Decision List

1
Decision List

• LING 572
• Fei Xia
• 1/12/06

2
Outline

• Basic concepts and properties
• Case study

3
Definitions

• A decision list (DL) is an ordered list of
  conjunctive rules.
• Rules can overlap, so the order is important.
• A k-DL the length of every rule is at most k.
• A decision tree determines an examples class by
  using the first matched rule.

4
An example

• A simple DL
• If X1v11 X2v21 then c1
• If X2v21 X3v34 then c2
• Classify an example(v11,v21,v34)
• The DL is 2-DL.

5
Rivests paper

• It assumes that all attributes (including goal
  attribute) are binary.
• It shows DL is easily learnable from examples.

6
Assignment and formula

• Input attributes x1, , xn
• An assignment gives each input attribute a value
  (1 or 0) e.g., 10001
• A boolean formula (function) maps each assignment
  to a value (1 or 0)

7

• Two formulae are equivalent if they give the same
  value for same input.
• Total number of different formulae
• ? Classification problem learn a formula given a
  partial table

8
CNF an DNF

• Literal
• Term conjunction (and) of literals
• Clause disjunction (or) of literals
• CNF (conjunctive normal form) the conjunction of
  clauses.
• DNF (disjunctive normal form) the disjunction of
  terms.
• k-CNF and k-DNF

9
A slightly different definition of DT

• A decision tree (DT) is a binary tree where each
  internal node is labeled with a variable, and
  each leaf is labeled with 0 or 1.
• k-DT the depth of a DT is at most k.
• A DT defines a boolean formula look at the paths
  whose leaf node is 1.
• An example

10
Decision list

• A decision list is a list of pairs
• (f1, v1), , (fr, vr),
• fi are terms, and frtrue.
• A decision list defines a boolean function
• given an assignment x, DL(x)vj, where j is
  the least index s.t. fj(x)1.

11
Relations among different representations

• CNF, DNF, DT, DL
• k-CNF, k-DNF, k-DT, k-DL
• For any k lt n, k-DL is a proper superset of the
  other three.
• Compared to DT, DL has a simple structure, but
  the complexity of the decisions allowed at each
  node is greater.

12
k-CNF and k-DNF are proper subsets of k-DL

• k-DNF is a subset of k-DL
• Each term t of a DNF is converted into a decision
  rule (t, 1).
• k-CNF is a subset of k-DL
• Every k-CNF is a complement of a k-DNF k-CNF and
  k-DNF are duals of each other.
• The complement of a k-DL is also a k-DL.
• Neither k-CNF nor k-DNF is a subset of the other
• Ex 1-DNF

13
K-DT is a proper set of k-DL

• K-DT is a subset of k-DNF
• Each leaf labeled with 1 maps to a term in
  k-DNF.
• K-DT is a subset of k-CNF
• Each leaf labeled with 0 maps to a clause in
  k-CNF
• ? k-DT is a subset of

14
K-DT, k-CNF, k-DNF and k-DT
k-CNF
k-DNF
k-DT
K-DL
15
Learnability

• Positive examples vs. negative examples of the
  concept being learned.
• In some domains, positive examples are easier to
  collect.
• A sample is a set of examples.
• A boolean function is consistent with a sample if
  it does not contradict any example in the sample.

16
Two properties of a learning algorithm

• A learning algorithm is economical if it requires
  few examples to identify the correct concept.
• A learning algorithm is efficient if it requires
  little computational effort to identify the
  correct concept.
• ? We prefer algorithms that are both economical
  and efficient.

17
Hypothesis space

• Hypothesis space F a set of concepts that are
  being considered.
• Hopefully, the concept being learned should be in
  the hypothesis space of a learning algorithm.
• The goal of a learning algorithm is to select the
  right concept from F given the training data.

18

• Discrepancy between two functions f and g
• Ideally, we want to be as small as
  possible.
• To deal with bad luck in drawing example
  according to Pn, we define a confidence
  parameter

19
Polynomially learnable

• A set of Boolean functions is polynomially
  learnable if there exists an algorithm A and a
  polynomial function
• when given a sample of f of size
• drawn according to Pn, A will with probability
  at least output a
  s.t.
• Furthermore, As running time is polynomially
  bounded in n and m.
• K-DL is polynomially learnable.


20
How to build a decision list

• Decision tree ? Decision list
• Greedy, iterative algorithm that builds DLs
  directly.

21
The algorithm in (Rivest, 1987)

• If the example set S is empty, halt.
• Examine each term of length k until a term t is
  found s.t. all examples in S which make t true
  are of the same type v.
• Add (t, v) to decision list and remove those
  examples from S.
• Repeat 1-3.

22
The general greedy algorithm

• RuleList, Etraining_data
• Repeat until E is empty or gain is small
• f Find_best_feature(E)
• Let E be the examples covered by f
• Let c be the most common class in E
• Add (f, c) to RuleList
• EE E

23
Problem of greedy algorithm

• The interpretation of rules depends on preceding
  rules.
• Each iteration reduces the number of training
  examples.
• Poor rule choices at the beginning of the list
  can significantly reduce the accuracy of DL
  learned.
• ? Several papers on alternative algorithms

24
Summary of (Rivest, 1987)

• Formal definition of DL
• Show the relation between k-DL, k-CNF, k-DNF and
  k-DL.
• Prove that k-DL is polynomially learnable.
• Give a simple greedy algorithm to build k-DL.

25
Outline

• Basic concepts and properties
• Case study

26
In practice

• Input attributes and the goal are not necessarily
  binary.
• Ex the previous word
• A term ? a feature (it is not necessarily a
  conjunction of literals)
• Ex the word appears in a k-word window
• Only some feature types are considered, instead
  of all possible features
• Ex previous word and next word
• Greedy algorithm quality measure
• Ex a feature with minimum entropy

27
Case study accent restoration

• Task to restore accents in Spanish and French
• ? A special case of WSD
• Ex ambiguous de-accented forms
• cesse ? cesse, cessé
• cote ?côté, côte, cote, coté
• Algorithm build a DL for each ambiguous
  de-accented form e.g., one for cesse, another
  one for cote
• Attributes words within a window

28
The algorithm

• Training
• Find the list of de-accent forms that are
  ambiguous.
• For each ambiguous form, build a decision list.
• Testing check each word in a sentence
• if it is ambiguous,
• then restore the accent form according to the DL

29
Step 1 Identify forms that are ambiguous
30
Step 2 Collecting training context
Context the previous three and next three
words. Strip the accents from the data. Why?
31
Step 3 Measure collocational distributions
Feature types are pre-defined.
32
Collocations
33
Step 4 Rank decision rules by log-likelihood
There are many alternatives.
word class
34
Step 5 Pruning DLs

• Pruning
• Cross-validation
• Remove redundant rules WEEKDAY rule precedes
  domingo rule.

35
Building DL

• For a de-accented form w, find all possible
  accented forms
• Collect training contexts
• collect k words on each side of w
• strip the accents from the data
• Measure collocational distributions
• use pre-defined attribute combination
• Ex -1 w, 1w, 2w
• Rank decision rules by log-likelihood
• Optional pruning and interpolation

36
Experiments
Prior (baseline) choose the most common form.
37
Global probabilities vs. Residual probabilities

• Two ways to calculate the log-likelihood
• Global probabilities using the full data set
• Residual probabilities using the residual
  training data
• More relevant, but less data and more expensive
  to compute.
• Interpolation use both
• In practice, global probability works better.

38
Combining vs. Not combining evidence

• Each decision is based on a single piece of
  evidence.
• Run-time efficiency and easy modeling
• It works well, at least for this task, but why?
• Combining all available evidence rarely produces
  different results
• The gross exaggeration of prob from combining
  all of these non-independent log-likelihood is
  avoided

39
Summary of case study

• It allows a wider context (compared to n-gram
  methods)
• It allows the use of multiple, highly
  non-independent evidence types (compared to
  Bayesian methods)
• ? kitchen-sink approach of the best kind

40
Advance topics
41
Probabilistic DL

• DL a rule is (f, v)
• Probabilistic DL a rule is
• (f, v1/p1 v2/p2 vn/pn)

42
Entropy of a feature q
fired
not fired
43
Algorithms for building DL

• AQ algorithm (Michalski, 1969)
• CN2 algorithm (Clark and Niblett, 1989)
• Segal and Etzioni (1994)
• Goodman (2002)

44
Summary of decision list

• Rules are easily understood by humans (but
  remember the order factor)
• DL tends to be relatively small, and fast and
  easy to apply in practice.
• DL is related to DT, CNF, DNF, and TBL.
• Learning greedy algorithm and other improved
  algorithms
• Extension probabilistic DL
• Ex if A B then (c1, 0.8) (c2, 0.2)
