Catalogue

1
Catalogue
Spring 2003 V1.0
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
2
Barcode Scanners
Specifications subject to change without notice
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
3
BaracodaPencil
Wireless Barcode Scanners
The most innovative Wireless Barcode Reader
Read decode common symbologies (UPC-EAN,
code39, code128) Write on tactile screens (PDA,
TabletPC, etc.) Communicate with PC, PDA, Mobile
phones, LAN, etc. via Bluetooth 1.1 Wireless
Technology

• Contact Scanning
• Real Time Batch modes
• Radio range up to 15 m
• Frequency 2.4 2.48 GHz GFSK
• Batch capacity gt 5000 bar codes
• Battery NimH rechargeable
• Battery life gt 3000 scans
• Dimension (112 mm X 25 mm X 16 mm)
• Weight 42g

Accessories
110 240 V. Charger
Car Charger
LeatherCase
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
4
BC2604
Wireless Barcode Scanners
CCD Wireless Scanner
Short Range Scanner Designed for retail
environments Up to 100m operational range

• Scanning distance CCD 2,5 to 18 cm
• Real Time Batch modes
• Radio range up to 100 m
• Frequency 2.4 2.48 GHz GFSK
• Batch capacity gt 3000 bar codes
• Battery 2xAA NimH 1800 mAhrechargeable
• Battery life gt 3000 scans
• Dimension 143 mm X 78,8 mm X 154,5 mm
• Weight 180g

Accessories
110 240 V. Charger
Car Charger
Holder
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
5
BL2604
Wireless Barcode Scanners
Laser Wireless Scanner
Long Range Scanner designed for retail
environments Up to 100m operational range

• Scanning distance Laser 10 to 50 cm
• Real Time Batch modes
• Radio range up to 100 m
• Frequency 2.4 2.48 GHz GFSK
• Batch capacity gt 3000 bar codes
• Battery 2xAA NimH 1800 mAhrechargeable
• Battery life gt 3000 scans
• Dimension 143 mm X 78,8 mm X 154,5 mm
• Weight 180g

Accessories
110 240 V. Charger
Car Charger
Holder
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
6
BL 1000
Wireless Barcode Scanners
Innovating Ergonomic Laser Scanner
Read decode common symbologies (UPC-EAN- JAN,
code39, code128) 3 interfaces available (RS232,
USB, Bluetooth) Great Price and many accessories

• Scanning distance 5 to 15 cm
• Real Time Batch modes
• Timestamp
• Batch capacity ? 100 bar codes
• Power 3 x AAA Alkaline batteries
• Audible indicator 3 sounds (can be disabled)

Accessories
DockingStation
ProtectiveBoot
BluetoothAdapter
USBAdapter
Holster
SerialCable
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
7
WSC 800
Wired Barcode Scanners
Contact CCD Scanner
High Optical Performance Ergonomic Design
Multiple Interface Design (Kboard wedge, Serial
Wand Emulation All in 1 unit)

• Scanning distance 0 to 5 cm
• Scanning width Up to 12 cm
• Shock resistance Approved by 1,2 m drop test
  on concrete
• Length 17 cm
• Width 9,3 cm
• Heigth 5,8 cm
• Weight 120 g excluding cable connector
• Voltage 5V DC10
• Connector 10P10C RJ45 Phone Jack
• Cable 2 m straight cable

Options
USB Interface Advanced Note-book, Keyboard
Interface (direct link)
Symbologies
Code39, Code39 extended, Interleaved 2 of 5,
EAN-13, EAN-8, UPC-A, UPC-C, Code128, Code93,
Coda bar, Code11, Code32, EAN-128, Chines postage
code, IATA, MSI/PLESSY, STD 2 of 5, Martix 2 of
5, Italian Pharmacy Code, Industrial 2 of 5,
BC-412
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
8
WSC 2100
Wired Barcode Scanners
Long Range CCD Scanner

• Scanning distance 2,5 to 20 cm
• Scanning width Up to 20 cm
• Shock resistance Approved by 1,5m drop test on
  concrete
• Length 9,3 cm
• Width 8 cm
• Heigth 15 cm
• Weight 165 g excluding cable connector
• Voltage 5V DC10
• Scan rate 150 scans/s

Options
USB Interface
Accessories
Symbologies
Code39, Code39 extended, Interleaved 2 of 5,
EAN-13, EAN-8, UPC-A, UPC-C, Code128, Code93,
Coda bar, Code11, Code32, EAN-128, Chines postage
code, IATA, MSI/PLESSY, STD 2 of 5, Martix 2 of
5, Italian Pharmacy Code, Industrial 2 of 5,
BC-412
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
9
BMC 3000
Mobile Computer
Built-in Laser Scanner

• Intel strong ARM 720T 74MHZ, 32 bits RISC CPU
  core
• OS Windows CE 3.0
• Memory 16/32 MB Nand Flash 128 KB Boot ROM
  32MB SDRAM
• Display 16 gray scale mono LCD with EL backlight
  240x320 pixels
• Audio Microphone Speaker Mono DIA earphone
  jack stereo
• Dimension 13,5 x 8,2 x 1,8 cm
• Weight 190 g
• Battery Type 4.2 V, 1500 mAh Li-Polymer
• Battery Life 1315 hours _at_ 1 scan every 5
  seconds
• Scan rate 150 scans/s
• Communication IrDA 1.0 USB 1.0 Compact
  Flash (CF) Type II expansion slot

Code39, Code39 extended, Interleaved 2 of 5,
EAN-13, EAN-8, UPC-A, UPC-E, Code128, Code93,
Coda bar, Code11, EAN-128, Chines postage code,
IATA, MAI/PLESSY, STD 2 of 5, Martix 2 of 5,
Code32
Symbologies
HANTZ PARTNER GMBH www.hantz.com
www.BluetoothUpgrades.de
10
Wireless connectivity
Specifications subject to change without notice
