OLAP

1
OLAP

• CS 543 Data Warehousing

2
Where Does OLAP Fit In? (1)

• OLAP On-line analytical processing.
• OLAP is a characterization of applications, not a
  database design technique.
• Idea is to provide very fast response time in
  order to facilitate iterative decision-making.
• Analytical processing requires access to complex
  aggregations (as opposed to record-level access).

3
Where Does OLAP Fit In? (2)

• Information is conceptually viewed as cubes for
  simplifying the way in which users access, view,
  and analyze data.
• Quantitative values are known as facts or
  measures.
• e.g., sales , units sold, etc.
• Descriptive categories are known as dimensions.
• e.g., geography, time, product, scenario (budget
  or actual), etc.
• Dimensions are often organized in hierarchies
  that represent levels of detail in the data
  (e.g., UPC, SKU, product subcategory, product
  category, etc.).

4
OLAP FASMI Test

• Fast Delivers information to the user at a
  fairly constant rate. Most queries should be
  delivered to the user in five seconds or less.
• Analysis Performs basic numerical and
  statistical analysis of the data, pre-defined by
  an application developer or defined ad hoc by the
  user.
• Shared Implements the security requirements
  necessary for sharing potentially confidential
  data across a large user population.
• Multi-dimensional The essential characteristic
  of OLAP.
• Information Accesses all the data and
  information necessary and relevant for the
  application, wherever it may reside and not
  limited by volume.
• ...from the OLAP Report by Pendse and Creeth.

5
Need for Multidimensional Analysis

• A simple analysis
• How many units of product A did we sell in the
  store in DHA, Lahore
• Typically, decision support requires more complex
  analyses
• How much revenue did the new product X generate
  during the last three months, broken down by
  individual months, in the Southern Region, by
  individual stores, broken down by the promotions,
  compared to estimates, and compared to the
  previous version of the the product?

6
Kinds of Analyses

• Roll-ups to provide summaries and aggregates
  along the hierarchies of the dimensions
• Drill-downs from the top level to the lowest
  along the hierarchies of the dimensions
• Calculations involving facts and metrics
• Algebraic equations involving key performance
  indicators
• Moving averages and growth percentages
• Trend analyses using statistical methods

7
(No Transcript)
8
(No Transcript)
9
OLAP?

• The name On-Line Analytical Processing was coined
  in a paper by E.F. Codd in 1993 (Providing
  On-Line Analytical Processing for User Analysts)
• A definition
• OLAP is a category of software technology that
  enables analysts, managers, and executives to
  gain insight into data through fast, consistent,
  interactive access in a a wide variety of
  possible views of information that has been
  transformed from raw data to reflect the real
  dimensionality of the enterprise as understood by
  the user

10
OLAP Features
11
Dimensional Analysis (1)
12
Dimensional Analysis (2)
13
Some Queries

• Display the total sales of all products for past
  five years in all stores
• Compare total sales for all stores, product by
  product, between years 2000 and 1999.
• Show comparison of sales by individual stores,
  product by product, between years 2000 and 1999
  only for those products with reduced sales.
• Show the results of the previous queries, but
  rotating the columns with rows

14
Hypercubes

• Multi-dimension cubes
• Hard to visualize and display beyond three
  dimensions
• Multi-dimensional domain structure (MDS)
• Represents each dimension as a line showing the
  values

15
MDS
16
Display of Hypercubes
17
(No Transcript)
18
(No Transcript)
19
Drill-Down and Roll-Up
20
Slice-and-Dice or Rotation
21
OLAP Models/Implementations

• MOLAP OLAP implemented with a multi-dimensional
  database.
• ROLAP OLAP implemented with a relational
  database.
• HOLAP OLAP implemented with a hybrid of
  multi-dimensional and relational database
  technologies.
• DOLAP OLAP implemented for desktop decision
  support environments.

22
ROLAP and MOLAP
23
MOLAP Implementations

• OLAP has historically been implemented through
  use of multi-dimensional databases (MDDs).
• Dimensions are key business factors for analysis
• geographies (zip, state, region,...)
• products (item, product category, product
  department,...)
• dates (day, week, month, quarter, year,...)
• Very high performance via fast look-up into
  cube data structure to retrieve pre-calculated
  results.
• Cube data structures allow pre-calculation of
  aggregate results for each possible combination
  of dimensional values.
• Use of application programming interface (API)
  for access via front-end tools.

24
(No Transcript)
25
MOLAP Implementations

• Need to consider both maintenance and storage
  implications when designing strategy for when to
  build cubes.
• Maintenance Considerations Every data item
  received into MDD must be aggregated into every
  cube (assuming to-date summaries are
  maintained).
• Storage Considerations Although cubes get much
  smaller (e.g., more dense) as dimensions get less
  detailed (e.g., year vs. day), storage
  implications for building hundreds of cubes can
  be significant.

26
MOLAP Implementations

• Typically outperform relational database
  technology because all answers are pre-computed
  into cubes (and overhead for accessing cubes is
  very low).
• Difficult to scale because of combinatorial
  explosion in the number and size of cubes when
  dimensions of significant cardinality are
  required.
• Beyond tens (sometimes small hundreds) of
  thousands of entries in a single dimension will
  break the MOLAP model because the pre-computed
  cube model does not work well when the cubes are
  very sparse in the population of individual
  cells.
• See www.olapreport.com/DataExplosion.htm

27
Virtual Cubes

• Virtual cubes are used when there is a need to
  join information from two dissimilar cubes that
  share one or more common dimensions.
• Similar to a relational view two (or more) cubes
  are linked along common dimension(s).
• Often used to save space by eliminating redundant
  storage of information.

28
Partitioned Cubes

• One logical cube of data can be spread across
  multiple physical cubes on separate (or same)
  servers.
• The divide-and-conquer approach of partitioned
  cubes helps to mitigate the scalability
  limitations of a MOLAP environment.
• Ideal cube partitioning is completely invisible
  to end users.

29
ROLAP Implementations

• Advances in database technologies and front-end
  tools have begun to allow deployment of OLAP
  using ANSI SQL RDBMS implementations.
• ROLAP facilitates deployment of much larger
  dimension tables than MOLAP implementations.
• Front-end tools to facilitate GUI access to
  multi-dimensional analysis capabilities.
• Aggregate awareness allows exploitation of
  pre-built summary tables for some front-end
  tools.
• Star schema designs are often used to facilitate
  OLAP against relational databases.

30
(No Transcript)
31
Simplified Third Normal Form (Retail)
32
Simplified Star Schema
33
Simplified Star Schema

• A vastly simplified physical data model!
• Collapse dimensional hierarchies into a single
  table for each dimension and create a single fact
  table from the header and detail records
• Fewer tables.
• Fewer joins to get results.

34
Star Schema for High Performance

• Business question How many in raincoats did I
  sell in the first week of January through stores
  in Boston?
• Assume
• 4 Billion rows in fact table.
• 20 different kinds (size, color, style) of
  raincoats (product category) out of 50,000 UPCs
  in store.
• 8 stores out of 400 are in BOSTON SMSA.
• 2 years of POS history in DBMS.

35
Star Schema for High Performance

• Simple (poor performance) approach to query
  execution
• 1. Join item table with filtering on raincoat
  product category (very selective) to fact table.
• 2. Join date table with filtering by week (next
  most selective) to result table.
• 3. Join store table with filtering on store to
  result table from step 2.
• 4. Aggregate.

36
Star Schema for High Performance

• Advanced (better performance) approach to query
  execution
• 1. Cartesian product join between dimensional
  tables.
• Result is 20 x 8 x 7 1,120 rows.
• 2. Use composite index on itemstoreday into
  fact table for very selective access.
• Access less than 0.00000008 percent of data in
  fact table!
• Sophisticated cost-based optimizers will figure
  this out.

37
Forcing a Cartesian Product Join

• Add an addition join_value column in each
  dimensional table.
• Set join_value to same value in all rows of the
  dimensional tables.
• Add additional where clause predicates joining on
  this column between dimensional tables.
• NOTE This shouldn't be necessary with a smart
  optimizer.

38
Forcing a Cartesian Product Join

• Sample code
• select sum(sales.sales_amt)
• from d_sales_detail
• ,store
• ,item
• ,period
• where d_sales_detail.store_id store.store_id
• and d_sales_detail.item_id item.item_id
• and d_sales_detail.day_dt period.day_dt
• and period.day_dt between '23-NOV-2000' and
  '24-DEC-2000'
• and item.trade_style_cd 'BARBIE'
• and store.state_cd 'CA'
• and store.join_value period.join_value
• and store.join_value item.join_value
• and period.join_value item.join_value

39
Star Schema for High Performance

• Problem What if I want to know raincoat sales
  in first week of January regardless of store?
• Answer Performance advantage of composite index
  in traditional RDBMS is severely impaired!
• B-tree indexing techniques do not allow for
  flexibility in the use of dimensions for query
  purposes.
• Bit indexing (and variations thereof) often
  allows much more generality in achieving high
  performance from a star schema.

40
Star Schema for High Performance

• Bottom Line
• It is not at all unusual to obtain an order of
  magnitude (or more) in performance advantage
  using a star schema with advanced indexing versus
  a more traditional relational database
  implementation.
• Despite what vendors may tell you, star schemas
  cannot be effectively implemented for all DSS
  business applications and/or data models.

41
ROLAP

• Relational OLAP often makes heavy use of summary
  tables to provide near instantaneous access for
  multi-dimensional queries.
• Foundation is usually star schema or snowflake
  database design.
• Allows OLAP with much larger data sets than
  multi-dimensional database (MDD) products using
  cube structures (MOLAP).

42
ROLAP

• Number of summary tables can get very large if
  discipline is not enforced...
• Assume a retail database with the following two
  dimensions on the fact table...
• Calendar Day, Week, Period, Quarter, Year, All
  Days
• Geography Store, Zone, District, Region, All
  Stores

43
ROLAP
Summary tables in a naive implementation require
all combinations of the dimensions at each
aggregation level...
30 summary tables! ... Add in item, SKU,
subcategory, category, and all items...now we are
up to 150 pre-aggregates!
44
ROLAP

• Summary tables are more of a maintenance issue
  than a storage issue in most production
  implementations.
• Notice that summary tables get much smaller as
  dimensions get less detailed (e.g., year vs.
  day).
• Should plan for double the size of the
  unsummarized data for ROLAP summaries in most
  environments.
• Every detail record that is received into
  warehouse must aggregate into EVERY summary
  table (assuming "to-date" summaries are
  maintained).

45
ROLAP

• Warning Do not assume that dimensions are
  always simple hierarchies.
• Example Items are not just category,
  subcategory, SKU, and atomic item.... what about
  trade styles or manufacturer?
• Now we need summary tables along these lines as
  well...another 120 summary tables!
• Calendar vs. accounting period vs. billing cycle
  can be even worse...

46
ROLAP

• Many ROLAP products have devised ways to reduce
  the number of summary tables
• Ability to build summaries on-the-fly as demanded
  by end-user applications.
• Ability to aggregate efficiently from subset of
  the summary tables.
• Tools exist in some products to assist in DBAs in
  selecting the "best aggregations to build.
• HOLAP (Hybrid OLAP) tools allow co-existence of
  pre-built cubes alongside relational OLAP
  structures.

47
Intelligent Aggregation Selection

• Maximum performance boost implies lots of disk
  for every pre-calculation.
• Minimum performance boost implies no disk with
  zero pre-calculation.
• Strategy is to use meta data to heuristically
  determine optimum set of aggregates from which
  all other aggregates can be derived.

48
Aggregate Wizards
49
Fact Table Aggregates

• Enhance performance on common queries at coarser
  granularities.
• Save space to permit storing more history than
  possible with finer granularities.
• Take advantage of need to store other facts (with
  similar samples) at a particular granularity.

50
Aggregate Advice

• Coarser granularity decreases potential
  cardinality, but usually increases density (e.g.,
  daily summary table is typically twice the size
  of weekly summary table - not seven times).
• Strongly consider omitting candidate aggregates
  where expected cardinality is more than 10 that
  of next finer granularity stored.
• Keep the detail for drill down, even if you
  deploy aggregates for performance.

51
Bottom Line

• There are many implementation techniques for
  delivery of an OLAP environment.
• Must fully consider the performance, scalability,
  complexity, and flexibility characteristics when
  deciding between MOLAP, ROLAP, and HOLAP.
• Understand your tools and RDBMS!

52
MOLAP Vs. ROLAP
53
Implementation Issues

• Data design and preparation
• Administration and performance
• OLAP platforms
• OLAP tools and products

54
Data Design and Preparation

• Characteristics of data
• Stores and uses much less data compared to a DW
• Data is summarized. You will rarely find data at
  the lowest levels of detail as in the DW
• Data is more flexible for processing and analysis
  partly because there is much less data to work
  with
• Every instance of the OLAP system in your
  environment is customized for the purpose that
  instance serves
• OLAP data is generally customized
• Types and levels
• Static and dynamic summary data
• Permanent and transient detailed data

55
Administration

• Administering and managing OLAP systems should be
  handled with that of the DW environment
• Some considerations
• Expectations on what data would be accessed and
  how
• Selection of the right business dimensions
• Selection of the right filters in loading data
  from the DW
• Choosing the aggregation, summarization, and
  precalculation
• Size of the multidimensional database
• Access and security privileges
• Backup and restore facilities
• Drill-through to the data warehouse
  drill-through to another OLAP instance

56
Performance

• OLAP takes most of the queries that normalling
  would run against the DW
• OLAP is designed for complex queries so it
  should enhance overall query performance of the
  DW environment
• OLAP can precalculate and pre-aggregate data for
  quick response

57
OLAP Platforms

• Usually, the data warehouse and OLAP systems
  reside on the same platform in the start. Later
  when the data warehouse becmes large and OLAP is
  a common task, OLAP system is moved to another
  platform
• A separate platform is needed when
• The size and usage of the DW consumes all
  resources
• Many departmental users desire OLAP capabilities
• The stability and performance of OLAP degrades
• OLAP tools require a different platform
  configuration than the DW
