Subroutines
Programming Language Principles Lecture 24

• Prepared by
• Manuel E. Bermúdez, Ph.D.
• Associate Professor
• University of Florida

2
Abstraction

• A process by which a programmer associates a name
  with a potentially complicated program fragment.
• Goal Think in terms of purpose vs.
  implementation.
• Two forms of abstraction
• Control Abstraction Represent an action.
• Data abstraction represent data (more later).

3
Control Abstraction

• Main control abstraction mechanism the
  subroutine.
• Subroutines perform operations on behalf of the
  caller.
• Can accept parameters. Parameters influence the
  subroutine's behavior. Give the subroutine data
  on which to operate.

4
Terminology

• Argument actual parameter.
• Parameters formal parameter.
• Subroutine that returns a value a
  function.
• Subroutine that doesn't return a value a
  procedure.
• Procedures are only executed for their side
  effects.

5
Subroutine Stack Layout

• Storage consumed by parameters can be allocated
  on a stack.
• Each routine that is called gets a stack
  frame/activation record on top of the stack.
• A frame contains
• Arguments, that are passed into the subroutine.
• Bookkeeping info (such as return address of
  caller, saved registers).
• Local variables / temporaries.

6
Stack Layout (revisited)
7
Frame Management

• Keeping the stack frame intact is the
  responsibility of the calling sequence code
  executed by the caller immediately before and
  after a subroutine call.
• Prologue Code executed at beginning (pass
  parameters, save return address, change program
  counter, change SP, save registers)
• Epilogue Code executed at the end (restore SP,
  restore registers, etc.)
• Calling sequence varies from processor to
  processor, and compiler to compiler.

8
Frame Management

• When a subroutine is finished it pops its frame
  from the stack (and leaves its return value if
  there is one on top of the stack)
• Stack pointer (SP) Register contains the address
  of the first unused location at the top of the
  stack.
• Frame pointer (FP) Contains an address within
  the frame. Objects within the stack are
  referenced via displacement addressing with
  respect to the FP.

9
Static Links (revisited)

• In a language with nested subroutines and static
  scoping (Pascal, Ada, Modula) objects that lie in
  surrounding subroutines (neither local, nor
  global) can be found by maintaining a static
  chain.
• Static Link (SL) Reference to (most recent
  instance of) the frame of the lexically
  surrounding subroutine. Needed to look up
  non-local variables (in surrounding scope).

10
Maintenance of static chains

• Standard approach
• caller computes callee's SL and passes it as an
  extra hidden parameter.
• Two cases

11
Static Links (revisited)

• The callee is nested (directly) inside the
  caller. The callee's static link should refer to
  the caller's frame. The caller passes its own FP
  as the callee's SL.
• Example A calls E, or B calls D.

12
Maintenance of static chains (contd)

• The callee is k gt 0 scopes outward -- closer to
  the outer level of lexical nesting. All scopes
  that surround the callee also surround the
  caller. The caller dereferences its own SL k
  times and passes the result as the callee's SL.
• Example E calls B, D calls C, or C calls B.

13
Static Link Disadvantage

• An object in a scope k levels out requires
  dereferencing the chain k times.
• We can fix this by using a display.
• A display embeds a static chain into an array.
• The j-th element of the display contains a
  reference to the frame of the most recently
  active routine at nesting level j.

14
Maintenance of Displays

• When calling subroutine at level j, the callee
  saves the current value of the jth display into
  the stack and replaces it with a copy of its own
  FP.
• Two cases

15
Maintenance of Displays (Case 1)
The callee is nested (directly) inside the
caller. Caller and callee share all display elems
up to the current level. Put callee's FP into
the display. Example A calls E, B calls D.

16
Maintenance of Displays (Case 2)

• The callee is at nesting level j, k gt 0 scopes
  outward from the caller. Caller and callee share
  display up to j-1. The caller's entry at j is
  different, so callee must save it before storing
  its own FP.
• Example E calls B, D calls E.

17
Handling Closures

• If callee is called through closure, the display
  scheme breaks.
• Solved by storing the entire display in the
  callees frame.
• Expensive, and not always necessary to store the
  entire display.
• Good argument for using static links. In general
  maintaining display is more expensive than SL.

18
Efficiency (Static link vs. Display)

• Display in memory a non-local object can be
  loaded in memory with two memory access
  operations. One for display, one for object
  loading.
• Static links non-local loading requires k
  dereferencing operations.
• Most programs don't nest subroutines more than
  2/3 levels deep. So static chain is short.

19
Efficiency (Static link vs. Display)

• Maintaining display is more expensive then
  maintaining static chain.
• Static chains allow closures (subroutines passed
  as parameters).
• Display (typically) uses fixed size array.
  Imposes a maximum depth of nested subroutines.

20
Case study 1

• C (gcc v. 2.7.2) on MIPS architecture (RISC)
• For description of MIPS architecture, see Section
  5.5.1 of the textbook.
• Arguments are accessed via offset from fp.
• First four scalar arguments are passed through
  registers (r4-r7, or f12-f15)

21
gcc on MIPS Architecture
22
gcc on MIPS Architecture (contd)

• The caller
• Saves any caller-saved registers that are still
  needed.
• Puts up to four scalar arguments into the
  registers.
• Puts remaining arguments at top of current frame.
• Performs a JAL (jump) which puts the return
  address in register ra and jumps to the target.

23
gcc on MIPS Architecture (contd)

• In the prologue the callee
• Subtracts the frame size from the sp.
• Saves any necessary registers into the beginning
  of the new frame, using sp as base for
  displacement mode addressing.
• copies sp into fp.

24
gcc on MIPS Architecture (contd)

• In the epilogue the callee
• Places return value (if any) into r2, f0 or
  memory.
• Copies the fp into the sp, to deallocate any
  allocated space.
• Restores saved registers including the ra, if
  needed, using sp as base for displacement mode
  addressing.
• Adds the frame size to the sp, to deallocate the
  frame.
• Performs a jra instruction (jump back)

25
Case Study 2

• Pascal (CodeWarrior v.9) on the Motorola 680x0.
  (old Mac, Amiga, Atari ST)
• CISC architecture.
• All arguments passed on the stack, not in
  registers.
• Arguments are pushed and popped (using auto
  increment and auto decrement instruction modes),
  updating the sp dynamically, rather than
  assembling them in a pre-allocated area.
• fp gets a dedicated register, by convention, a6.

26
Pascal on M680x0
27
Pascal on M680x0 (contd)

• The Caller
• allocates space for a small return value, or
  pushes the address of a large one. Skip if this
  is a procedure.
• pushes arguments (or their addresses)
  left-to-right. Skip if there are no parameters.

28
Pascal on M680x0 (contd)

• The Callee, in the prologue
• executes a link instruction decrement sp enough
  to accommodate all locals, temps, and large
  arguments copied from caller.
• pushes any registers that need to be saved (fp,
  in a6).
• copies any large arguments needed.

29
Pascal on M680x0 (contd)

• The Callee, in the epilogue
• sets the return value (bottom of frame)
• pops saved registers.
• executes an unlk instruction, to restore the sp
• pops arguments and SL.
• returns.

30
Pascal on M680x0 (contd)

• Since Pascal allows subroutines to be nested,
  passing a subroutine as a parameter requires a
  closure.
• Eight-byte long closure
• First four are static link of closure
  (environment link in RPAL).
• Last four bytes are address of subroutine's code.
• Passed by address (due to its length), though
  it's never changed.

31
In-line expansion

• Compiler can choose to compile routine inline.
• Inline expansion increases code size, but is
  significantly faster.
• C
• inline int max (int a, int b)
• return a gt b ? a b

32
In-line expansion (contd)

• Ada
• function max (a, b integer)
• return integer is begin
• if a gt b then return a else
• return b end if
• end max
• pragma inline (max)
• In both languages, the compiler directive is a
  suggestion that can be ignored.
