Seismic Retrofit of a Hospital Building Using
Dampers
Bob Glasgow, MS, SE Amir Gilani, PhD, SE Kit
Miyamoto, MS, SE
2
Introduction

• Hospital Building South of Los Angeles
• Steel MRF with Pre-Northridge Beam-Column
  Connections
• FEMA 356 Guidelines Evaluation
• Non-ductile Connections
• Small Column Sizes
• Seismic Retrofit
• FVDs
• Minimize Operational Interruption

3
Building Description

• Constructed in the 1970s, 40 ft Tall
• Three Stories Partial Basement
• 282ft x 75 ft, Rectangular Floor Plan
• Building Weight 3,100 kips

4
Photograph of the Building
5
Framing

• Gravity
• 3 ¼ in. LWC over 3 in. Metal Deck
• Steel Beams and Columns
• Lateral
• Perimeter MRF, Longitudinal
• MRF all Bays, Transverse
• Foundation
• Pre-stressed Concrete Square Piles

6
Floor Framing
8.5 two-way slab
7
Performance Evaluation

• Performance Objectives
• LS at DBE
• CP at MCE
• Design Criteria
• PH Rotations less than 0.5 Radian
• More Strict than FEMA 356 351 (OSHPD
  Requirement)
• Story Drift Ratios less than 1
• First Floor Displacement lt 1.5 in. to Avoid
  Pounding Against the Adjacent Single Story
  Buildings

8
Seismic Demand

• Soil type SD
• DBE RS
• Ss 0.9g
• S1 0.5g

9
Seismic Evaluation

• Performance Based Earthquake Engineering (PBEE)
  Methodology
• Analysis Procedure
• Modal
• Nonlinear Static (Pushover)
• Nonlinear Dynamic (Response History)

10
Analytical Model
11
Dynamic Analysis

• Consider Two Cases
• Column Bases Fixed Pinned
• Observations
• No Torsional Coupling Most Mass Participate in
  First Mode
• Thus
• Use Separate 2D Models for Evaluation

12
Evaluation of the Existing Building

• Linear Dynamic Analysis
• Pinned Base Models
• Large Drifts First Story, Could Lead to Soft
  Story Behavior
• All Models
• Drifts of Existing Building too Large, Would Lead
  to Large Demand on Steel Members

13
NSP-Pushover Analysis

• 2-D Models
• Pinned and Fixed Base
• FEMA 356 PHs
• 0.5 Radian Limit

14
Longitudinal Response
Fixed Based Model
Pinned Based Model
15
Transverse Response
Fixed Based Model Pinned Base Model
16
Existing Building Evaluation

• Many PHs Exceed the 0.5 Radian Limit
• Hinging in Columns
• Response is Unacceptable

17
Proposed Conventional Retrofit

• All Columns
• Weld Full-length Cover Plates to Columns
• All Connections
• Add Continuity Plates
• Reinforce Panel Zone

18
Drawbacks of Conventional Retrofit

• Cost
• Total Disturbance of Occupancy, Business
  Interruption
• Time to Perform Retrofit

19
State-of-the-Art Retrofit

• Reduce Seismic Demand by Increasing Supplemental
  Damping
• Minor Occupancy Interruption
• Repair of Selected Columns
• Cost-effective
• Use Fluid Viscous Dampers

20
FVDs

• Force Nearly Out-of-Phase with Elastic Forces
• Easily Installed
• Reliable
• Used Previously for New and Retrofitted Steel
  Framed MRFs
• Add 4 Units Each Floor Each Direction

21
Proposed FVD Installation
22
Retrofitted Model
23
Evaluation of Retrofitted Model

• NL Response (Time) History Analysis
• Pushover Analysis at the Target Roof Displacement
  to Check Existing Frame Elements

24
Roof Displacement Response
25
Existing Building Response in Longitudinal
Direction
26
Damped Response in Longitudinal Direction
27
Pushover Response, Retrofitted Model
Note all PH Rotations lt0.5 Radian
28
Performance Evaluation

• Three Objectives
• Maximum Story Drift Ratio 0.9 lt1
• Small PH Rotations
• First Story Displacement 1.3 in lt1.5 in
• All Performance Goals are met

29
Components of Seismic Input Energy
Input Dampers Inherent Viscous
30
Conclusions

• Evaluation
• PBEE Used to Assess Performance Retrofit
• FEMA 356 NL Procedures
• Proposed Retrofit
• Add FVDs Reduce Seismic Demand Significantly
• Minimize Business Interruption
