Learning and Perceptrons

1
Learning and Perceptrons

• CIS 479/579
• Bruce R. Maxim
• UM-Dearborn

2
Momentum and Friction

• When human players use a mouse to aim
• Momentum turns the view more than they expect for
  large angles (the ballistic mouse thing)
• Friction slows down the turn for small angles
• Adjustments are needed to avoid losing accuracy
• For AI players they just aim at an exact target
  and shoot
• Perfect shooters may not be fun to play against
  so turning errors can be introduced

3
(No Transcript)
4
Explicit Model

• A mathematical function for computing the actual
  turning angle in terms of desired angle and
  previous output
• ? 1.0 0.1 noise(angle)
• output(t) (angle ?) ? output(t 1) (1
  - ?)
• scaling factors for blending previous output
  with angle request in range 0.3,0.5
• initialized to random value between in range
  0.9, 1.1
• noise( ) returns value in range -1,1 could use
  cos(angle2 0.217 342/angle)

5
Linear Approximation

• We can use a perceptron to approximate the
  function described earlier
• Once the animat learns the a faster approximation
  for function it can be removed from the AI code
• Aiming errors just become a constraint on animat
  behavior

6
(No Transcript)
7
Methodology

• Approximation computed by training network
  iteratively
• Desired output is computed for random inputs
• By grouping results, the batch algorithm can be
  used to find values for weights and bias
• A small perceptron is applied twice (to get pitch
  and then yaw) rather creating a larger one that
  does both
• This reduces memory use at the expense of
  programming time

8
Accumulating Errors

• Momentum and friction causes errors or drift that
  tend to accumulate after several turns
• These errors allow the AI to perform more
  realistically performance
• Ignoring the variations in aiming will make the
  AI too error prone to challenge human players

9
Inverse Error

• To compensate for aiming errors, we could define
  an inverse error function to help correct the
  aiming errors
• Not every function as a definable inverse so that
  AI would be better served by a math-free method
  of approximating this type of function
• Given enough trial and error through simulation
  opportunities the AI should be able to predict
  the corrected angles needed

10
Learning - 1

• In effect the AI learns how to deal with aiming
  errors by receiving evaluative feedback
• Using this feedback the AI can incrementally
  improve its task performance
• The AI uses its sensors to detect the actual
  angles the body was turned since the last update
• Unfortunately the AI learns to shoot where it
  should have shot last time

11
Learning - 2

• With enough trials the AI can learn to anticipate
  where to shoot (the NN weights provide a crude
  memory to work with)
• Both the inputs and outputs will need to be
  scaled because the perceptron will have to deal
  with values that are not within the unit vector

12
Aimy

• Perceptron is used to learn corrected angles
  needed to prevent undershooting and overshooting
• Gathers data from its sensors to determine how
  far its body turned based on each requested angle
• Incremental training is used to approximate the
  inverse function needed to prevent aming errors

13
Evaluation - 1

• Animat should have the opportunity to correct
  aiming while moving around
• Perceptrons can learn more quickly when more
  training samples are presented
• The animat can corrects its aim on only two
  dimensions (pitch and yaw)
• Only when pitch is near horizontal can the animat
  aim while it is moving

14
Evaluation - 2

• When looking fully up or fully down there is no
  forward movement is possible, this prevents
  learning
• To prevent this trap, the animat is only allowed
  to control yaw until satisfactory results are
  obtained
• The worst that happens is the animat spinning
  around while learning

15
Evaluation - 3

• The way in which the yaw is chosen determines the
  angles available for learning
• If the animat full control over the yaw, it can
  decide what to learn and what to ignore (the
  effect may be for the NN to always predict the
  same turn to correct aiming errors)
• This is a good reason for forcing the NN to
  examine a variety of randomly generated angles
  during training to get a more representative
  training set and better learning

16
Multilayer Perceptrons

• Single layer perceptrons can only deal with
  linear problems
• Non-linear problems can only be approximated by
  single layer perceptrons
• Multilayer perceptrons (MLP)
• Have extra middle layers know as hidden layers
• The middle layers require more sophisticated
  activation functions than single layer
  perceptrons (e.g. linear activations would make
  MLP behave like single layer perceptron)

17
(No Transcript)
18
Topology

• MLP topology is said to be forward feed because
  there are no backward (recurrent) connections
• There can be an arbitrary number of hidden layers
  in MLP
• Adding too many hidden layers increases the
  computational complexity of the network
• One hidden layer is usually enough to allow the
  MLP to be a universal approximator capable of
  approximating any continuous function

19
Hidden Layers

• In some cases, there may be many independencies
  among the input variables and adding an extra
  hidden layer can be helpful
• Adding hidden layers some times can reduce the
  total number of weights needed for suitable
  approximation
• MLP with two hidden layers can approximate any
  non-continuous functions

20
Hidden Neurons

• Choosing the number of neurons in the hidden
  layer is an art, often depends on the AI
  designers intuition and experience
• The neurons in the hidden layer are needed to
  represent the problem knowledge internally
• As the number of dimensions grows the complexity
  of the decision surface (path through hidden
  layer) increases
• Basically the output on one side of the surface
  is positive and negative on the other side

21
Connections

• Neurons can be fully connected to one another
  within and between layers
• Neurons can also be sparsely connected and even
  skip layers (e.g. straight from input to output)
• Most MLP are fully connected to simplify
  programming

22
Activation Function Properties

• Derivable (known and computable derivative)
• Continuous (derivative defined every where)
• Complexity (nonlinear for higher order tasks)
• Monotonous (derivative positive)
• Boundless (activation output and its derivative
  are finite)
• Polarity (bipolar preferred to positive)

23
Activation Functions

• Activation functions for the input and output
  layers are usually one of the following
• Step, Linear, Threshold logic, Sigmoid
• Hidden layer activation functions might be one of
  the following
• Sigmoid sig(x) 1/(1 e-?x)
• Hyperbolic tangent
• Bipolar Sigmoid sigb(x) 2/(1 e-?x) - 1

24
Role of Hidden Layers

• The use of a hidden layer implies that the
  information needed to compute the output must be
  filtered before passing it on to the next layer
• Each layer of the MLP receives its input from the
  previous layer and passes its modified output on
  to the next layer

25
Feed-Forward Algorithm

• current input // process input layer
• for layer 1 to n
• for i 1 to m // compute output of each neuron
• // multiply arrays and sum result
• s NetSum(neuron(I).weights.current)
• outputi Activate(s)
• // next layer uses this layers output as input

• current output

26
Benefits of MLP

• The importance of MLPs is not that they really
  mimic animal brains, they do not
• MLP have a thoroughly researched mathematical
  foundation and have been proven to work well in
  some applications
• MLP can be trained to do interesting things and
  this training really just involves numeric
  optimization (minimizing output error)

27
Back Propagation - 1

• BP is the process of filtering error from the
  output layer back through the preceding layers
• BP was developed in response to fact that single
  layer perceptron algorithms do not train hidden
  layers
• BP is the essence of most MLP learning algorithms

28
(No Transcript)
29
Back Propagation - 2

• Form of hill climbing know as gradient ascent
  hill climbing
• several directions tried simultaneously
• steepest gradient used to direct search
• Training may require thousands of
  backpropagations
• BP can get stuck or become unstable during
  training
• BP can be done in stages

30
Back Propagation - 3

• BP can train a net to recognize several concepts
  simultaneously
• Trained neural networks can be used to make
  predictions
• Too many trainable weights relative to the number
  of training facts can lead to overflow problems

31
Back Propagation Algorithm - 1

• Given set of input-output pairs
• Task compute weights for 3 layer network at maps
  inputs to corresponding outputs
• Algorithm
• 1.Determine the number of neurons required
• 2.Initialize weights to random values
• 3.Set activation values for threshold units

32
Back Propagation Algorithm - 2

• 4.Choose and input-output pair and assign
  activation levels to input neurons
• 5.Propagate activations from input neurons to
  hidden layer neurons for each neuron
• hj 1/(1 e-? w1ijXi)
• 6.Propagate activations from hidden layer neurons
  to output neurons for each neuron
• oj 1/(1 e-? w2ijhi)

33
Back PropagationAlgorithm - 3

• 7.Compute error for output neurons by comparing
  pattern to actual
• 8.Compute error for neurons in hidden layer
• 9.Adjust weights in between hidden layer and
  output layer
• 10.Adjust weights between input layer and hidden
  layer
• 11.Go to step 4

34
Backprop - 1

• // compute gradient in last layer neurons
• for j 1 to m
• deltaj deriv_activate(net_sum)
• (desiredj outputj)
• for i last 1 to first // process layers
• for j 1 to m
• total 0
• for k 1 to n
• total deltak weightsjk
• deltaj deriv_activate(net_sum) total

35
Backprop - 2

• // steepest descent for error gradient for
• // each weight
• for j 1 to m
• for i 1 to n
• // adjust weights using error gradient
• weightji learning_rate
• deltaj outputI
• // The generalized delta rule is used to
• // compute each weight ?wij
• // learning_rate set by KE
• // deltaj is gradient of neuron j error

36
Quick Propagation

• Batch technique
• Exploits locally adaptive techniques to adjust
  step magnitude based on local parameters
• Uses knowledge of higher-order derivatives (e.g.
  Newtons methods)
• Allows for better prediction of the slope of the
  curve and location of minima
• Weights updated using method similar to backprop

37
Quickprop - 1

• // Requires two additional arrays for step and
• // gradient - it remembers last set of values
• // New weight update replaces steepest descent
• for j 1 to m
• for i 1 to n // compute gradient and step
• new_gradientji -deltaj inputi
• new_stepji new_gradientji /
• (old_gradientji
• new_gradientjI)
• old_stepji

38
Quickprop - 1

• // adjust weight
• weightji new_stepji
• // store values for next iteration
• old_stepji new_stepji
• old_gradientji new_gradientji
• Note since this is a batch algorithm all
  gradients for each training samples are added
  together

39
Resilient Propagation

• Weights updated only after all training samples
  have been seen
• The step size is not determined by the gradient
  unlike steepest descent techniques
• Equations are not too hard to implement

40
Rprop - 1

• // New weight update replaces steepest descent
• for j 1 to m
• for i 1 to n // compute gradient and step
• new_gradientji -deltaj inputi
• // analyze change to get size of update
• if(new_gradientjiold_gradientjigt0)
• new_updateji nplus
  new_updateji
• else if(new_gradientjiold_gradientjilt
  0)
• new_updateji nminus
  new_updateji
• else
• new_updateji old_updateji

41
Rprop - 2

• // determine step direction
• if(new_gradientj gt 0)
• stepji -new_updateji
• else if(new_gradientj lt 0)
• stepji new_updateji
• else
• stepji 0
• // adjust weight and store values
• weightji stepji
• old_updateji new_updateji
• old_gradientji new_gradientji

42
Building Neural Networks

• Define the problem in terms of neurons
• think in terms of layers
• Represent information as neurons
• operationalize neurons
• select their data type
• locate data for testing and training
• Define the network
• Train the network
• Test the network

43
Structuring the Training Facts

• Use randomly ordered facts
• Use representative data
• Include people who survive surgery as well as
  people who do not
• Neurons cant be coded
• 1horse1, 2horse2, etc.
• Networks like lots of inputs and outputs
• Better to use two output neurons (one for buy and
  one for sell than one coded 1buy and 0sell)

44
Structuring the Training Facts

• For historical data, use rows not columns
• dont use
• day1 day2 day3
• 3 4 5
• do use
• day
• 3
• 4
• 5

45
Structuring the Training Facts

• Neural networks like differences over big numbers
• use 50
• not 350 vs 400
• For seasonal data
• use 1 column per month with winter cases coded
• 1 for Dec, Jan, Feb, and 0 for other months
• Think qualitatively not quantitatively
• use restaurant visit on Monday in early Feb
• not restaurant visit on day 43

46
Generalization 1

• Learning phase is responsible for optimizing the
  weights from the training examples
• It would be good if the NN could also process new
  or unseen examples correctly as well
  (generalization)
• If NN is bound too tightly to training examples
  is known as overfitting
• Overfitting is never a problem with single layer
  perceptrons

47
Generalization 2

• For MLP number of hidden neurons affects
  complexity of decision surface
• Need to find the trade-off between the number of
  hidden neurons and result quality
• Incorrect or incomplete data interferes with
  generalization
• Bad training examples are usually to blame for
  failure of MLP to learn concepts

48
Testing and Validation

• Training sets used to optimize the weights for
  a given set of parameters
• Validation sets used to check the quality of
  training, help to find best combination of
  parameters
• Testing sets check final quality of validated
  perceptrons (no test info is used to improve NN)

49
How can you tell things arent working out?

• Your network refuses to learn 10-20 of the
  training facts
• Things to try
• Check definition file for data range errors
• Check for bad (incorrect) facts
• Some training facts may conflict with one another
• The training tolerance level may be too strict
  for the data being used
• Switch from absolute score to differences

50
Batch vs Incremental

• Batch preferred over incremental training
• Converge to answer faster
• Have greater accuracy
• Incremental data can be gathered for batch
  processing if necessary
• Incremental approaches best suited for real-time,
  in-game learning (requires less memory)

51
Forgetting

• With incremental learning, it may be wise to slow
  down learning rate later in the game to avoid
  forgetting earlier lessons
• No formal approach to reducing learning rate,
  linear or exponential decay strategies are often
  successful
• This implies that learning will eventually become
  frozen as time passes

52
Perceptron Advantages

• Good mathematical foundation
• If solution exists it can be found
• Work best for well defined problems
• If things go wrong the parameters can be adjusted
• Lots training algorithms exist
• MLP works easily with continuous values
• Deals well with noise

53
Perceptron Disadvantages - 1

• NN do not contain an easily understood
  representation of their knowledge
• MLP depends entirely on the algorithms used to
  create it
• MLP does not scale well
• Once trained MLP is not updated without
  retraining
• Retraining does not preserve pervious MLP
  knowledge

54
Perceptron Disadvantages - 2

• Design of inputs and outputs can have a profound
  impact on MLP success
• Input may require pre-processing and outputs may
  require post-processing
• Getting the right number of layers and neurons
  requires trial and error

55
Onno

• Uses a large neural network to handle shooting
  (prediction, target selection, aiming)
• Input is similar to that described in previous
  chapters
• Results are moderate, but demonstrates
  versatility of MLP and benefits of decomposing
  behaviors

56
Why havent there been more NN commercial
successes?

• Programming neural networks is very difficult
  each constraint must be hardwired with O(N2)
  lateral inhibitory and O(N3) diagonal excitatory
  connections
• Learning in NN is hard
• learning algorithms are hard to write
• choosing the right knowledge representation in
  the hidden layer is non-trivial

57
Why havent there been more NN commercial
successes?

• For many application symbol-based knowledge is
  superior to circuit-based knowledge in terms of
  performance
• Neural networks may have been oversold (as has
  been the problem with many early AI technologies)
