns.
• For each Foundset, read appropriate Projection
  indexes. Read values of the columns to be
  aggregated from index, and aggregate the result
  into the proper cell of the memory-resident array.

34
Value-List Indexes

• Grouping by columns D1.A, D2.B using Value-List
  index
• For each entry v1 in the Value-List index for
  D1.A
• For each entry v2 in the Value-List index for
  D2.B
• Bg Bv1 AND Bv2 AND Bf
• Evaluate AGG( F.C ) on Bg

35
Conclusion

• For read-only systems, we could use more complex
  index structures to speed up queries. The Bitmap,
  Projection, and Bit-Slice indexes serve this
  purpose.
