Module on Computational Astrophysics

1
Module on Computational Astrophysics Professor
Jim Stone Department of Astrophysical Sciences
and PACM
2
Module on Computational Astrophysics

• Jim Stone
• Department of Astrophysical Sciences
• 125 Peyton Hall ph. 258-3815
  jmstone_at_princeton.edu
• www.astro.princeton.edu/jstone

Lecture 1 Introduction to astrophysics,
mathematics, and methods Lecture 2 Optimization,
parallelization, modern methods Lecture 3
Particle-mesh methods Lecture 4 Particle-based
hydro methods, future directions
3
When is computation needed in astrophysics?

• Calculating the orbits of planets over billions
  of years
• Requires very accurate N-body methods
• Stellar structure and evolution
• Requires ODE solver, numerical linear algebra,
  hydrodynamics
• Formation of stars and planets
• Hydrodynamic and MHD solvers, N-body methods
• Dynamical evolution of star clusters
• Very fast N-body methods
• Formation of galaxies
• Very fast N-body methods, hydrodynamics
• Data analysis and image processing (astronomy)
• Numerical linear algebra, pattern recognition,
  data mining

4
Thus, computational methods of interest to
astronomers and astrophysicists are

• N-body methods
• ODE solvers
• Numerical linear algebra
• Hyperbolic, parabolic, elliptic PDE solvers
• Image processing, data mining and analysis

We cant cover it all! We have to focus on one
topic
5
N-body algorithms

• Why N-body methods?
• Allow one to study interesting problems
• Physics is simple
• Mathematics is simple (but not too simple)
• Computational methods are complex (but not too
  complex)
• Methods are applicable in other disciplines (e.g.
  plasma physics, molecular dynamics)

Lets look at some examples of the application of
N-body methods to problems in astrophysics
6
Example 1.
Orbits of solar system bodies from Doug
Hamiltons webpage Solar System Viewer
7
Example 2 Stellar dynamics at the galactic
center
8
Example 3 Stellar dynamics in a globular cluster
9
Example 3. (continued)
Movie from Frank Summers, AMNH
10
Example 4. Stellar dynamics during collision of
two galaxies
11
Example 4. (continued)
Calculation by Chris Mihos, Vanderbilt U.
12
Example 5 Formation of structure in the Universe
Evolution of the Universe is an initial value
problem
The past temperature fluctuations 300,000 years
after the Big Bang
WMAP
13
The present distribution of galaxies near the
Milky Way today (14 billion years after Big Bang)
14
Example 5 Formation of structure is computed by
N-body simulations (particles represent dark
matter)
Movie by Andrey Kravtsov, U. Chicago
15
Example 5 (continued) Zoom-in on formation of
cluster of galaxies
16
Example 6. Dynamics of galaxies during cluster
formation
Movie by John Dubinski, U. Toronto
17
How are these results computed?
Motion of individual particles given by Newtons
Laws
Forces computed from Newtons Law of Gravity
Just have to solve two coupled ODEs, plus
evaluate forces.
18
Introduction to mathematics of the N-body problem.
We will use numerical methods to get solutions to
the equations of motion. Useful to understand
mathematical properties of solutions.
For N2, solution can be computed analytically
(two-body problem). Total momentum p m1v1
m2v2 Rate of change of p dp/dt m1dv1/dt
m2dv2/dt F1 F2 But F1 -F2,
--gt dp/dt 0 --gt p const. So particles
move around a common point (the Center of Mass),
which moves at a constant velocity.
19
Two-body problem (continued)
Can show motion of particles follows Keplers
Third Law R distance between particles P
period of orbit
20
For N3, no analytic solution possible (!!)
Example of orbits in a 3-body encounter
21
For N3, no analytic solution possible (!!)
Approximate solutions are possible in certain
limiting cases, e.g. when one particle is much
less massive than other two. BUT, certain
constraints still apply (useful as
diagnostics) Total energy conserved Angular
momentum conserved Total momentum conserved,
so center of mass moves at constant velocity
(providing 6 more constraints).
22
For continuum approximations
apply.
Rather than solving for the position of each
particle individually, instead compute the
evolution of the phase space density f (x, v,
t) At any instant in time, each particle is
represented by a point in the 6-dimensional space
(x, v). There are so many particles, this space
is filled with points. f represents the density
of points in this space, and it evolves in time
according to the Boltzmann equation Hard part
is evaluating the collision term. Common to use
the Fokker-Planck approximation. Continuum
methods work well for dense stellar systems, but
not when single particle interactions (binaries)
are important.
23
Timescales in N-body problems.
Most fundamental is the crossing-time. Consider
a star cluster of radius R which contains N stars
of mass m By the virial theorem, for a system in
equilibrium, the sum of kinetic and potential
energies for a single star is
So
For N104, m 0.5 solar masses, R 4 pc, tcross
5 million years But age of cluster is about 10
billion years gtgt tcross In addition, orbital time
of binaries in cluster can be ltlt
tcross Multi-timescale problem
24
Computational Tasks

• Setup distribution of N particles
• Compute forces between particles
• Evolve positions using ODE solver
• Display/analyze results

25
1. Setup initial distribution of particles
Can be complex for large N Need realistic model
of mass distribution in cluster, galaxy, etc.
26
2. Computing Forces between particles.
Magnitude of force on ith particle This
diverges as distance between particles --gt 0 Can
cause very small time steps. Solution is to use a
softened potential e
softening parameter Physically, this eliminates
the formation of binaries with r lt e Hard
binaries (very small separation) are an important
source of energy in clusters this means e should
be as small as possible
27
Direct summation is most straightforward method
of evaluating F But, number of operations
scales as N(N-1)/2 Severly limits number of
particles, usually N lt 104 Motivates finding more
efficient techniques (more later)
28
3. Evolve positions using ODE solver
Could use any ODE solver (e.g. Runge-Kutta,
Burlisch-Stoer, ) Must balance accuracy versus
efficiency Need many particles to capture
dynamics correctly, which can be just as
important as the accuracy of any one particle
orbit (except for planetary orbits, when N
small). Perhaps most popular method is leap-frog.
29
Leap-frog scheme
Define positions (x) and forces (F) at time level
n velocities (v)
at time level n1/2 Then, for ith particle
To start integration, need initial x and V at two
separate time levels. Specify x0 and v0 and then
integrate V to Dt/2 using high-order scheme
