CAA HUMS Research Project Meeting 16th March 2006

1
CAA HUMS Research Project Meeting16th March 2006

• Presentation by Brian Larder, Rob Callan, Lorry
  Stoate

2
Agenda

• Minutes of 20 October meeting (accuracy and
  actions)
• Overview of activities since last meeting
• Anomaly detection process development model
  information extraction
• Presentation and demonstration of the results of
  the off-line data analysis (phase 1)
• Review of live trial system development
• Additional fault data?
• End of phase 1 report
• Planning of live trial (phase 2)
• HUMS for rotor systems
• AOB
• Date of next meeting

3

• Overview of activities since last meeting

4
Overview of activities since last meeting

• We have produced a software tool to manage the
  configuration for generating anomaly models
• Specifying data source, model storage, model
  parameters, input indicators, etc was very
  tedious and holding back efficient progress
• This tool allows the analyst to define a set of
  tasks that are then stored and executed as batch
  process
• Tasks can also be placed on different available
  machines which is important because each task
  takes a lot of CPU time

5
Overview of activities since last meeting

• Model Building
• Models have been built for all main, tail,
  intermediate and accessory gears
• Fitness score predictions have been produced for
  all data
• A lot of analysis has been undertaken to review
  the models (see later sections)
• Alerting threshold
• The strategy for setting a threshold for anomaly
  alerts has been studied in some detail
• We have implemented an alerting strategy but this
  will need reviewing based on feedback
• Development of the live trial system
• To be demonstrated later

6

• Anomaly detection process development model
  information extraction

7
Anomaly detection process development model
information extraction

• There are three key elements to anomaly detection
• Data pre-processing
• Used to emphasis data characteristics that are
  considered important such as trends
• This can be difficult but it is a critical stage
• Pre-processing can be considered as tagging the
  data as interesting or not interesting
• Anomaly modelling
• Main function is to highlight data of interest
  and to emphasise its significance
• For HUMS data, model training needs to be robust
  to anomalous training
• In other words, the training data will contain
  anomalies due to sensor and general
  instrumentation problems that occur in practice
• Alerting strategy
• Defining the events that lead to flagging the
  operators attention

8
Anomaly detection process development model
information extraction

• Alerting strategy
• The predicted fitness scores from the training
  data have been used to generate alerting
  thresholds (one per model)
• The threshold is not based on a mean value plus
  so many standard deviations
• The fitness scores do not follow a normal
  distribution
• The strategy has been to examine the fitness
  scores using a statistical plot that can assist
  with identifying different regions of density
• The idea is to set the threshold at a point where
  there is change in density
• The point should also lie towards the end of the
  cumulative distribution (i.e. such that the
  majority of data will not be in alert)
• Whilst the modelling is robust to anomalies in
  the training data, the threshold will be affected
  by the quality of the training data
• This strategy will be used in the live trial but
  we need the live trial experience to refine it

9

• Presentation and demonstration of the results of
  the off-line data analysis (phase 1)

10
Model Assessment

• The Anomaly modeling is the most complex element
  in the three stage process
• The technology is independent of the other two
  stages of pre-processing and alerting
• In our view it should provide more than a
  mechanism to flag anomalous data
• It should provide an insight into the large
  data picture
• We have addressed the following questions
• Does it do what it is designed to do?
• What benefits does it bring?
• The answers to these questions will be
  illustrated throughout todays presentation
• It will become apparent that HUMS will clearly
  benefit from the application of the anomaly
  processing
• In our view, there is a proven need for this type
  of technology

11
Model Assessment

• The overall objective for the anomaly detection
  technology can be summarized by the following
  requirement
• Anomaly models will be built from data that
  contain an undefined percentage of anomalies. The
  models should recognize outlying training data.
  The models response to outliers should be
  adaptive via configurable tuning humans have to
  attach value to the anomalous information
  provided (i.e, ability to configure the alerting
  rate and trade off between false positives and
  costs)
• What has been done to test the success of this
  objective (and to answer the questions from the
  previous slide)?
• Models have been built for all 35 shafts (main,
  tail, intermediate and accessories)
• Resulted in 140 models
• Absolute and trend X 2 (8 indicators and M6)
• Fitness predictions have been produced against
  all of these models for
• Training, validation and current data

12
Model Assessment

• What has been done to test the success of this
  objective (and to answer the questions from the
  previous slide)?
• The training data approximates to about half that
  available
• For example, the training data contained 60 main
  gearboxes but in total there are now 115
• The validation data contains those gearboxes
  whose data were acquired before April 2004 and
  were not used for training
• The current data consists of the current fleet
  and there will be some overlap with the
  validation data (where current components were in
  service before April 2004)
• The models have produced a huge amount of
  information and it is impossible to analyze all
  of this in the time available
• A selection of models have been explored in
  detail
• We have directed most of our attention at the
  current fleet

13
Model Assessment

• Before proceeding with a review of the findings
  we need to keep in mind a few points
• The models have been built in a one-off process
• There has been no tuning but we have always
  stated there will be a need for this following
  the review and during the live trial
• Initially we were struck by the quantity of low
  fitness scores being produced by the models and
  thought the model adaptation was probably too
  aggressive
• In some models this is true (hence the need for
  the ability to re-tune) but in most cases the
  modeling is pointing to genuinely outlying data
  there happens to be a lot of it!
• We can only re-tune once we have discussed some
  representative cases and established an initial
  policy of how we want the system to respond
• Some low fitness scores are misleading
• This is not a modeling issue and it originates in
  the trend data pre-processing where there has
  been a step change because of maintenance to
  correct high vibration

14
Model Assessment

• Does the anomaly modeling fundamentally work?
• The ProDAPS modeling diagnostic tool has been
  used to explore model content and features
• Anomalous fitness scores have been reviewed
  against the condition indicators (mainly covered
  in a later section)
• Model diagnostics
• The model diagnostics tool extracts a range of
  information and we shall see some of this
• We have taken all of the 8 indicator models for
  the main gearbox and extracted what we call
  coverage statistics
• Basically we ask the model for a fleet view on
  all of the indicators
• Sometimes the coverage shows that the tuning is
  too aggressive but often it illustrates that the
  modeling is doing a far superior job of
  representing the data than can be achieved using
  traditional parametric statistics
• An example follows

15
Model Assessment

• The top chart shows a plot of the absolute values
  for FSA_SO1 from the training data on the Stbd
  Aft Fw
• The bars show a histogram of the data and whilst
  the bulk of the data approximates a normal
  distribution it contains a very long tail
• The red line is the distribution computed from
  the data
• A single mode fleet distribution is a poor model
  of the data
• This effect is repeated over many indicators and
  models
• The histogram shows what looks to be a central
  distribution that is extended with a lot of
  outlying data
• The chart at the bottom shows the output of a
  ProDAPS cluster model
• This illustrates the impact of the outlying data
• ProDAPS indicated that it would take in the order
  of 17 distributions to provide a good model of
  this data
• The anomaly models are built using 8 indicators
• Ideally we would like the model to target the
  outlying data and find the distribution that
  characterises the main fleet
• This is a very difficult challenge but it is the
  core objective we have set for the anomaly
  modelling

16
Model Assessment

• The chart on the left is the fleet distribution
  that has been identified by the model
• It is clearly much more representative of the
  fleet data
• It has clearly targeted outlying data
• The diagnostic tool can also take the fleet
  statistics and produce what we call a global fit
• For a component, the global fitness scores can
  look similar to the anomaly fitness scores but
  often they will contradict
• The global fits in conjunction with the anomaly
  fits can be very informative
• We shall illustrate the global fit for FSA_SO1 on
  the Stbd Aft Fw and show what is driving the
  outliers

17
Revisit the Bevel Pinion fault case

• The global fitness on the Bevel Pinion case
  reveals some interesting information
• If we examine the absolute indicators for all
  data
• FSA_GE22 is the highest for this fault component
• FSA_SON is suppressed
• FSA_MS_2 does not look significant
• The diagnostics show, that although FSA_GE22
  reaches the highest value of all data seen to
  date it is almost impossible to attach any
  significance to the trend when doing a simple
  fleet comparison
• On the other hand
• The anomaly model, shows the significance on both
  the absolute and trend models
• In terms of the absolute model
• FSA_MS_2 and FSA_GE22 are significant (see next
  slide)
• In terms of the trend model
• FSA_GE22 and FSA_SON are significant

18
Revisit the Bevel Pinion fault case

• The global fitness on the Bevel Pinion case
  reveals some interesting information
• The ProDAPS model diagnostics can indicate which
  indicators are driving the low fitness
• The plot to the right shows that FSA_MS_2 is more
  significant than FSA_GE22 in terms of absolute
  values
• This is lost in the fleet statistics

19
Model Assessment

• Review of selected cases based on current fleet
  data

20
Fan 15 blades
21
Accelerometer n8 (12RK1)
Accelerometer n10 (12RK3)
Accelerometer n11 (14RK1)
Accelerometer n12 (14RK2)
Accelerometer n13 (12RK4)
Accelerometer n14 (12RK5)
Accelerometer n15 (18RK1)
Accelerometer n16 (18RK2)
22
Recommendations for future research

• The activities of research and development often
  highlight the need for further work
• Pre-processing
• There is a great deal of variability in HUMS data
  (e.g. due to various maintenance actions)
• This variability could mask important trends
  because the trend pre-processing as it currently
  exists does a form of differencing and it does
  not distinguish between a developing trend and
  step change or ocurrence of noise in the data
• Model tuning
• The application of this technology is very new
  and we need the trial experience to refine the
  models
• Probabilistic alerting policy
• It is unrealistic to set a hard threshold to
  demarcate the interesting from the
  non-interesting
• We need a point at which an alert is triggered
  but we also need a type of anomaly index
• There could be a tendency to interpret fitness
  scores in a manner similar to reading a linear
  temperature scale but the distribution is not
  linear
• A probabilistic measure is more appropriate
• A probabilistic measure would also normalise the
  anomalies and assist with reasoning across shafts

23
Recommendations for future research

• The the activities of research and development
  often highlight the need for further work
• Data mine the features of anomalous trends to
  test theoretical models
• ProDAPS diagnostics can point to the indicators
  that are driving trends
• It would be informative to mine these features to
  test established diagnostic knowledge and develop
  this
• Reasoning
• More directed information could be provided by
  reasoning with anomaly outputs
• Fuse information across shafts to identify
  instrumentation issues
• Reason about the nature of the anomaly trends
  vs high variability vs step changes etc
• Reason about the indicators driving the trend to
  provide more detail on the significance of
  anomalies
• Case-based reasoning to search for any similar
  previous cases

24

• Review of live trial system development

25
Web-based anomaly detection system architecture

• The anomaly detection system will operate as a
  secure web server, located at Smiths in
  Southampton.
• HUMS data is automatically transferred overnight
  from Bristows Web Portal to Southampton
  (Working).
• The HUMS data is imported into the anomaly
  detection systems data warehouse and analysed
  overnight (Working).
• Bristow have a remote login to the system to view
  results at any time via a web browser (Tested).

26
Summary of major activities and findings

• Live trial system development
• Activities
• Development of software components for live trial
  system
• Overnight Data processing
• Complete data flow (including Alerting) has
  been working daily since 16th February 2006.
• Management of documentary data (gearbox changes,
  recording of trial findings etc.) still to be
  implemented.
• User Interface (UI) -
• A Basic navigation is in place (drill down).
• An Annotation strategy demonstrable.
• Acknowledging Alerts demonstrable.
• Historical Search strategy identified.
• Speed of connection, and practicality tested with
  Bristow.
• Findings
• We have addressed all potential areas of risk in
  the data processing and UI.
• We still have some features of the UI to complete
  for the live trial.

27

• Additional fault data?

28
Sources of fault data for system testing

• BHL AS332L IHUMS data
• Large quantity of historical data.
• With BHL investigation of IHUMS indicator trends
  related to anomaly detection results, it is
  possible to perform a good assessment of anomaly
  detection capabilities using the existing data
  set.
• CHC Scotia AS332L IHUMS data
• Data for cracked AS332L bevel pinion.
• WHL AS332L MGB data from CAA seeded defect test
  programme
• Documentary information on this received from
  WHL.
• Limited analysis coverage, but some fault related
  trends could be obtained.
• Difficulties obtaining data from WHL.

29

• End of phase 1 report

30

• Planning of live trial (phase 2)

31
Plan for 6 month trial

• Tasks to be completed prior to start of 6 month
  trial
• Completion of User Interface software
• Model tuning / Data re-modelling
• Definition of BHL operational procedures
• Daily review of anomaly detection
• Feedback from follow-up of review
• Reporting of faults, component changes and
  maintenance actions
• System problem reporting
• Definition of Smiths support procedures
• Database update following component changes
• Investigation of reported system problems and
  anomaly model behaviour
• Configuration control for any model tuning
• Trial start date
• Forecast for mid May
• Trial performance assessment
• Project review meeting after first month of
  operations?
• Decision on trial extension

32

• HUMS for rotor systems

33
HUMS for rotor systems

• Contract amendment received from CAA on 18
  January
• Obtaining University support for study
• Selection of University of Glasgow (including
  rotorcraft group from Imperial College London,
  led by Dr Richard Brown.)
• Arrangement of Confidentiality Agreement
• Agreement of SOW (focus on literature review,
  mathematical modelling and laboratory test
  facilities)
• Signing of a Research Agreement
• Project start
• Planned start date 3rd April
• Planned Smiths resources
• BDL Project management and liaison with UoG
• SS Accident data review
• REC Application of machine learning techniques
• DLG Mathematician support

34

• AOB and date of next meeting
