Title: Seizure Recovery System For Fuel System Distributor


1
Seizure Recovery System For Fuel System
Distributor
  • Mid Point Review
  • Sponsored by Cummins Engine Company
  • Team 11
  • Michal Brown, Keron Miller,
  • Sean Edwards, Ben Nuttall

2
Design Request
  • Our objective is to design a mechanism that will
    enable the rotor to break away from the gear pump
    shaft when the rotor seizes and then re-engage at
    the same timing.

3
Progress Choices
1. Continue to generate concepts until the team
can decide on a concept that will obviously be
successful. 2. Focus on analyzing the current
concepts in more detail.
4
Milestones for this semester
  • Concentrate on the concepts we have established
    rather than continue to focus on the generation
    of additional concepts
  • Perform detailed analysis of all current
    concepts.
  • Apply appropriate mathematical models to concepts
    to determine if the design will satisfy the
    customer specifications.

5
Analysis
  • An additional design consideration is that the
    drive sometimes rotates in reverse. Negative
    torque should not cause angular misalignment or
    disengagement.
  • Establish whether the current concepts can be
    fabricated to fit within the space limitations of
    the design.

6
Photos
7
Customer Original Design
Original parts
8
Customer Interim Solution
Part modifications
9
Design Concepts
Concept 1
10
Design Concepts
Concept 2
11
Design Concepts
Concept 3
12
Design Concepts
Concept 4
13
Design Concepts
Concept 5
14
  • Visit our project webpage

www.eng.fsu.edu/nuttall/cummins
15
(No Transcript)
16
Questions?
