Edpsy 511

1
Edpsy 511

• Exploratory Data Analysis
• Homework 1 Due 9/20

2
Landmarks in the data

• Quartiles
• Were often interested in the 25th, 50th and 75th
  percentiles.
• 39, 38, 38, 36, 36, 31, 29, 29, 28, 19
• Steps
• First, order the scores from least to greatest.
• Second, Add 1 to the sample size.
• Why?
• Third, Multiply sample size by percentile to find
  location.
• Q1 (10 1) .25
• Q2 (10 1) .50
• Q3 (10 1) .75
• If the value obtained is a fraction take the
  average of the two adjacent X values.

3
Box-and-Whiskers Plots (a.k.a., Boxplots)
4
Shapes of Distributions

• Normal distribution
• Positive Skew
• Or right skewed
• Negative Skew
• Or left skewed

5
How is this variable distributed?
6
How is this variable distributed?
7
How is this variable distributed?
8
Descriptive Statistics
9
Statistics vs. Parameters

• A parameter is a characteristic of a population.
• It is a numerical or graphic way to summarize
  data obtained from the population
• A statistic is a characteristic of a sample.
• It is a numerical or graphic way to summarize
  data obtained from a sample

10
Types of Numerical Data

• There are two fundamental types of numerical
  data
• Categorical data obtained by determining the
  frequency of occurrences in each of several
  categories
• Quantitative data obtained by determining
  placement on a scale that indicates amount or
  degree

11
Techniques for Summarizing Quantitative Data

• Frequency Distributions
• Histograms
• Stem and Leaf Plots
• Distribution curves
• Averages
• Variability

12
Summary Measures
Summary Measures
Variation
Central Tendency
Quartile
Arithmetic Mean
Median
Mode
Range
Variance
Standard Deviation
13
Measures of Central Tendency
Central Tendency
Average (Mean)
Median
Mode
14
Mean (Arithmetic Mean)

• Mean (arithmetic mean) of data values
• Sample mean
• Population mean

Sample Size
Population Size
15
Mean

• The most common measure of central tendency
• Affected by extreme values (outliers)

0 1 2 3 4 5 6 7 8 9 10
0 1 2 3 4 5 6 7 8 9 10 12
14
Mean 5
Mean 6
16
Mean of Grouped Frequency
17
Weighted Mean

• A form of mean obtained from groups of data in
  which the different sizes of the groups are
  accounted for or weighted.

18
(No Transcript)
19
Median

• Robust measure of central tendency
• Not affected by extreme values
• In an Ordered array, median is the middle
  number
• If n or N is odd, median is the middle number
• If n or N is even, median is the average of the
  two middle numbers

0 1 2 3 4 5 6 7 8 9 10
0 1 2 3 4 5 6 7 8 9 10 12
14
Median 5
Median 5
20
Mode

• A measure of central tendency
• Value that occurs most often
• Not affected by extreme values
• Used for either numerical or categorical data
• There may may be no mode
• There may be several modes

0 1 2 3 4 5 6
0 1 2 3 4 5 6 7 8 9 10 11
12 13 14
No Mode
Mode 9
21
The Normal Curve
22
Different Distributions Compared
23
Variability

• Refers to the extent to which the scores on a
  quantitative variable in a distribution are
  spread out.
• The range represents the difference between the
  highest and lowest scores in a distribution.
• A five number summary reports the lowest, the
  first quartile, the median, the third quartile,
  and highest score.
• Five number summaries are often portrayed
  graphically by the use of box plots.

24
Variance

• The Variance, s2, represents the amount of
  variability of the data relative to their mean
• As shown below, the variance is the average of
  the squared deviations of the observations about
  their mean

• The Variance, s2, is the sample variance, and is
  used to estimate the actual population variance,
  s 2

25
Standard Deviation

• Considered the most useful index of variability.
• It is a single number that represents the spread
  of a distribution.
• If a distribution is normal, then the mean plus
  or minus 3 SD will encompass about 99 of all
  scores in the distribution.

26
Calculation of the Variance and Standard
Deviation of a Distribution
Raw Score Mean X X (X X)2
85 54 31 961 80 54 26 676 70 54 16 256 60 54 6 36
55 54 1 1 50 54 -4 16 45 54 -9 81 40 54 -14 196 30
54 -24 576 25 54 -29 841

404.44
Standard deviation (SD)
27
Comparing Standard Deviations
Data A
Mean 15.5 S 3.338
11 12 13 14 15 16 17 18
19 20 21
Data B
Mean 15.5 S .9258
11 12 13 14 15 16 17 18
19 20 21
Data C
Mean 15.5 S 4.57
11 12 13 14 15 16 17 18
19 20 21
28
Facts about the Normal Distribution

• 50 of all the observations fall on each side of
  the mean.
• 68 of scores fall within 1 SD of the mean in a
  normal distribution.
• 27 of the observations fall between 1 and 2 SD
  from the mean.
• 99.7 of all scores fall within 3 SD of the mean.

• This is often referred to as the 68-95-99.7 rule

29
Fifty Percent of All Scores in a Normal Curve
Fall on Each Side of the Mean
30
Probabilities Under the Normal Curve
31
Standard Scores

• Standard scores use a common scale to indicate
  how an individual compares to other individuals
  in a group.
• The simplest form of a standard score is a Z
  score.
• A Z score expresses how far a raw score is from
  the mean in standard deviation units.
• Standard scores provide a better basis for
  comparing performance on different measures than
  do raw scores.
• A Probability is a percent stated in decimal form
  and refers to the likelihood of an event
  occurring.
• T scores are z scores expressed in a different
  form (z score x 10 50).

32
Probability Areas Between the Mean and Different
Z Scores
33
Examples of Standard Scores
