Exchanging Intensional XML Data

1
Exchanging Intensional XML Data

• Tova Milo, INRIA Tel Aviv University
• Serge Abiteboul, INRIA Xyleme S.A.
• Bernd Amann, CNAM
• Omar Benjelloun, INRIA
• Frederic Dang Ngoc, INRIA

SIGMOD 2003 San Diego
2
Introduction
3
Intensional documents

• Early days of the web
• Extensional data (static HTML)
• CGI scripts (perl, )
• Code is executed to generate data.
• Intensional data
• HTML with embedded code (php, jsp, )
• Embedded code is executed before sending data.
• XML with embedded calls to Web services
• Calls are still evaluated before sending (Jelly,
  MX, ).
• Active XML
• Calls do not have to be evaluated before sending
  data.
• Advantages of intensional data
• More information it shows how data is generated
• Dynamic it provide the means, e.g. to refresh
  data
• Control the exchange of intensional data (to call
  or not to call?).

4
Web services in a nutshell

• A number of standards
• XML, SOAP, WSDL, UDDI,
• Means to provide, invoke and describe remote
  functions with XML input/output.
• They make intensional documents exchangeable.

5
Context Active XML (AXML)

• A language XML with embedded service calls
• A peer-to-peer system
• Each peer
• Repository of intensional (AXML) documents
• Server provides Web services (XQuery)
• Client when invoking the embedded service calls
• And many more cool features
• distribution and replication
• continuous services
• etc.
• AXML peers exchange intensional data.

6
Outline

• Introduction
• Intensional data
• Schema-controlled exchange of intensional data
• Safe rewriting algorithm
• Conclusion

7
Intensional data
8
Materialization
lt?xml version1.0 ?gt ltnewspapergt lttitlegtLe
Mondelt/titlegt ltdategt06/10/2003lt/dategt ltcall
svcYahoo.GetTempgt ltcitygtParislt/citygt
lt/callgt ltcall svcTimeOut.GetEventsgt
exhibits lt/callgt lt/newspapergt
06/10/2003
lttempgt16Clt/tempgt
Le Monde
ltexhibitsgt ltcall svcYahoo.GetExhibitsgt
ltcitygtParislt/citygt lt/callgt lt/exhibitsgt

• Materialization replacing a service call by its
  result.
• Its a recursive process.

9
To call or not to call ?

• Materialization can be performed
• by the sender, before sending a document
• or by the receiver, after receiving it.

10
Why control the materialization of calls?

• For added functionality, e.g.
• Intensional data allows to get up-to-date
  information.
• For security reasons or capabilities, e.g.
• I dont trust this Web service/domain,
• I dont have the right credentials to invoke it,
• It costs money,
• Maybe the receiver doesnt know Active XML!
• For performance reasons, e.g.
• A proxy can invoke all the services on behalf of
  a PDA.
• and many more reasons you can think of!

11
How to control it? Using types

• We extend XML Schema, with intensional types
  XMLSchemaint

g
Data exchange schema
q
f
g
f
q
...
...
g
g
g
q
r
f
...
g
f
r
...
q
g
g
q
...
r
...
...
...
...

• Static analysis algos use signatures of services
  WSDLint

12
Schema-controlled exchange
13
The extended schema language
To simplify, we use here a DTD-like syntax

• Data
• newspaper title.date.(GetTemptemp).(GetEventse
  xhibit)
• title data
• date data
• temp data
• city data
• exhibit title.(GetDatedate)
• Functions
• GetTemp(city) -gt temp
• GetEvents(data) -gt (exhibitperformance)
• GetDate(title) -gt date

• Rewriting replace call(s) by an arbitrary
  output of the service.

14
Rewritings

• The Goal
• Given
• an intensional document d
• a schema s,
• Can we rewrite d so that it matches s?
• Safe rewriting one that for sure leads to s
• (we know without making any call).
• Possible rewriting one that possibly leads to s
  (depending on the answer of the service).

15
Difficulties

• Infinite search space
• Vertical
• Horizontal
• Main problem
• The result of a Web service call is unknown,
• We just know a signature (input/output types)
• We want a very efficient solution.
• Foundations of the problem
• tree automata,
• with existential and universal transitions.

16
Results

• Restrictions on the considered rewritings
• Left-to-right No going back and forth
• K-depth bound on the nesting of function calls
• (Search space still infinite but finitely
  representable)
• Under these restrictions
• We have algorithms to find safe/possible
  rewritings.
• They are PTIME (for deterministic schemas).
• We can also do it between schemas.
• Recent follow-up work by MSS03
• The general problem is undecidable.
• Some complexity results.

17
Safe rewriting algorithm
18
Safe rewriting algorithm

• Sketch
• Deal with function parameters,
• Traverse the tree top-down,
• For each data node, rewrite its children.

19
Rewriting the input parameters of calls

• To invoke a service, the parameters must match
  its signature.

• Start from the deepest calls

• Move recursively upward

• Finish by rewriting the document.

20
Safe rewriting algorithm

• Sketch
• Deal with function parameters,
• Traverse the tree top-down,
• For each data node, rewrite its children.

21
Rewriting a nodes children

• We have
• The children title.date.GetTemp.GetEvents
• The type to match title.date.temp.(GetEventsexhi
  bit)
• Output types of services
• GetTemp -gt temp
• GetEvents -gt (exhibit performance)
• Three steps
• Build an FSA that accepts all k-depth rewritings
  of the word.
• Build an FSA that recognizes the complement of
  the type.
• Compute their intersection to find a safe
  rewriting.
• Smarter algo in the system lazy automata
  construction.

22
Rewriting a nodes children

• accepts all k-depth rewritings of the
  word.
• This is for title.date.GetTemp.GetEvents
• Output types of services
• GetTemp -gt temp
• GetEvents -gt (exhibit performance)

date
GetEvents
GetTemp
q2
q3
?
?
?
?
temp
exhibit
performance
23
Rewriting a nodes children (2)

• is the complement automaton for the target
  type.
• Newspaper title.date.temp.(GetEventsexhibit)

GetEvents

p6


exhibit
exhibit
24
Rewriting a nodes children (3)

?
exhibit
q4,p6
q7,p5
q4,p5
performance
?
performance
exhibit
GetEvents
?
?
exhibit
performance
q3,p6
q7,p6
q7,p3
q4,p3
q7,p6
?
GetTemp
title
date
GetEvents
q1,p1
q2,p2
q3,p3
q4,p4
q0,p0
?
?
A safe rewriting exists!
title.date.GetTemp.GetEvents
title.date.temp.GetEvents
temp
q5,p2
q6,p3
25
Other algorithms (in the paper)

• Possible rewriting
• Schema compatibility
• Verifies that all instances of a schema safely
  rewrite to instances of another schema.
• Key idea It is sufficient to check a finite
  number of instance representatives.

26
Conclusion

• Schema-controlled exchange of intensional data
• Implemented as part of the Active XML system
• Fun applications
• Easy customization of Web services (VLDB03 demo)

• Types form the basis to match client preferences
• Surveillance of an AXML application (call
  tracing)
• Perspectives
• Extend with automatic data conversion
• Further optimize the algorithm (notably, for
  simple cases)

27
Shameless advertisement
Shameless advertisement

• Active XML
• a language and peer-to-peer system based on XML
  with embedded calls to Web services
• VLDB02 demo
• SIGMOD session, tomorrow morning
• http//www-rocq.inria.fr/verso/Gemo/Projects/axml
• (or google//ActiveXML)
• Lots of cool applications
• mobile computing, network configuration,
  warehouse of web resources

28
Merci
