Title: Friction


1
Friction
  • Friction Problem Situations

2
Friction
  • Friction Ff is a force that resists motion
  • Friction involves objects in contact with each
    other.
  • Friction must be overcome before motion occurs.
  • Friction is caused by the uneven surfaces of the
    touching objects. As surfaces are pressed
    together, they tend to interlock and offer
    resistance to being moved over each other.

3
Friction
  • Frictional forces are always in the direction
    that is opposite to the direction of motion or to
    the net force that produces the motion.
  • Friction acts parallel to the surfaces in
    contact.

4
Types of Friction
  • Static friction maximum frictional force
    between stationary objects.
  • Until some maximum value is reached and motion
    occurs, the frictional force is whatever force is
    necessary to prevent motion.
  • Sliding or kinetic friction frictional force
    between objects that are sliding with respect to
    one another.
  • Once enough force has been applied to the object
    to overcome static friction and get the object to
    move, the friction changes to sliding (or
    kinetic) friction.
  • Sliding (kinetic) friction is less than static
    friction.

5
Types of Friction
  • Static and sliding friction are dependent on
  • The nature of the surfaces in contact. Rough
    surfaces tend to produce more friction.
  • The normal force (Fn) pressing the surfaces
    together the greater Fn is, the more friction
    there is.

6
Types of Friction
7
Types of Friction
  • Rolling friction involves one object rolling
    over a surface or another object.
  • Fluid friction involves the movement of a fluid
    over an object (air resistance or drag in water)
    or the addition of a lubricant (oil, grease,
    etc.) to change sliding or rolling friction to
    fluid friction.

8
Coefficient of Friction
  • Coefficient of friction (?) ratio of the
    frictional force to the normal force pressing the
    surfaces together. ? has no units.
  • Static
  • Sliding (kinetic)

9
Coefficient of Friction
10
Horizontal Surface Constant Speed
  • Constant speed a O m/s2.
  • The normal force pressing the surfaces together
    is the weight Fn Fw

11
Horizontal Surface a gt O m/s2
12
Horizontal Surface a gt O m/s2
  • If solving for
  • Fx
  • Ff
  • a

13
Horizontal Surface Skidding to a Stop or
Slowing Down (a lt O m/s2)
  • The frictional force is responsible for the
    negative acceleration.
  • Generally, there is no Fx.

14
Horizontal Surface Skidding to a Stop or
Slowing Down (a lt O m/s2)
  • Most common use involves finding acceleration
    with a velocity equation and finding mk
  • Acceleration will be negative because the speed
    is decreasing.

15
Horizontal Surface Skidding to a Stop or
Slowing Down (a lt O m/s2)
  • The negative sign for acceleration a is dropped
    because mk is a ratio of forces that does not
    depend on direction.
  • Maximum stopping distance occurs when the tire is
    rotating. When this happens, a -msg.
  • Otherwise, use a -mkg to find the
    acceleration, then use a velocity equation to
    find distance, time, or speed.

16
Down an Inclined Plane
17
Down an Inclined Plane
  • Resolve Fw into Fx and Fy.
  • The angle of the incline is always equal to the
    angle between Fw and Fy.
  • Fw is always the hypotenuse of the right triangle
    formed by Fw, Fx, and Fy.

18
Down an Inclined Plane
  • The force pressing the surfaces together is NOT
    Fw, but Fy Fn Fy.
  • or

19
Down an Inclined Plane
  • For constant speed (a 0 m/s2)

20
Down an Inclined Plane
  • To determine the angle of the incline
  • If moving
  • If at rest

21
Up an Inclined Plane
22
Up an Inclined Plane
  • Resolve Fw into Fx and Fy.
  • The angle of the incline is always equal to the
    angle between Fw and Fy.
  • Fw is always the hypotenuse of the right triangle
    formed by Fw, Fx, and Fy.

23
Up an Inclined Plane
  • Fa is the force that must be applied in the
    direction of motion.
  • Fa must overcome both friction and the
    x-component of the weight.
  • The force pressing the surfaces together is Fy.

24
Up an Inclined Plane
  • For constant speed, a 0 m/s2.
  • Fa Fx Ff
  • For a gt 0 m/s2.
  • Fa Fx Ff (ma)

25
Pulling an Object on a Flat Surface
26
Pulling an Object on a Flat Surface
  • The pulling force F is resolved into Fx and Fy.

27
Pulling an Object on a Flat Surface
  • Fn is the force that the ground exerts upward on
    the mass. Fn equals the downward weight Fw minus
    the upward force Fy from the pulling force.
  • For constant speed, a 0 m/s2.

28
Simultaneous Pulling and Pushing an Object on a
Flat Surface
29
Simultaneous Pulling and Pushing an Object on a
Flat Surface
30
Pushing an Object on a Flat Surface
31
Pushing an Object on a Flat Surface
  • The pushing force F is resolved into Fx and Fy.

32
Pushing an Object on a Flat Surface
  • Fn is the force that the ground exerts upward on
    the mass. Fn equals the downward weight Fw plus
    the upward force Fy from the pushing force.
  • For constant speed, a 0 m/s2.

33
Pulling and Tension
  • The acceleration a of both masses is the same.

34
Pulling and Tension
  • For each mass
  • Isolate each mass and examine the forces acting
    on that mass.

35
Pulling and Tension
  • m1 mass
  • T1 may not be a tension, but could be an applied
    force (Fa) that causes motion.

36
Pulling and Tension
  • m2 mass

37
Pulling and Tension
  • This problem can often be solved as a system of
    equations
  • See the Solving Simultaneous Equations notes for
    instructions on how to solve this problem using a
    TI or Casio calculator.

38
Revisiting Tension and Friction
39
Revisiting Tension and Friction
  • For the mass on the table, m1
  • For the hanging mass, m2
  • The acceleration a of both masses is the same.

40
Revisiting Tension and Friction
