LINEAR CLASSIFICATION METHODS

1
LINEAR CLASSIFICATION METHODS

• STAT 597 E
• Fengjuan Xuan
• Caimiao Wei
• Bogdan Ilie

2
Introduction

• The observations in the dataset we will work on
  (BUPA liver disorders) were sampled by BUPA
  Medical Research Ltd and consist of 7 variables
  and 345 observed vectors. The first 5 variables
  are measurements taken by blood tests that are
  thought to be sensitive to liver disorders and
  might arise from excessive alcohol consumption.
  The sixth variable is a sort of selector
  variable. The subjects are single male
  individuals. The seventh variable is a selector
  on the dataset, being used to split it into two
  sets, indicating the class identity. Among all
  the observations, there are 145 people belonging
  to the liver-disorder group (corresponding to
  selector number 2) and 200 people belonging to
  the liver-normal group.

3
Description of variables

• The description of each variable is below
• 1. mcv mean corpuscular volume
• 2. alkphos alkaline phosphotase
• 3. sgpt alamine aminotransferase
• 4. sgot aspartate aminotransferase
• 5. gammagt gamma-glutamyl transpeptidase
• 6. drinks number of half-pint equivalents of
  alcoholic beverages
• drunk per day
• 7. selector field used to split data into
  two sets. It is a binary categorical variable
  with indicators 1 and 2 ( 2 corresponding to
  liver disorder)

4
Matrix Plot of the variables
5
Logistic regression in full Space

• Coefficients
• Value Std. Error t value
• (Intercept) 5.99024204 2.684250011 2.231626
• mcv -0.06398345 0.029631551 -2.159301
• alk -0.01952510 0.006756806 -2.889694
• sgpt -0.06410562 0.012283808 -5.218709
• sgot 0.12319769 0.024254150 5.079448
• gammagt 0.01894688 0.005589619 3.389656
• drinks -0.06807958 0.040358528 -1.686870
• So the classification rule is G(x)

6
Classification error rate

• the classification error on the whole training
  data set.
• error rate 0.2956
• Sensitivity 0.825
• Specificity 0.5379
• The error rate and its standard error
  obtained by 10-fold cross validation
• error rate(Standard Error) 0.307461384336384
  (0.0271)
• Sensitivity(Standard Error) 0.816280482802222
  (0.0203)
• Specificity(Standard Error) 0.531134992458522
  (0.0699)

7
Backward step wise model selection based on AIC

• Five variables are selected after step-wise model
  selection. The first variable MCV is deleted.
• error rate(Standard Error) 0.329460817156602
  (0.03051)
• Sensitivity(Standard Error) 0.792109881015521
  (0.03433)
• Specificity(Standard Error) 0.507341628959276
  (0.03863)
• COMMENT
• This method has a larger classification error
  rate than the original one. Using stepwise
  doesnt improve classification

8
Scree plot for the PCA
9
The performance of the Logistic regression on the
reduced space

• The reduced space is obtained by selecting the
  first three principle components. The standard
  error is obtained by 10 fold cross validation.
• error rate(Standard Error) 0.456256232089833
  (0.023414)
• Sensitivity(Standard Error) 0.372869939127443
  (0.031675)
• Specificity(Standard Error) 0.783003663003663
  (0.030785)
• Comment
• the classification error rate is around 50,
  which is not much better than the random
  guessing.

10
The classification plot on the first two
principle components plane
11
Linear Discriminant Analysis

• LDA assumes a multivariate normal distribution,
  so we make some log transformations on some
  variables.
• Y1mac Y2log(alk)
• Y3log(sgpt) Y4log(sgpt)
• Y5log(gammat) Y6log(dringks1)

12
The histogram of the sgpt variable and its log
transformation
13
The performance of the LDA based on Transformed
data

• Comment the classification error is the smallest
  among all methods and the sensitivity is the
  largest
• error rate 0.263768115942029
• Sensitivity 0.865
• Specificity 0.558620689655172
• By the log transformation, we make the assumption
  of multivariate normality reasonable. So the
  classification becomes better.

14
LDA after PCA

• error rate 0.411594202898551
• Sensitivity 0.88
• Specificity 0.186206896551724
• Comment
• the performance is not improved by PCA

15
Conclusion

• Four different methods are applied to the liver
  disorder data set. The LDA based on the
  transformed variables works best and the Logistic
  regression based on the original data set second.

• The classification method based on the principle
  component doesnt work well. Although the first
  three principle components contain more than 97
  variation, we may still lose the most important
  information for classification.
• The transformations can make the LDA method work
  better in some cases. The LDA assumes the
  normality distribution which is a very strong
  assumption in many data sets. For example, in our
  data, all variables except the first one are
  seriously skewed. That is why log transform works.
