Tree structure

1
Tree structure

• By Edward F. Gilman
• Department of Environmental Horticulture
• University of Florida
• http//hort.ufl.edu/woody/planting

2
Tree Structure

• Whats the Problem?

3
What is good structure?
Outline of topics

• Forest grown vs. open grown tree
• Codominant stems
• Good branch attachment
• Structurally sound tree

4
Forest grown tree
vs..
Open grown tree

• How do they develop on their own?

5
Trees in the forest grow with one trunk, and
codominant stems toward the top of the tree
6
Codominant stems form far up into the canopy on
most forest trees
7
Open grown trees

• Canopy develops low on the trunk
• Canopy spreads wide
• Tree is often wider than tall

8
Its party time for all
Its all about access to sunlight
9
(No Transcript)
10
Appears to be a nice tree
11
Close-up of base of tree
12
Huge crack
Same tree five years later
13
Fall down go boom tree
Keep an eye on this side of the tree
14
I thought I heard something creak last night
15
What is good structure?
Outline of topics

• Forest grown vs. open grown tree
• Codominant stems
• Good branch attachment
• Structurally sound tree

16
2. Codominant stems
Stems nearly same diameter
17
(No Transcript)
18
These are weak
Elephant ears
Severely acute angle
19
Why are they a problem?
Included barkbeginning to form
20
Bark inclusion
Decay and discoloration from self wounding
21
Bark inclusion
Closed crack indicating inclusion
Near-normal wood formation
22
Closure crack indicating inclusion
Bark inclusion
23
Bark inclusion (Not a codominant stem!)
24
Close-up of closure crack
25
What is good structure?
Outline of topics

• Forest grown vs. open grown tree
• Codominant stems
• Good branch attachment
• Structurally sound tree

26
3. Good branch attachment

• How does a BRANCH form?
• What are the indicators?

27
(No Transcript)
28
(No Transcript)
29
Branch bark ridge present

• Some branch unions have a prominent branch bark
  ridge

30
No branch bark ridge
Collar
31
Pine union

• Collar is visible as a swelling at the base of
  the branch
• Branch bark ridge (arrows) is visible as a dark,
  rough bark region on the top and sides of the
  union

32
Wood orientation at union

• Peel the bark from the union
• Note how trunk wood grows out onto the base of
  the branch (dotted line is edge of trunk wood)

33
Desirable branch size
34
(No Transcript)
35
Strong union
Weak union
36
What is good structure?
Outline of topics

• Forest grown vs. open grown tree
• Codominant stems
• Good branch attachment
• Structurally sound tree

37
4. Structurally sound tree

• Scaffold branches spaced vertically.
• Rule of thumb about 5 of trees ultimate
  height.
• Scaffold branches spaced radially none directly
  above another.
• Consistently maintain 60 L.C.R.

38
Good structure
39
Stems too close together
40
Pruning
Is a solution that will be discussed in another
presentation.
41
Tree structure

• By Edward F. Gilman
• Department of Environmental Horticulture
• University of Florida
• http//hort.ufl.edu/woody/planting
