SAT and CSP competitions

1
SAT and CSP competitions benchmark
librariessome lessons learnt?

• Toby Walsh
• NICTA UNSW
• Sydney, Australia

2
Whats the best way to benchmark systems?
3
Outline

• Benchmark libraries
• Founding CSPLib.org
• Competitions
• SAT competition judge
• TPTP competition judge

4
Why?

• Why did I set up CSPLib.org
• I needed problems against which to benchmark my
  latest inference techniques
• Zebra and random problems dont cut it!
• I thought it would help unify and advance the CP
  community

5
Random problems

• ve
• Easy to generate
• Hard (if chosen from phase transition)
• Impossible to cheat
• You can solve 1000 variable random 3SAT problems
  at l/n4.2, Ill be impressed

6
Random problems

• -ve
• Lack structures found in real world
• Unrepresentative
• E.g. random 3SAT either have many solutions or
  none
• Different methods work well on them
• Random SAT forward looking algorithms
• Industrial SAT backward looking algorithms

7
Why?

• Thesis every mature field has a benchmark
  library
• Deduction started in 1960s
• TPTP set up in 1993
• SAT started in 1960s
• SAT DIMACS challenge in 1992
• SATLib set up in 1999
• CP started in 1970s
• CSPLib set up in 1998

8
Why?

• Thesis every mature field has a benchmark
  library
• Spatial and temporal reasoning started in early
  80s (or before?)
• Its been approximately 30 years so its about
  time you guys set one up!

9
Benchmark libraries

• CSPLib.org
• Over 35k unique visitors
• Still not everything Id want it to be
• But state of the art for experimentation is now
  much better than it was
• I havent seen a zebra for a very long time

10
An ideal library

• Desiderata taken from
• CSPLib a benchmark library for constraints,
  Proc. CP-99

11
An ideal library

• Location
• On the web and easy to find
• TPTP.org
• CSPLib.org
• SATLib.org
• QBFLib.org
• http//elib.zib.de/pub/mp-testdata/tsp/tsplib/tspl
  ib.html
• http//mat.gsia.cmu.edu/COLOR/instances.html

12
An ideal library

• Easy to use
• Tools to make benchmarking as painless as
  possible
• tptp2X,
• Diverse
• To help prevent over-fitting

13
An ideal library

• Large
• Growing continuously
• Again helps to prevent over-fitting
• Extensible
• To new problems or domains

14
An ideal library

• Complete
• One stop for your problems
• Topical
• For instance, it should report current best
  solutions found

15
An ideal library

• Independent
• Not tied to a particular solver or proprietary
  input language
• Mix of difficulties
• Hard and easy problems
• Solved and open problems
• With perhaps even a difficulty index?

16
An ideal library

• Accurate
• It should be trusted
• Used
• A valued resource for the community

17
Problem format

• Lo-tech or hi-tech?

18
Lo-tech formats

• DIMACS format used in SATLib
• c a simple example
• p cnf 3 2
• 1 -1 0
• 1 2 3 0
• This represents x v -x, x or y or z

19
Lo-tech formats

• DIMACS format used in SATLib
• ve
• All programming languages can read integers!
• Small amount of extensibility built in (e.g. QBF)
• -ve
• Larger extensions are problematic (e.g. beyond
  CNF to arbitrary Boolean circuits)

20
Hi-tech formats

• CP competition
• ltinstancegt
• ltpresentation
• name"4-queens"
• description"This problem involves placing
  4 queens on a chessboard"
• nbSolutions"at least 1"
• format"XCSP1.1 (XML CSP Representation
  1.1)"
• /gt
• ltdomains nbDomains"1"gt
• ltdomain name"dom0" nbValues"4"
  values"1..4" /gt
• lt/domainsgt
• ltvariables nbVariables"4"gt
• ltvariable name"X0" domain"dom0"/gt
• lt/variablesgt
• ltrelations nbRelations"3"gt
• ltrelation
• name"rel0" domain"dom0 dom0
  nbConflicts"10
• conflicts"(1,1)(1,2)(2,1)(2,2)(2,3)(3,2)(
  3,3)(3,4)(4,3)(4,4)" /gt

21
Hi-tech formats

• XML
• ve
• Easy to extend
• Parsing tools can be provided
• -ve
• Complex and verbose
• Computers can parse terse structures easily

22
No-tech formats

• CSPLib
• Problems are specified in natural language
• No agreement at that time for an input language
• One focus was on how you model a problem
• Today there is more consensus on modelling
  languages like Zinc

23
No-tech formats

• CSPLib
• Problems are specified in natural language
• But you can still provide in one place
• Input data
• Results
• Code
• Parsers

24
Getting problems

• Submit them yourself
• Initially, you must do this so library has some
  critical mass first time people look at it
• But it becomes tiresome and unrepresentative to
  do so continually
• Ask at every talk
• Tried for several years but it (almost) never
  worked

25
Getting problems

• Need some incentive
• Offer money?
• Price of entry for the competition?
• If you have a competition, users will submit
  problems that their solver is good at?

26
Competitions
27
Libraries Competitions

• You can have a library without a competition
• But you cant have a competition without a library

28
Libraries Competitions

• Libraries then competition
• TPTP then CASC
• Easy and safe!
• Libraries and competition
• Planning
• RoboCup

29
Increasing complexity

• Constraints
• 1st year, binary extensional
• 2nd year, limited number of globals
• 3rd year, unlimited
• Planning
• Increasing complexity
• Time, metrics, uncertainty,

30
Benefits

• Gets ideas implemented
• Rewards engineering
• Progress needs both science and engineering!
• Puts it all together

31
Benefits

• Gives greater importance to important low-level
  issues
• In SAT
• Watched literals
• VSIDS

32
Benefits

• Witness the progress in SAT
• 1985, 10s vars
• 1995, 100s vars
• 2005, 1000s vars
• Not just Moores law at play!

33
Pitfalls

• Competitions require lots of work
• Organizers get limited (academic) reward
• One solution is to organize also competition
  special issues

34
Pitfalls

• Competitions encourage incremental improvements
• Dont have them too often!
• You may discover a local minimum
• E.g. MDPs for speech recognition
• Give out best new solver prize?

35
The Chaff story

• Industrial problems, SAT UNSAT instances
• 2008, 1st MiniSAT (son of zChaff)
• 2007, 1st RSAT (son of MiniSAT)
• 2006, 1st MiniSAT
• 2005, 1st SatELite GTI (MiniSATpreprocessor)
• 2004, 1st zChaff (Forklift from 2003 was better)
• 2003, 1st Forklift
• 2002, 1st zChaff

36
Other issues

• Man-power
• Organizers
• One is not enough?
• Judges
• All rules need interpretation
• Compute-power
• Find a friendly cluster

37
Other issues

• Multiple tracks
• SAT/UNSAT
• Random/industrial/crafted
• Certificate/Uncertificated

38
Other issues

• Holding problems back if possible
• Release some problems so competitors can ensure
  solver compliance
• But hold most back so competition is blind!

39
Other issues

• Multiple phases
• Too many solvers for all to compete with long
  timeouts
• First phase to test correctness
• Second phase to throw out the slow solvers (who
  cost you many timeouts)
• Third phase to differentiate between better
  solvers

40
Other issues

• Reward function
• ltcompleted, average time, gt
• solution purse speed purse
• Points for each problem divided between those
  solvers that solve it
• Getting buy in from competitors
• It will (and should) evolve over time!

41
Other issues

• Prizes
• Give out many!
• Good for peoples CVs
• Good motivator for future years

42
Other issues

• Open or closed source?
• Open to share progress
• Closed to get the best
• Last years winner
• Condition of entry
• To see progress is being made!

43
Other issues

• Smallest unsolved problem
• Give a prize!
• Timing
• Run during the conference
• Creates a buzz so people enter next year
• Get a slot in program to discuss results
• Get a slot in banquet to give out prizes

44
Conclusions

• Benchmark libraries
• When an area is several decades old, why wouldnt
  you have one?
• Competitions
• Designed well, held not too frequently, with
  buy-in from the community, why wouldnt you?

45
Questions

• Disagreements
• Other opinions
• Different experiences
