Genetic Programming and Genetic Algorithms

1
Genetic ProgrammingandGenetic Algorithms

• General Introduction

2
Introduction

• This series of lectures tries to cover the area
  of search from a different perspective.
• We first observe that every program is a
  function, from a domain to a range a program
  takes an input from an acceptable set of inputs
  and generates an output (side-effects could be
  part of the output). Sometimes the program is
  aware of the exact set of acceptable inputs -
  and reacts appropriately to inputs outside that
  set most of the time such awareness is limited
  and so the function the program corresponds to
  may produce unpredictable (or undesirable)
  input-output pairs outside a small part of the
  possible set of inputs.

3
Introduction

• If the function can be represented in terms of
  already known functions either in terms of
  algebraic formulae or in terms of exact (domain,
  range) pairing rules, we can describe the
  function explicitly and we can end with a program
  for computing the input-output relation.
• If the function cannot be so represented, we have
  a problem
• If the function CAN be so represented, we may
  still (and, with high probability, do) have a
  problem (NP-Complete, anyone?)
• Can we solve the problem(s)?
• The answer will be, by and large, NO, BUT

4
Introduction

• If we do not have explicit rules to take us from
  an input to an output, what can we expect to
  have?
• A finite collection of valid input-output pairs
• A way of evaluating whether a collection of
  input-output pairs produced is more or less
  desirable than some other collection of pairs
  with the same input components
• A way of evaluating when our process of function
  construction can stop, either because we are not
  generating better functions or because some
  other cost (time or space) is becoming
  unacceptable.

5
Introduction

• In some instances, we have a function and we are
  trying to find an input-output with some desired
  characteristics - e.g., a maximum, a minimum or a
  saddle-point of the function. If the function is
  given with a simple analytical form, Calculus
  techniques may be adequate. If the function is
  given in a very complex form (or, at least, not
  amenable to simple analytic techniques), an
  intelligent search (using known properties of
  the function to reduce the search space) may be
  the only available strategy.

6
Introduction

• One of the early results was obtained by
  McCulloch and Pitts (starting in the 1940s) via
  their study of perceptrons input-output networks
  with an input layer of nodes connected to an
  output layer of nodes.
• By the late 1960s this setup had been shown to
  be inadequate to represent useful functions
  (e.g. XOR) (Minsky and Papert, Perceptrons, MIT
  Press, 1969). Later on, other people showed that
  the introduction of a third layer was adequate
  for the approximation of any desired
  well-behaved function the level of
  approximation was tied to the number of nodes in
  this intermediate layer.
• More specifically, we have

7
Introduction

• The Universal Approximation Theorem. Let f() be
  a non-constant, bounded and monotone-increasing
  continuous function on R. Let Ip denote the
  p-dimensional closed unit hypercube 0, 1p. Let
  C(Ip) denote the space of continuous functions Ip
  --gt R. Then, given any function f Î C(Ip) and e
  gt 0, there exists an integer M and sets of real
  constants ai, qi and wij, where i 1, , M and j
  1, , p, such that we may define as
  an approximate realization of the function f()
  that is, F(x1, , xp) - f(x1, , xp) lt e
  for all (x1, , xp) Î Ip.
• Proof. See the references in Simon Haykin,
  Neural Networks, a Comprehensive
  Foundation,Macmillan, 1994, pp. 181-182. (There
  is a second edition out)

8
Introduction

• We can observe
• the logistic function 1/1 exp(-v) used as
  the nonlinearity in a neuron model satisfies the
  conditions on f() above
• the network can be thought as having p input
  nodes and a single hidden layer with M neurons
  the inputs are x1, x2, , xp
• the hidden neuron i has synaptic weights wi1,
  wi2, , wip and threshold qi
• the network output is a linear combination of
  the outputs of the hidden neurons, with a1, , aM
  defining the coefficients of this combination.

9
Introduction

• The theorem itself is a simple existence theorem
  - a generalization of Fouriers result going back
  to the 1820s. It tells us that a single layer
  suffices, but it does not tell us anything about
  efficiency of representation, minimality, ease of
  training, size of the required set of hidden
  nodes, etc.
• It allows for further results relating the
  accuracy of estimation of a function f by the
  approximation F to the accuracy of the empirical
  fit - i.e., a way of relating M, the number of
  hidden nodes, to N, the size of the training set.
  One can also show that there exists a choice of
  M so that the rate of convergence of training is
  O((1/N)1/2) time a logarithmic factor.

10
Introduction

• One of the problems with single hidden layer
  perceptrons is that all intermediate information
  is global it becomes impossible to interpret
  anything as a local feature.
• Introducing two hidden layers allows one to
  interpret the information at the layer closest to
  the input as local while the information at the
  layer closest to the output is global.
• Other types of problems lead in a natural way to
  two-layer networks.

11
Introduction

• The point to be made is that, although
  mathematical theory supports the approximability
  of most reasonable classes of functions from an
  n-dimensional euclidean space to an m-dimensional
  one, coming up with a usable approximation in a
  reasonable amount of time ( use of computational
  resources) given a small amount of information
  remains (for now and forever) a completely
  non-trivial problem.
• The problem is, essentially, one of search
  among all possible approximations find one that
• fits the known input/output relation best
  (e.g., with minimum least square error)
• allows us to interpolate at points where we do
  not have data
• has acceptable cost in both construction and
  evaluation.

12
Introduction

• What general method can we devise?
• Random Search start with a pair, add another,,
  and so on, rejecting all those that do not meet
  acceptable (input, output) criteria. You may use
  continuity - which, essentially, says that nearby
  input value should lead to nearby output values.
  After a while, you may have enough of a function
  to perform (linear) interpolation with some
  feeling that you wont have too many surprises.
• Non-Random Search find a clever general purpose
  algorithm that will allow us to build a good
  function with acceptable cost.
• For the second one, recall that just about all
  the NP-Complete problems we know require a
  complete enumeration of all possible
  configurations to guarantee finding a solution
  so

13
Introduction

• More formally
• The No Free Lunch Theorems No search algorithm
  is superior to any other algorithm on average
  across all possible problems.
• Consequence algorithms that perform better than
  random search on one class of problems will
  perform worse than random search on another.
• Consequence all algorithms we devise will have
  to be tailored to the search domain - it is the
  use of specific domain-dependent information that
  gives us algorithms better than random search.
  Outside of a given domain, our results will be
  (much) worse.

14
Introduction

• We are going to concentrate on some aspects of
  search and of function construction through
  search - the techniques to be introduced attempt
  to find computational analogues to methods that
  (to the best of our current knowledge) appear
  used in biological evolution.
• Since biological evolution appears based on
  modification of the DNA exchanged from parent(s)
  to offspring we are going to have to find ways
  to
• encode all desired characteristics of a problem
  in a data structure that can support DNA-type
  modifications (whatever they will be, but they
  must include some analogues of chromosomal
  recombination and mutation applied to strings
  over some alphabet) and still remain meaningful
  in our context
• construct an evaluation function (equivalent to
  evolutionary fitness determination) on either the
  underlying data structure

15
Introduction

• derivable from the original one (i.e., the
  genotype)
• c) devise a strategy for differential
  reproduction, so that fitter individuals
  produce more offspring with a high chance of
  possessing desirable characteristics, while
  guarding against genetic overspecialization.
• A lot of the terms are in quotes, since it is not
  obvious how the analogy with biological systems
  will be implemented as they say, the devil is in
  the details

16
Introduction

• The Problem of Representation. How do we
  represent the information to be searched for?
• In DNA-based search we deal with an alphabet
  over 4 letters (A, C, G, T), and finite strings
  over that alphabet. The length of the strings is
  (more or less) fixed and parent-child information
  exchange seems to consist (at least at a first
  approximation - and for two-parent species) of
  the joining together of two single parental
  chromosomal strands into a double descendant
  strand with dominant and recessive alleles for
  nearly all the genes so transmitted. Two other
  known mechanisms involve movement of sections of
  the string from one location to another and
  single-locus changes (point mutations). Besides
  some other known mechanisms, there may well be
  many unknown ones.

17
Introduction

• Some early representations used fixed-length
  strings of binary digits each position had a 0
  or a 1 (a bit-gene). A function scored the
  string. Evolution of a solution involved
• Determining which individuals would reproduce.
• Selecting the pairs of individuals contributing
  to the offspring.
• Determining how they would so contribute.
• Determining the role and frequency of
  point-mutations.
• Defining the new population.
• Repeating the process from 1. above.
• Determining when termination was reached.
• Extraction of the best individual as the
  solution.

18
Introduction

• There are several slightly different ways of
  looking at the evolution of a population via
  genetic-analogue methods
• each generation corresponds to another subset of
  possible individuals. Convergence will
  correspond to a family of subsets of decreasing
  diameter (under some metric).

19
Introduction

• 2) Given a population of M individuals with N
  binary genes each, the number of states such a
  population can be in is given by the
  formula Finding a solution
  means, essentially, finding a limiting state for
  the evolving family of populations. A best
  individual of the limit population is our desired
  solution.

20
Introduction

• 3) We can interpret each possible individual as a
  point in some space. The evaluation function
  defines a function from this space to R. We look
  for the maximum of this function over the space.
  The graph of this function provides us with what
  is called a fitness landscape. The evolution
  mechanism creates sets of different points in the
  domain from one generation to the next. We stop
  when several successive generations have not
  produced a substantially better individual, or
  when a given amount of computational resources
  has been expended.

21
Introduction

• We need to consider how the offspring will
  receive the information from the parents, and the
  mechanisms that correspond to point-mutation and,
  possibly, to larger scale mutation (e.g.,
  repositioning of substrings within a chromosome).
• Start from binary strings each parent is
  represented by a binary string of length N. A
  reasonable analog to the contribution of single
  chromosomal strands from each parent, with
  dominant and recessive alleles may be to just
  take a prefix substring of (random) length 0 n
  N from the first parent, a suffix substring of
  length N - n from the second parent and
  concatenate them in the same prefix-suffix order.
  This provides a new chromosome of length N.
  Mutation can be simulated by walking down the
  new string and randomly resetting the bits.

22
Introduction

• At the simplest level, we now have a data
  structure which is just a fixed length string of
  bits, an evaluation function to provide relative
  ranks of different individuals, a mechanism for
  enforcing differential reproduction, and a
  mechanism to provide the next generation. A
  variant may include allowing some of the best
  individuals of one generation to have exact
  copies appear in the next.
• A question that begs to be asked is given a
  current generation, can we say anything about the
  evolution of genetic patterns from one generation
  to the next? This is crucial to our being able
  to believe that the process set in motion has
  some convergence properties, rather than just
  leading us to a completely random population.

23
Introduction

• Other Representations. Some problems have
  natural representations in terms of larger
  alphabets (actual DNA comes to mind - 4 letters)
  or in terms of continuous quantities (requiring
  floating point numbers over various ranges). If
  the cardinality of the alphabet is a power of 2,
  we can still use the same bit-oriented
  mechanisms, and the chromosome at the next
  generation will remain meaningful.
• If the alphabet is made up of continuous
  ranges, the problem of representation becomes
  more complex. A possible solution involves using
  a contiguous range of bits to represent each more
  structured entity, with the caveat that mutation
  and recombination must be constrained not to exit
  the appropriate ranges. Another solution
  involves accepting floating point values (rather
  than bits) as genes.

24
Introduction

• This may simplify the interpretation (and
  implementation) of recombination and mutation,
  but we are still left with the problem of
  guaranteeing meaning for the results of such
  actions.
• Another representational problem arises in what
  is properly called genetic programming where
  the object being evolved is a program that
  attempts to compute a specific (only partially
  known) function. Natural representation of
  programs may involve trees, where the nodes are
  functions (interior nodes) or parameter values
  (leaves - if the program does not require
  iteration or recursion), or graphs. Although it
  is always possible to reduce everything to bits,
  any intuition is likely to be so removed from the
  bit-representation as to be useless.

25
Introduction
A difference in approach between genetic
algorithms and genetic programming can be
exemplified in the two diagrams below in genetic
algorithms, once the problem is codified into a
data structure, we just apply the genetic
algorithm in genetic programming the interaction
with the original problem remains more direct and
ongoing.
26
Introduction

• More specifically, the genetic algorithm approach
  results in defining a binary string and then
  modifying and evaluating binary strings,
  constructing successive generations using (at
  least) crossover and mutation operators

27
Introduction

• The genetic programming approach leads to a cycle

28
Introduction

• The string is replaced by a tree, and the tree
  can be modified in ways that are more complex
  than those supported by a string (the apparent
  cycle is not crucial - the methods are all
  cyclical in nature). More crucial is the
  observation that we cannot limit a program to a
  fixed number of tree nodes the search would be
  much too limited. This implies that the usual
  methods (which we will study in more detail
  later) for evaluating convergence will have to
  be modified - if they are applicable at all.

29
Introduction

• Why should anything converge? By allowing a
  best element of the population P to survive
  from one generation to the next, we can ensure
  that the derived evaluation function F(t)
  maxx ÎPt f(x) is monotone non-decreasing in t,
  but this does not mean that we should expect
  improvement or convergence. Another approach,
  based on the idea of a schema, provides a
  probabilistic approach, still with substantial
  drawbacks.

30
Introduction

• Some Examples 1 - Function Optimization. You
  are given the function f(x) xsin(10p x) 1.0
  over the closed interval -1.0, 2.0, and you are
  expected to find the value of x in that range
  that maximizes it Z. Michalewicz, p.18.
• An analytic approach would first compute the
  zeros of the first derivative (the function
  possesses a first derivative at every point in
  (-1.0, 2.0) so any interior maxima or minima will
  appear only at zeros of the derivative). There
  are finitely many such values over the given
  interval. We can now evaluate the function at
  all such values, plus -1.0 and 2.0 (solving
  tan(10px) 10px 0 will require some numerics -
  nothing too hard). A value of x for which we
  attain the maximum of this finite set, plus
  endpoints, provides us with a correct (input,
  output) pair, and a solution to our problem.

31
Introduction

• In the absence of analytic techniques, what can
  we do? We can choose a finite random set of
  points in -1.0, 2.0, evaluate the function at
  those points, choose a point where the function
  achieves a largest value and stop.
• A modification would entail choosing a small
  random set, finding the x-value where the
  function has the largest value choosing a second
  random set near this value, and repeating the
  process with smaller and smaller sets near better
  and better values. Stop when you dont improve
  from one generation to the next, or when you
  run out of computational cycles.
• The second technique, just like the first, is
  likely to leave us stuck near a relative
  maximum which is not optimal Can we do better?

32
Introduction

• How do we devise a genetic algorithm?
  Essentially, we want to add some intelligence
  to this random search try to avoid getting stuck
  on local maxima, and direct the search so that it
  is - hopefully - more efficient than strictly
  random. How?
• Representation what precision do we want? Lets
  choose six places after the decimal point (there
  has to be a point beyond which we dont care).
  Six decimal points 31000000 intervals over
  -1.0, 2.0. Notice that 2097152 221 lt 3000000
  lt 222 4194304, so we will use a string on 22
  bits to represent numbers in the desired range.
• We now have binary strings b21b20b1b0, which we
  can convert to decimal in -1.0, 2.0

33
Introduction

• The two chromosomes 000 and 111 correspond to
  the endpoints -1.0 and 2.0, respectively. All
  others correspond to interior points. The
  evaluation function simply takes a binary
  chromosome, say v, transforms into a decimal
  number, say dec(v), and evaluates f at that
  number eval(v) f(dec(v)).
• Initialization. Create a random initial
  population of chromosomes.
• Ranking. Rank the chromosomes according to the
  evaluation function.
• Reproduction. Normalize the rankings so that each
  rank corresponds to an appropriate subinterval of
  0, 1. Run the random number generator twice,
  using the subintervals to determine probability
  of choice, to obtain two parents.

34
Introduction

• When the parents are found, we create the
  offspring. Two operators are used crossover and
  mutation. Select, randomly, the gene after which
  the crossover takes place. The first parent
  contributes the part of its chromosome ending at
  that gene (inclusive) the second parent
  contributes the final part of its chromosome to
  the offspring. If mutation is to be included,
  one must successively use the random number
  generator to determine if each gene of the
  offspring is to be changed. Repeat the process
  until a number of offspring equal to the desired
  population is obtained.
• Next Generation. We now have a new generation,
  for the process to be repeated.

35
Introduction

• Several issues must be resolved
• the size of the initial population (50, in this
  case)
• the number of generations the process is allowed
  to continue (150, in this case)
• the probability of crossover (the probability
  that a chromosome undegoes cross-over pc
  0.25)
• the probability of mutation (the probability
  that a gene is flipped pm 0.01).
• None of them can be optimally determined
• A run provides the following results

36
Introduction

• The best individuals discovered within 150
  generations are given in the table below.

37
Introduction

• Some Examples 2 - The Prisoners Dilemma. This
  is discussed in Michalewiczs book, in
  Mitchells, and, quite extensively, in D. B.
  Fogels.
• The Problem two individuals are held prisoner
  and are under pressure to confess to some
  undesirable activity implicating the other. The
  options (and rewards/punishments) are summarized
  in the table below.

38
Introduction

• The aim of the game is to find a strategy that,
  over the long run, will maximize ones gains. At
  any one point, the maximizing strategy would have
  the winner defect, and the loser holding out, so
  there is always a temptation to defect. In fact,
  defection is always the safest individual
  choice at each point. On the other hand, a
  sequence of mutual defections has a combined
  payoff much smaller than that of a sequence of
  mutual cooperations. We can compute
• An infinite sequence of random choices (each
  configuration has probability 0.25) has an
  expected return (for each of the players) of
  2.25, with an expected cumulative return of 4.5
• An infinite sequence of defections, with the
  other choosing randomly has an expected return
  (for the defector) of 3 and of 0.5 (for the
  other), so the expected cumulative return is only
  3.5

39
Introduction

• 3. Ex. compute the expected returns, individual
  and cumulative, for at least two other sequences
  of actions.
• Representing a solution. Ideally, we should have
  a complete memory of the past to determine the
  next decision. Since this is not possible, a
  decision has to be made on the basis of a finite
  memory. Michalewiczs text uses the previous
  three moves. In fact (Mitchells and Fogels
  books), tournaments (human and computer) were
  organized by A. Axelrod in the 70s and 80s
  to try to determine best strategies, and he
  decided to use the three-move-memory we will
  use here. If a chromosome contains information
  about the three previous moves, and since there
  are 4 possible outcomes for each move, we have to
  keep track of 64 ( 444) possible games - 64
  different histories.

40
Introduction

• If we order the histories in some canonical
  order, a 64-bit array allows us to associate a
  response to each history. We must also prime the
  system with three initial games, with two bits
  required for each (index into histories). Total
  70 bits for a chromosome.
• Choose an initial population. Create a number, N,
  of random 70-bit strings.
• Test each player to determine effectiveness. Use
  the strategy encoded in the chromosome to play
  games against all other players. The fitness
  is the average score over all the games played.
  The original study by Axelrod had each member of
  the population play against a set of given
  strategies - culled from one of the human and
  computer tournaments. The initial game sequence
  provides an index into the bit-string, so one
  could use the first six bits to determine the

41
Introduction

• initial strategy for each player (player no. 1
  uses its initial conditions to determine the game
  sequence to be continued by both).
• Select the player to breed. A player with an
  average score (within a standard deviation of
  average) is given one mating a player with a
  score one or more standard deviations above
  average is given two matings one with a score
  one or more standard deviations below average is
  give no matings (some minor adjustment may be
  necessary to keep the population of constant
  size).
• Breed. Randomly pick pairs, and create two
  descendants per mating using both crossover and
  mutation.

42
Introduction

• Results. Experiments lead to a number of
  strategies being discovered.
• Continue cooperation after three initial
  cooperations (CC)(CC)(CC) leads to C.
• Defect when the other player defects
  (CC)(CC)(CD) leads to D.
• Continue to cooperate after cooperation has been
  restored (CD)(CD)(CC) leads to C.
• Cooperate when cooperation has been restored
  after your own defection (DC)(CC)(CC) leads to
  C,
• Defect after three mutual defections
  (DD)(DD)(DD) leads to D.
• If the payoff for successful defection is
  increased to 6, strategies can delop with
  expected payoffs gt 3.0 (Fogel).

43
Introduction

• The evolved strategies can be represented as
  finite-state machines, which can also mean that
  the final best strategy can be interpreted as a
  formal program - the best evolved.
• This was an example of co-evolution, where the
  individuals in a population were pitted against
  one another and caused the population to evolve
  through mutual interactions.
• For much more detail, see the papers by Axelrod
  or the book by D. B. Fogel Evolutionary
  Computation.

44
Introduction

• Some Examples 3 - The Traveling Salesman
  Problem. This is a well-known NP-Complete
  problem, which has some reasonable
  approximation schemes - at least in the case in
  which the distances between nodes satisfy a
  triangle inequality (see Cormen al., Ch. 35).
  There can be no expectation of an exact solution
  (find a tour of minimum length) in anything but
  exponential time, but it may be possible to
  beat the quality of the known deterministic
  approximation algorithms without giving up too
  much time
• What is a chromosome? A reasonable
  interpretation for a chromosome is that it
  represents a tour. Since the complete graph
  consists of N nodes, is the chromosome a binary
  string (array) or an integer array?

45
Introduction

• This is an important decision because of the
  genetic operators do we split at a bit or at a
  full node index (integer)?
• If we use a bit representation, our chromosome
  will need Nceiling(log2N) bits. Using crossover
  or mutation at the bit level cannot guarantee
  that the new chromosome represents a new tour,
  or, possibly, even that we have a path in the
  graph (if exp(ceiling(log2N)) gt N).
• If we use integer representation (N integers),
  and we use our genetic operators at integer
  boundaries, we can at least guarantee that we
  still have a path, although maybe not a tour.

46
Introduction

• The choice in this case is of an integer
  representation for the chromosome, essentially
  because
• it avoids one set of problems - the possible
  introduction of non-existent nodes and,
• it permits some simpler cross-over repair
  algorithms to make sure that no stillborn
  descendants are allowed into the population. The
  repair algorithms can be incorporated into the
  genetic operators.
• Mutation can be handled ina similar way.
• Intialization. For a population of size M, pick
  M random permutations on N items. Another
  possibility is to use a greedy algorithm to
  construct M approximate solutions, and start from
  those.

47
Introduction

• Evaluation and Ranking. Straightforward for each
  individual - just compute the value of the tour
  it represents.
• Breeding. Both crossover and mutation must be
  implemented carefully to preserve a tour and to
  maintain a relationship with the parents. We
  will look at the details at some later date.
• Results. The algorithm, as described, appears to
  be better than random search, but is not very
  efficient a 100 city tour, after 20,000
  generations, gives a value for the best tour
  found about 9.4 above optimum (Michalewicz, p.
  26).

48
Introduction

• Some Examples 4 - Tree-Based Genetic
  Programming. Assume we are given a function,
  either explicitly or, more likely, as a set of
  (input, output) pairs. Assume we have a finite
  set of pairs derived from the function y x2.
  We want to construct a best interpolating
  function we can, obviously starting only from
  the set of (input, output) pairs.
• A program can be viewed as a tree structure,
  where the leaves are terminals ( parameter
  values), while the interior nodes are function
  calls whose children are values provided from
  farther down the tree.

49
Introduction

• One would start with an initial population of
  trees, evaluate the individuals on the set of
  (input, output) pairs assigning each a value
  dependent on how good the match is between the
  output values computed by the program and those
  given. One would then

apply some tree-compatible genetic algorithms to
generate the new population.
50
Introduction

• Another example of next generation

51
Introduction

• Final result we have a true match, although all
  we really know is that we have achieved an exact
  interpolation of the given (input, output) set.

52
Introduction

• The program simple-gp.c evolves such a solution.
• It develops a formula (with some understanding of
  the need to take care of zero-divisions) which,
  complex as it appears, can, in fact be reduced to
  an actual function unfortunately it does not
  look much like the actual function on a first
  reading. This is not an unusual problem, since
  the rules for canonical representation of
  rational functions are fairly hard to implement
  see some of the early programs for symbolic
  computation.

53
Introduction

• This approach raises a number of representational
  questions how do we represent a program? What is
  a chromosome? What is mutation? etc.
• Part of the problem is that a constant length
  chromosome might correspond to a rather limited
  family of trees, making the whole evolutionary
  process moot. On the other hand, introducing
  variable length chromosomes with very large
  alphabets ( primitive functions and parameter
  values) may grow our chromosomes to enormous size
  (although our own DNA may be trying to warn us).
  Furthermore, we are looking for some theoretical
  models to at least give plausibility to our
  methods such theoretical models are likely to be
  far too complicated

54
Introduction

• Some other ideas on Genetic Programming. Other
  questions would arise on the meaning of a
  program as we indicated in the Prisoners
  Dilemma, one can evolve finite-state machines
  that are quite efficient. Those are, undeniably,
  programs. The next question might be on how to
  represent (and define and apply genetic
  operators) for stack machines (supporting
  recursion), assembly-language machines,
  graph-reduction machines (which are used in the
  compilation and optimization of functional
  language programs), etc.
• And all of this requires some kind of supporting
  theoretical framework.
