Crash Data Collection and Analysis

1
Crash Data Collection and Analysis

• Archana Ganapathi
• Department of EECS, UC Berkeley
• (archanag_at_cs.berkeley.edu)

2
ROC Philosophy

• If a problem has no solution, it may not be a
  problem, but a fact, not to be solved, but to be
  coped with over time. Shimon Peres

3
Motivation (1)

• Collect real failure/attack information
• to drive benchmarks
• evaluate our ideas via prototypes tested using
  benchmarks

• help us select problems to tackle

4
Motivation (2)For the good of the industry

• Determine dominant cause Windows crashes
• Document crash likelihood of SW/HW components
• Discovering product dependability
• Build oracle for system behavior

5
Motivation (3)My machine crashes

• Since 2/25/04
• 3 system crashes
• 30 application errors
• 177 application hangs
• Who cares?
• I do!
• People who share similar experiences
• In general, customer uproar

6
Data Source (so far)

• 300 research machines in the EECS department
• Windows XP SP1
• Relatively low variability in user profile
• Caveat data might be unrepresentative of many
  users


7
Data Collection

• Collect minidumps that contain
• The Stop message/parameters/data
• Loaded drivers
• Processor context for processor that stopped
• Process info/kernel context for process/thread
  stopped

• The Kernel-mode call stack for thread that stopped

8
How we collect minidumps

• Corporate Error Reporting
• http//www.microsoft.com/resources/satech/cer/
• Manage error reports/msgs generated by WER and
  other programs

• Configure clients to redirect reports to CER
  shared directory

9
CER setup

• Modify group policy for sending error reports to
  directory in local server

• Easy-to-install software for server
• Use software to configure/view
• CER shared directory and policies
• Per machine/user crash statistics

10
Crash reporting

• Transparent to user
• No prompt for user to send crash report
• Auto direct crash reports to local server instead
  of Microsoft

• Frequency of collection
• synchronized with application and system crashes
  on computers


11
Parsing the crash dumps

• Use Microsofts publicly available debugging
  tools

• Load crash dump and analyze using
• symbol server
• executable images

12
Analysis results

• What happened that is immediately responsible for
  the crash

• exact error code
• brief description, primarily for debugging
• Bucketing info, e.g. "driver fault"
• Details for debugging, e.g. stack contents

13
Sample Results
14
Raw Crash Data is Skewed

• User retry
• System instability period
• Inter- and intra-app related crashes

15
Sample Results
16
Sample Results
17
Time-based Crash Filter
18
What do we want to know from this data?

• Do some apps appear to crash more than others?
• Are some dlls more highly correlated with crashes
  than others?

• Usage, design etc

19
Common Hypotheses

• Microsoft OS is unreliable and causes most
  crashes

• Third party dlls arent as well written as
  Microsoft dlls

• Different applications in the same category crash
  more than others

20
Application Categories
21
User behavior study

• How regularly do people use different
  applications?

• Do people behave differently if different things
  crash?

• How frequently do people proactively reboot their
  computer for system stability?


22
Preliminary User Survey
23
Crashes by app category
24
Digging deeper

• Based on stack and symbols
• Microsoft tools categorize cause of crashes
• Our analysis is only as accurate as their
  analysis tools allow us to be

25
Crashes by application
26
Crashes by component
27
Who is responsible for these faulty components?!

• Hungappno one and everyone
• Dllswhoever writes them
• Exeswhoever writes them

28
Applications that hang
29
Bad components
30
Who wrote the crashing components?
31
Application Dependencies
App a
App b
App c
Time
0 5 10 15 20
25 30 35
40
32
Inter-app dependencies
33
System Crashes

• XP operating system crashes very rarely!
• More impactingmost require reboot
• 4/490 isnt enough data to study system
  crashes!!

• Copied system crash dump files from peers
  C/windows/minidump directory

34
50 System Crashes

• CLASSPNP.SYS 2
• win32k.sys 2
• SynTP.sys 1
• TDI.SYS 1
• ino_fltr.sys 1
• ks.sys 1
• drvnddm.sys 1
• ntkrnlmp.exe 1
• Pool_Corruption 1

• watchdog.sys 7
• ar5211.sys 6
• ibmpmdrv.sys 6
• ati3duag.dll 5
• SYMEVENT.SYS 3
• ipsecw2k.sys 3
• memory_corruption 3
• ialmdev5.DLL 2
• PSCRIPT4.DLL 2
• ntoskrnl.exe 2

35
50 System Crashes
36
Limitations of this analysis

• No info on how long each application was used
  before crash

• Need metrics on system and application usage
• Skewed by user communitys usage patterns

37
Useful Metrics

• Availability
• system uptime
• CPU(s)
• processes, processor queue length, non-idle
• Memory
• available physical memory, free swap space
• Disk(s)
• free space
• Network(s)
• IP address, packetsbytes sentreceived/sec

38
User survey limitations

• Data only as accurate as user reports
• Difficult to estimate time spent using each
  application

• Hard to distinguish active usage from background
  processes

39
Future Work

• Expand data set
• Non-academic environment
• Other operating systems
• Perform fine-grained inter-application dependency
  analysis

• Compare failure paths of related crashes

40
Concluding Thoughts

• Lots of interesting patterns to be learned from
  crashes

• Getting data is difficult
• Thats why Im here?
• I would love to share analyzed results with data
  contributors!

41
Questions/comments?

• UC Berkeley ROC website http//roc.cs.berkeley.ed
  u
