Development of Front-End Electronics for
Picosecond Resolution TOF Detectors Fukun Tang,
Enrico Fermi Institute, The University of
Chicago With Henry Frisch, Mary Heintz, Harold
Sanders (The University of Chicago), John
Anderson, Karen Byrum, Gary Drake (Argonne
National Laboratory) and Jean-Francois Genat
(Saclay)
Time Stretcher ASIC Design Considerations
Time Stretcher ASIC Design and Simulations
Introduction
Time Stretcher ASIC Design and Simulations
Digital Phase-Frequency Detector and Charge Pump
Design
The Basic Structure of 2GHz PLLs
MCP Photo Detector Output Signal Characteristics
With newly designed 2x2 inches, 1024 equal timing
anodes micro-channel plate (MCP) photo detector
featuring single pulse rising time in the order
of 50ps and transit time spread (TTS) in the
order of 25ps, it has become possible to attempt
a design of a large area detector with
pico-second resolution for relativistic
particles. The picosecond Time-of-Flight
electronics system consists of a custom ASIC and
several commercial chips with a MCP
photo-detector that is designed to measure the
arrival time of charged particles with a design
goal of one picosecond resolution. Effectively,
the system acts as a digital phototube all
analog signal processing is performed directly by
the circuits mounted on the MCP such that the
only interfaces that connect to external data
collection systems are digital control, digital
data output and power supplies. The frond-end
ASIC chip will be built with IBM 0.13u SiGe
BiCMOS 8HP process. The basic functional
circuitry in this chip includes a signal
receiver, an ultra low timing jitter/walk
discriminator, a control logic block, a 2Ghz PLL
common stop clock generator and an 1200 time
stretcher with a dynamic range of 1ns. DAQ chip
will convert each stretched signals to digital by
a 11-bit counter with 200ps resolution. With
1200 time stretching ratio, the time-to-digital
conversion will give 1ps time resolution.
Fig. 6
We have designed 2 types of PLLs (Analog and
Digital) to ensure if we can achieve a less than
1ps timing jitter for common stop clock.
Fig.12
Fig. 12 showed digital phase-frequency detector.
The proper reset delay time can optimize the
phase detector speed and cancel the inherent
errors that caused by the glitch from charge pump
mismatch and reset signal mismatch when both
reference and local clocks arrive in the same
time. As a result, the erroneous jitter can be
reduced when PLL locked in zero-phase. Fig13.
is the simplified schematic of charge pump, it is
a pair of well matched current steering switches
that control the current mirrors that act as
PLLs charge pump. This circuit is operated to
minimize the switching charge injection.
Fig. 3 shows the simulation result of MCP output
signal. The signal rising time is in the order of
15-20ps, pulse width is in the order of 40ps in
FWHM. This fast signal requires ASIC to have very
high speed circuits to process the front-end
analog signal .
Fig. 3 MCP Output Signal
APLL (Fig.6) is designed fully based on hetero
junction transistors, the very high speed and
ultra low noise transistors can help achieve very
low timing jitter in APLL. The only disadvantage
is the narrow pull-in range. Due to the
varactors variation process-to-process, this may
cause VCOs initial frequency out of the PLLs
pull-in range, in this case, the APLL wont go to
lock.
ASIC Technology and Design Kit
The DPLL(Fig.7) recently has been designed and
simulated. From simulation results, the
performance well meets our requirements.
The Time Stretcher will be built with IBM 0.13u
SiGe BiCMOS 8HP process. This state-of-art SiGe
process has the hetero-junction bipolar
transistors with the transition frequency as high
as 200GHz. The ultra low noise devices allow us
to build the very high performance circuits to
meet our requirements.
Fig. 7
Fig.13
Low Phase Noise VCO Design
PLL Lock Range and Jitter Prediction
Fig. 14 showed PLLs locking range. The red chart
showed PLL locked to 1.9GHz, blue chart showed
PLL locked to 2GHz the purple chart showed PLL
locked to 2.1GHz. A maximum of 10mV ripple was
observed in a loop bandwidth of 100MHz, which
equivalents to the timing jitter of 0.33ps
peak-to-peak. We predict a lower PLL bandwidth
can further reduce the ripple.
Fig.14
Fig.8 VCO Schematic
Fig. 1 MCPs 1024 anode pads have been grouped
to 4 sections, the anode signals in each section
will be summed in the equal time anode board and
sent to its time stretcher, a DAQ chip converts
the stretched pulses from 4 stretchers to
digital and also manages the communication with
system.
Circuit simulation with real time data and
interface to other simulation tools
Fig. 1
Simulink Modeling and Simulation
Due to MCP output signal is in extremely high
speed, it is almost impossible to use probe to
test and measure real time signals with the
circuits. In this case, a complete system
simulation is a key factor to build a successful
system. Fig. 4 shows the interface between
circuit simulation with real time data.
Fig.15
A Simulink modeling for fast simulation has been
setup, the preliminary simulation results well
matched Cadence Spectre simulation. We expect
the PLLs acquisition time can be as long as few
hundreds of microseconds or milliseconds if we
run PLL in a bandwidth of 100KHz to 1MHz. In this
case, it is impossible for Spectre to handle so
large transit simulation time scale (miliseconds)
with so small resolution time step (few ps).
Simulink can be used for the further simulations
to optimize the PLL loop bandwidth and loop gains
for minimized the PLL jitter.
VCO V-F Transfer Function and Phase Noise
Fig10 VCO Phase Noise Plot
Fig. 4
Stretching Circuit Simulation
Fig.16
Fig. 2 The time stretcher receives signal from
MCP, a very low timing jitter/walk discriminator
will be implemented to generate a start signal.
The time to measure is the difference between
start and Stop, that is a 500ps-1ns time
interval pulse . With the following 1200 time
stretching circuit, a stretched pulse
(100n-200ns) then be sent to DAQ chip for
digitizing by a 11 bit counter with 200ps
resolution.
As an evaluation, a preliminary 1200 time
stretching circuit simulation has been done with
IHP SiGe SG25H1 process, the current sources with
a ratio of 1200 is in behavior model. Fig. 5
shows 1ns pulse has been stretched to 274ns, the
extra 74 ns was caused by the charge injection
from the switches.
Fig. 9 V-F Transfer Function
VCO Layout
Fig. 2
Fig. 11 VCO Layout View.
Fig. 5 1200 pulse stretching pulse
Conclusion
(1) IBM 0.13um SiGe BiCMOS8HP has been evaluated,
it is very user-friendly design kit. (2) Circuit
performance well met to our requirements based on
our very low jitter PLL designs. (3) It is
possible to generate an on-chip PLL to generate a
stable, very low jitter (lt1ps) common stop
clock. (4) More challenging work need to be done
on Time Stretcher chip design including the ultra
low timing jitter/walk discriminator and the
dual-slop ramping time stretching circuits etc.
Inductors Varactors Heterojunction
Transistors Capacitors
2GHz Phase Locked Loop Design and Simulation
2GHz PLL is required to generate the very low
jitter common stop clock for Time Stretcher
chip. We have simulated analog PLL and digital
PLL. The simulation results showed both achieved
a timing jitter less than 1ps. The analog PLL
uses much less components than digital PLL, but
it has very narrow pull-in range, as a result,
the initial VCO frequency may out of the PLLs
pull-in range because the VCO varator variations
process-to-process. The digital PLL has a very
wide locking range and pull-in range, so that the
varactor variations process-to-process should not
be a problem.
