Veritas Provisioning Manager

1
Veritas Provisioning Manager

• Technical Presentation

2
Agenda

• Challenges in Data Center Operations
• Improving Operational Practices
• Data Center Automation - Opportunities for
  Application
• Veritas Provisioning Manager
• Applying Server Build Automation
• Summary and Recommendations

3
The Expanding Datacenter
Storage
Databases AuthenticationApplications
Applications
Switches
LOB Production Subnets
Development, Test, QA Subnets
LOB Production Subnets
4
Trends In IT Architecture

• Number of Servers is growing
• Scale out Linux/Windows more servers
• Scale up partitioning more instances
• Definition of an Application is changing
• Multi-tiered applications ? SOA greater
  complexity
• More business critical applications greater
  risk
• Server virtualization emerging
• Across all server platforms more OS instances
• Moving into production greater exposure
• Shared storage is ubiquitous
• SAN/FC attached database servers more
  dependencies
• NAS/iSCSI attached middle tiers and web more
  dependencies and complexity

Environment is more distributed
Environment is more complex
Environment is more dynamic
5
Operational Consequences and Challenges

• Reactive
• Extemporized processes
• Ad-hoc builds and configurations
• Balkanized groups
• System, network, application, directory
  administrators
• Application code from many development teams
• Every group has a tool
• Jumpstart, Kickstart, NIM
• Scripts and more scripts and

• High error rates
• No baseline for support

• Everything takes longer
• SLAs missed

• Hard to maintain
• Impossible to integrate
• Hidden tribal knowledge

6
Why Automate Server Build, Rebuild, and
Configuration?

• Major source of costs, delays, errors, outages
• Unmanageable environments
• Frequent out-of-band changes drift
• Time and personnel sinks
• A process to implement
• Create standard system definitions and templates
• Capture best practices of application install and
  configuration
• Define approved processes for server build,
  migration, and changes
• Mandate out-of-band changes use standard
  practices and tools
• Implement these processes and practices as
  point-and-click
• Take single-system operations to multi-system
  operations

7
Automating a Process
OS Install / Config
hours
Automated Provisioning and Configuration
Handoff
days
Network Config
hours
Handoff
days
Database Install / Conf
hours
Handoff
days
Application(s)
hours
8
Scaling Automating a Process
Automated Provisioning and Configuration
x20
WEEKS
MINUTES
9
Agenda

• Challenges in Data Center Operations
• Improving Operational Practices
• Data Center Automation - Opportunities for
  Application
• Veritas Provisioning Manager
• Applying Server Build Automation
• Summary and Recommendations

10
VPM Functional Summary
INSTALL/CONFIGURE ADDTL. APPLICATIONS
11
Core Functions

• Image-based deployment
• Image/snapshot unattended installs
• Personalization and configuration
• Package/model-based deployment and configuration
• Applications, firmware, BIOS, device operations
• Models provide mechanism for custom configuration

• Automate process of deployment and configuration
  of servers
• Opscripts, jobs
• Automated rule-based deployment
• Integrated VLANs operation

12
VPM How It Works
VPM Master Server
Managed Servers

• Solaris
• Windows
• Red Hat Linux

Web UI
VPM Agents

• Bare metal agent (AOS)
• OS Agent (ITAP)
• Windows, Red Hat, SUSE, Solaris, AIX

Repositories
Database

• CIFS
• NFS

• Embedded, or
• Oracle 9i, 10g

13
Key VPM Characteristics

• Based on standard network protocols
• No separate DHCP, tftp, or OS vendor servers
  required
• Single web-based UI for all platforms
• Bare-metal RAM OS (Active OS, Linux kernel for
  x86, Solaris for SPARC, AIX for Power) for
  snapshot/image save/deploy/compress and bare
  metal operation
• ITAP agent for personalization, package
  deployment, server comparisons
• Packages can do anything a command line or shell
  can do.
• Plus parameterization (variables), file/registry
  edits, constraints
• Distributed repositories for speed and
  scalability
• Fine-grained role-based administration
• Automatic rule-driven and best-fit provisioning

14
Why Image-based Provisioning

• Image snapshots
• Typically 15-20 minutes
• AOS (Active OS) is an architecture-specific
  RAM-resident OS
• AOS understands volumes and file system
• File, smart-sector, sector-mode
• AOS creates correct geometry, applies to new
  disk(s)
• Volume, partition, filesystem information
• Personalization customizes image for new
  environment
• Each OS instructed to scan and reconfigure
  devices (implementation is OS-specific)
• Hostname, IP address, other required network
  information
• AOS takes a snapshot in multiple layers
• Incremental snapshots
• Fast, efficient, complete, portable across
  systems

15
VPM Software Packages and Models

• Software deployment and configuration
• Complements image snapshots
• Powerful basis for extensible automation
• Package construct contains software, scripts,
  data,
• Model contains variable or parameterized
  information for installation instance
• Attached to package

16
Provisioning Manager Software Packages and Models

• Uses for package and models
• Install, uninstall and modify software, patches,
  any arbitrary entity
• Repeat a common system management task
• Issue any CLI commands or scripts
• Perform any of the above on multiple servers
  simultaneously
• A software package may contain
• CLI command, CLI script, executables, files
• Anything you can think of
• Attached Models
• Models define parameters (variables) for software
  packages
• Pre configuration commands (e.g. purge
  directories)
• Parameters (typed and checked - INT, float,
  string, IP address, password, directory etc)
• Can be mandatory, defaulted, prompted
• Post configuration commands (e.g. start dependent
  programs)
• Object modification (Any file, test files,
  XML,INI, INF, IIS DB, and registry)
• Replaces manual edits and errors

17
Provisioning Manager Leveraging Automation
Console

• Operations needs to install and reconfigure three
  application packages on fifty servers

Web Server
Provisioning Manager
Servers
Repositories
18
Provisioning Manager Start Processes
Console

• Operator uses browser UI to select three software
  packages, then select fifty servers, clicks
  Start

Web Server
Provisioning Manager
Servers
Repositories
19
Provisioning Manager Parallel Execution Begins
Console

• VPM automatically assembles task list and begins
  process on fifty systems

Web Server
CMD Deploy Packages XYZ
Provisioning Manager
Servers
Repositories
20
Provisioning Manager Unattended Management
Console

• To fifty servers, in parallel
• READ packages XYZ
• Perform edits
• Perform configuration
• Perform commands

Web Server
Provisioning Manager
SW
SW
SW
SW
Servers
Repositories
21
Capturing Processes in VPM

• OpScripts and jobs
• GUI created sequence of commands
• Created by architect or administrator, used by
  operators
• No coding or scripting!!
• Can be auto-triggered
• Date and time
• A VPM Event (Like Start Up Server Successful or
  New Server Auto-discovered)
• An SNMP Trap
• Combine with provisioning policies

22
VPM Major Components
Web Browser
Web-based Console
Logic
VPM Server
Database
Repository
Execution and Logging
Repository
ITAP Agent
ITAP Agent
ITAP Agent
Managed Assets
Switches
SPARC (Solaris)
x86 (Windows/Linux)
PowerPC (AIX)
23
Agenda

• Challenges in Data Center Operations
• Improving Operational Practices
• Data Center Automation - Opportunities for
  Application
• Veritas Provisioning Manager
• Applying Server Build Automation
• Summary and Recommendations

24
Test and Development Operations

• Problem
• Constantly changing software configurations
• Systems need to built and rebuilt continually
• High sysadmin requirements to meet needs
• Manual operation leads to high error rates
• Lack of responsiveness impacts productivity
• VPM functions
• Fast, simple, automated build and rebuild
• Reduces admin workload for standardized tasks
• Reduces errors and improves supportability
• Increases developer productivity

25
VPM in Disaster Recovery Repurposing Operations

• Problem
• Full replicated DR site is expensive
• Building DR failover on-the-fly is slow and
  unreliable
• VPM function
• Re-use your Test/Dev resources for DR.
• Document and capture your best deployment
  practices, then on demand
• Snapshot current Test/Development suite
• Deploy base production snapshots
• Use VPM restore, SAN or NAS for application
  install
• Attach to SAN, NAS, replicated mirrors, etc for
  volatile data
• Go
• Many designs / scenarios are possible
• Avoid replicated hardware suite costs
• Improve response time and SLAs
• Reduce errors and improve supportability

26
Operational Challenges in Redeploying
Applications and Servers

• Problem
• Moving applications from server to server is
  tedious, slow, error prone
• Migration of data centers or deployment of new
  servers magnifies problem
• Almost impossible to ensure ALL characteristics
  of an application are captured and replicated
• VPM function
• Pick up a snapshot and drop it on a different /
  new platform
• Imaging technology platform personalization
  parameter-based customization simple and
  complete re-deployment
• Imaging is dramatically faster than
  script/media-based alternatives
• Accuracy and completeness of migration
• Reduce errors and improve supportability

27
Deploying or Reconfiguring Large Numbers of
Applications

• Problem
• What if you have 200 SAP applications you need
  to keep updating?
• Or constantly changing content that needs to be
  pushed to a hundred servers?
• Slow, unresponsive, error prone, consumes
  resources
• VPM function
• Standardization and automation of deployment
• Speed deployment, cut errors, reduce costs,
  improve supportability, improve responsiveness,
  meet SLA goals

28
More examples

• Create standardized golden server build and
  push to subsidiary sites
• Known characteristics supportable
• Simple deployment time saved
• Rebuild 20 servers with X OS Y patches Z
  applications
• Select and go
• QA engineer needs to test
• OS version A, Service Pack B, Database C,
  Application D
• Selects free asset, relevant snapshots and
  packages, click go
• Test needs to run destructive test of
  multi-tiered application
• Snapshot all servers
• Run tests
• Restore snapshots
• Minimal hands-on

29
Summary

• Current server build and configuration is
• Too complex, resource-intensive, slow,
  error-prone, no control / audit
• Process, practice, tools exist to remediate
  server build and configuration problems
• Examine process and practice, formally document
  them
• Applicable VPM capabilities
• Image-based provisioning for speed and accuracy
• Software packages and models for flexibility and
  customization
• Opscripts and jobs for capture of best practices
  as process
• Integrated VLAN control for single-step
  provisioning

30
Recommendations

• Implement simple snapshot provisioning and
  reprovisioning
• VPM uniquely suited for quick implementation
• Begin embedding processes in VPM operations
• Architect specifies process
• System administrator puts process in VPM using
  GUI tools
• Operator uses VPM in day-to-day operation
• The Result
• Fast, low-overhead, efficient server build and
  configuration
• Fixes the problem you have, not the theory
• Avoids the overhead and failures of lifecycle
  management

31
Practical Centralized Automation
One Interface to All Platforms
Simple to Implement
Automated Provisioning
Fast and Accurate
Flexible and Extensible
No Additional Specialized Servers Required
32
Thank you
