Title: MSE 606 B Engineering Operations Research II


1
MSE 606 BEngineering Operations Research II
  • Dr. Ahmad R. SarfarazManufacturing Systems
    Engineering and Management
  • California State University, Northridge

2
Agenda
  • Course syllabus and administration
  • Overview of Operations Research II

3
STANDARD OPERATING PROCEDURES
  • Collaborative learning groups for research paper
    and HW assignments will be utilized
  • HW assignments and research paper can be worked
    in a group of 2-3 students/group
  • Problems will typically be assigned at each class
    session and will form the basis for the
    examinations
  • HW assignments will be due at the beginning of
    the next class session
  • One set (the original) should be turned in per
    group
  • All students need to have a copy of the HW
    solution with them in class
  • HW is marked as turned in 5 of the homework
    assignments are corrected and graded

4
Evaluation
  • Requirement Parts Points Total Points
  • HW assignments 5 30 150
  • Exam1 1 250 250
  • Final 1 300 300
  • Research Paper 1 300 300

5
Topics Covered
  • Inventory Control (deterministic)
  • Nonlinear Programming (NLP)
  • Dynamic Programming (deterministic)
  • Overview of probability and statistics
  • Inventory Control (probabilistic)
  • Forecasting
  • Decision Analysis
  • Markov Analysis
  • Queuing Analysis
  • Simulation
  • Game Theory

6
Organization
  • First Session
  • Introduction of new material and mathematical
    development
  • Second Secession
  • Solutions procedures, sample problems, and
    applications

7
The Importance of Inventory Control
  • Why is it so important?
  • Total value of all inventory is more than a
    1,000,000,000,000
  • More than 4,000 each for every man, woman, and
    child in the country
  • Reducing a little bit, can enhance companys
    competitiveness
  • Exist many models including determinate and
    probabilistic models

8
Nonlinear Programming (NLP)
  • Presented
  • Linear Programming models and several variations
    of the LP models
  • Objective functions and the constraints were
    linear
  • Many realistic problems have nonlinear functions
  • When LP problems contain nonlinear functions,
    they are referred NLP
  • Have a separate name, because they are solved
    differently

9
Dynamic Programming
  • An approach for making a sequence of interrelated
    decisions
  • Applicable to problems that are multistage in
    nature
  • Example
  • A problem of determining an optimal solution over
    1-year horizon might be broken into 12 smaller
    stages
  • Decomposes a large problem into a number smaller
    problems
  • Once all small problems have been solved, we have
    optimal solution to large problem

10
Multicriteria Decision Making Analytical
Hierarchy Process
  • Presented goal programming last semester
  • Learned how to formulate a problem with more than
    one objectives
  • AHP developed by Saati
  • A method for rankling decision alternatives and
    selecting the best one when the decision maker
    has multiple objectives, or criteria
  • GP answers how much?, whereas AHP answers
    which one?

11
Decision Analysis
  • In LP formulation, we assumed that certainty
    existed
  • Means that all of the model coefficients, and
    constraint values are known with certainty
  • Many decision-making situations occur under
    conditions of uncertainty
  • Decision situations can be categorized into two
    classes situations in which probabilities can be
    assigned to future occurrences and situations in
    which probabilities cannot be assigned
  • Will present both situations

12
Markov Analysis
  • Like a decision analysis, it is not an
    optimization technique
  • A probabilistic technique
  • Provides probabilistic information about a
    decision situation
  • Applicable to systems that probabilistic
    information moves from one state (condition) to
    another, over time
  • Example
  • Probability that a machine will be running one
    day breakdown on the next
  • Probability that a customer will change his/her
    taste from one month to the next
  • Referred to as the Brand Switching

13
Game Theory
  • In decision analysis, there is one decision maker
  • No competitors whose decisions might change the
    decision made by the first one
  • Many situations involve several decision makers
    who compete with one another to arrive at the
    best outcome
  • Examples
  • Card games, parlor games, political campaigns,
    athletic competitions, military battles,
    advertising and marketing campaigns, and so on

14
Forecasting
  • Prediction of what will occur in the future
  • Managers are continuously trying to predict the
    future
  • They usually use judgment, opinion, or past
    experiences to forecast
  • Mathematical models exist to help managers
  • Will present some of these techniques

15
Queuing Analysis
  • Waiting in queues-waiting lines-is one of the
    most occurrences in everyones life
  • Not only people spend a significant of their time
    in lines, but products queue up in production
    plants
  • Examples machinery waits to be serviced, planes
    wait to take off and land, ships at ports wait to
    unload and load, and so on
  • Because time is a valuable resource, the
    reduction of waiting time is an important topic

16
Simulation
  • Some of the OR topics deal with mathematical
    models that can be applied to certain types of
    problems
  • Not all real-world problems can be solved by
    applying a specific type of technique
  • When problems cannot be formulated, simulation is
    an alternative technique
  • Simulation technique can be applied to queuing,
    inventory control, production and manufacturing,
    finance, marketing, public sector operations, and
    environmental and resource analysis

17
Next Session
  • NLP Modeling
  • Objective functions
  • Decision variables
  • Constraints

18
Inventory Modeling
19
Why is it Important?
  • Pervades the business world
  • Necessary for any company dealing with physical
    products
  • Manufacturing
  • Wholesalers
  • Retailers
  • Total value (in US) is more than
    1000,000,000,000
  • 25 associates with storing cost
  • Hence, reducing a little bit, can enhance
    companys competitiveness

20
Basic Questions in Inventory Control
  • How much should we stock?
  • Two extreme answers to this question
  • A lot
  • This ensures that we never run out
  • An easy way of managing Stock
  • Expensive in inventory costs, cheap in
    management costs
  • None/very Little
  • Known as JIT
  • A difficult way of managing stock
  • Cheap in inventory costs, expensive in
    management costs
  • When should we order?

21
Types of Inventory Policies
  • Depends on demand and lead time
  • the number of units that will need to be
    withdrawn from inventory
  • Deterministic Models
  • Stochastic Models

22
Types of Inventory Costs
  • Purchasing Costs
  • Holding costs
  • Ordering costs
  • Stock out costs
  • Not considered here
  • Annual Inventory CostPurchasing CostsHolding
    CostsOrdering Costs

23
Holding Costs
  • Storage Costs
  • Labor
  • Overheads (Heating, Lighting, Security)
  • Money Tied up (Loss of Interest, Opportunity
    Cost)
  • Obsolescence Costs
  • Stock Deterioration (Lose Money If Product
    Deteriorates)
  • Theft/insurance

24
Ordering Costs
  • Clerical/labor Costs of Processing Orders
  • Inspection and Return of Poor Quality Products
  • Transport Costs
  • Handling Costs

25
Deterministic Assumptions
  • Demand is known and constant
  • Lead time is known and constant
  • Order quantity does not depend on price
  • Order quantity arrives all at once when needed
  • Planned shortages are not allowed

26
Basic Model
Q
Inventory level
time
27
Inventory Control Notation
  • Kordering cost
  • cunit purchasing cost
  • hholding cost per unit per unit of time
  • Qordering quantity
  • aannual demand
  • tcycle time

28
Annual Holding Cost
  • Annual holding cost (holding cost per
    unit)(Average inventory
  • h(Q/2)
  • where Q/2 is the average (constant) inventory
    level

Annual Holding Cost
Holding Cost Curve
Order Quantity
29
Annual Order Cost
  • Annual order cost co(R/Q)
  • where (R/Q) is the number of orders per year (R
    used, Q each order)

Total Annual Ordering Cost
Annual Order Cost
Order Quantity
30
Total Annual Cost Curve
Total Annual cost
Cost
Annual holding cost
Annual ordering cost
Q
31
Optimal Policy
  • TC ch(Q/2) co(R/Q)
  • The function that we want to minimize by choosing
    an appropriate value of Q
  • Differentiating total cost with respect to Q and
    equating to zero Q (2Rco/ch)1/2
  • Total annual cost associated with the EOQ
    (2Rcoch) 1/2

32
Assumptions in Deterministic Models
  • Demand is known and constant
  • Lead time is known and constant
  • Order quantity does not depend on price
  • Order quantity arrives all at once when needed
  • Planned shortages are not allowed
  • Presented EOQ model for a single item
  • Relaxed the 4th assumption and developed the EPQ
    model

33
EOQ Model with Quantity Discount
  • Relax the 3rd assumption
  • Quantity discount means that the order quantity
    depends on price
  • More quantity at lower price
  • To illustrate the problem, consider this example
  • C1gtC2gtC3gtC4

34
Graphical Solution Plot of Cj and Q
TC
C1
C2
C3
Q
Q1
Q2
Q3
35
Solution Procedure
  • For each unit price, calculate the EOQ
  • If the EOQ is within the feasible range,
    calculate the corresponding TC
  • If the EOQ is not within the feasible range,
    calculate TC using the total cost function
  • Compare the TC for all unit prices and choose the
    minimum TC

36
Example
  • Ordering cost A2500
  • Inventory carrying charge I15
  • Annual demand, D200 units
  • Vender offers the price discount

37
Solution
  • Compute Q at C11400
  • Q (2DA/IC)1/2(2)(2500)(200)/(210)1/269
  • Outside the feasible range
  • Q (2DA/IC)1/2(2)(2500)(200)/(165)1/278
  • Inside the feasible range
  • TCDC (2DAIC)1/2232,845
  • Must be compared with the TC of lower (lowest in
    this particular example) discount price
  • TCDC 2DA/QHQ/2
  • TC(200)(900)(2)(200)(2500)/90 (135)(90)/2
    191,630
  • Since 191,630lt 232,845, the maximum discount
    price should be taken and 90 units ordered

38
The EOQ Model with Shortages
  • Assumptions
  • Demand is known and constant
  • Lead time is known and constant
  • Order quantity does not depend on price
  • Order quantity arrives all at once when needed
    (EPQ case)
  • Planned shortages are allowed

39
Allowed Shortages or Backordering
  • May be worthwhile to permit some shortages to
    occur
  • Can result savings in holding costs
  • Benefit may be offset by the shortage cost
  • Sale is not lost firm does not lose the customer
  • Customers wait to have their demand filled from
    next order
  • Shortage cost is the penalty incurred when we ran
    out of stock (often requires expediting and
    higher price in shorter lead time)
  • All shortages are satisfied from the next order

40
Graphical Representation of Backordering
Inventory level
Q-S
Q
time
S
T
t1
t2
41
Revisiting EOQ Modeling
  • Consider only one cycle
  • During T (where TQ/D) one order (Q) is placed,
    so the order cost is A and the purchase cost is
    QC
  • Holding cost is (Q/2)(H)(T)
  • TC for one cycle QCA(Q/2)(H)(T)
  • Annual TC is (D/Q)QCA(Q/2)(H)(T)
  • TCDCDA/QHQ/2 same thing we had before

Q
T
42
Determination of Q and S Values
  • Consider just one cycle
  • During T (where TQ/D) one order (Q) is placed,
    so the order cost is A and the purchase cost is
    QC
  • Holding cost is (Q-S)/2)(H)(t1), where
    t1(Q-S)/D, or (Q-S)2(H/2D)
  • If kshortage cost per unit, shortage cost/cycle
    is (K)(S/2)(t2), where t2 S/D, or KS2/2D
  • TC for one cycle
  • QCA (Q-S)2(H/2D) KS2/2D
  • Annual TC
  • (D/Q)QCA (Q-S)2(H/2D) KS2/2D
  • TCDCDA/Q (Q-S)2(QH/2) QKS2/2

t2
Q
Q-S
S
t1
43
Optimal values for Q and S
  • TCDCDA/Q (Q-S)2(QH/2) QKS2/2
  • Partial derivatives of TC with respect to Q and S
    are equated to zero
  • Q (2DA/IC)1/2 ((HK)/K)1/2
  • SHQ/(HK)
  • If K approaches infinity, Q approaches to
    (2DA/IC)1/2

44
Example
Write a Comment
User Comments (0)
