Batten Down the Hatches Deploying a Firewall

1
Batten Down the Hatches Deploying a Firewall

• Michael Herz Department of Civil Engineering
  December 2nd, 2003

2
What happened?

• found viruses and compromises
• realized the holes and weaknesses in operating
  systems and software
• observed the response from the manufacturers
• observed users behaviour
• computing environment became more and more
  complex and heterogeneous

3
The Vulnerabilities

• everything has holes
• hardware routers, switches, printers
• operating systems Windows, Unix
• software e-mail clients and servers, web
  servers, office packages
• administrative mistakes
• error-prone GUI configuration
• bad passwords
• missing patches
• outdated anti-virus definitions

4
The Attack Methodology

• scan for open vulnerabilities
• bait using social engineering
• baiting e-mails
• tempting web pages
• tempting newsgroup posting
• exploit and deploy
• virus
• back-door
• zombie
• network service

5
Exploit Characteristics

• hide in RAM, existing files, new files
• some are benign and some malignant
• replicate through network services, e-mail, disks
• many variants
• not always a virus

6
What This Leads To

• frustrated users and wasted time
• destroyed data and hardware
• online storage for sensitive material
• consumed network bandwidth -gt denial of service
• consumed system resources -gt slowness crashes
• stolen passwords -gt future compromises
• stolen data -gt identity theft
• back doors leave systems critically exposed

7
Where We Were

• a few protocols were blocked at the campus
  boundary
• most people used up-to-date AV software
• most people patched their operating systems and
  software in a timely fashion
• many people used insecure passwords
• most people never changed their passwords
• some people used software firewalls
• compromises were a daily occurrence within our
  department

8
What We Depended On for Security

• operating system and software manufacturers to
  identify, notify, and provide solutions for
  vulnerabilities
• anti-virus software manufacturers to identify
  viruses and provide protection
• the kindness of strangers
• consideration of attackers
• the correct sequence of events

9
Why Firewall?

• There is no way to ensure a system is
  uncompromised or secure.
• Many users deal with confidential information.
• If we cannot guarantee that our systems are
  secure, we do not have the freedom to carry out
  our daily activities.

10
What will a Firewall do?

• A firewall will not protect you from any of the
  dangers associated with computing.
• A firewall potentially reduces the risk of
  encountering these dangers and potentially makes
  it more manageable.

11
The Civil Network

• Divided in 3 Class C networks
• Faculty and Staff Network
• 200 computers
• average 600kbps in and 300kbps out
• high risk users
• high security required
• very heterogeneous environment
• Grad Student Network
• high and low network performance demands
• high risk users
• medium security required
• slightly heterogeneous environment
• Undergraduate Student Network
• high network performance demands
• very homogeneous environment
• UW Wireless network
• NAA protected

12
Firewalls applied to The Civil Network

• Divided in 3 Class C networks
• Faculty and Staff Network
  Commercial Firewall Solution
• 200 computers
• average 600kbps in and 300kbps out
• high risk users
• high security required
• very heterogeneous environment
• Grad Student Network
  ACL on the switch/router
• high and low network performance demands
• high risk users
• medium security required
• slightly heterogeneous environment
• Undergraduate Student Network
  ACL on the switch/router
• high network performance demands
• very homogeneous environment
• UW Wireless network
  ACL and authentication
• NAA protected

13
Firewall Features

• Stateful Packet Inspection
• E-mail Filtering
• customizable file types
• SMTP POP
• Hardware VPN
• 200 clients and 1000 tunnels
• 3DES (168-Bit) Performance 45 Mbps
• Web Filtering
• Network throughput
• 128,000 concurrent connections
• 190 Mbps performance
• 100 Mb Full Duplex WAN LAN and DMZ
• Antivirus integration
• NAT Services
• DHCP Services

14
My Rules

• Block everything coming in
• Allow HTTP in to Web Server
• Allow POP3 and SMTP in to Mail Server
• Allow VPN in to all stations

15
Rule Exceptions

• 1 Backup Server in to back-up clients
• 2 Management Servers in to managed clients
• 1 WAN class C subnet in to 1 Terminal Server
• 1 WAN class C subnet in to 1 File Server
• 1 WAN class C subnet in to 1 File Server
• WAN in to 1 FTP Server
• WAN in to 2 Web Servers

16
Filtered E-mail Attachments

• .ade Microsoft Access project extension
• .adp Microsoft Access project
• .bas Microsoft Visual Basic class module
• .bat Batch file
• .chm Compiled HTML Help file
• .cmd Microsoft Windows NT Command Script
• .com Microsoft MS-DOS program
• .cpl Control Panel extension
• .crt Security certificate
• .exe Program
• .hlp Help file
• .hta HTML program
• .inf Setup Information
• .ins Internet Naming Service
• .isp Internet Communication settings
• .js JScript file
• .jse Jscript Encoded Script file
• .lnk Shortcut
• .mda Microsoft Access add-in program

• .mde Microsoft Access MDE database
• .mdz Microsoft Access wizard program
• .msc Microsoft Common Console Document
• .msi Microsoft Windows Installer package
• .msp Windows Installer patch
• .mst Visual Test source files
• .pcd Photo CD or Visual Test compiled script
• .pif Shortcut to MS-DOS program
• .reg Registration entries
• .scr Screen saver
• .sct Windows Script Component
• .shs Shell Scrap Object
• .url Internet shortcut
• .vb VBScript file
• .vbe VBScript Encoded Script file
• .vbs VBScript file
• .wsc Windows Script Component
• .wsf Windows Script file
• .wsh Windows Script Host Settings file

17
Access Attempt Statistics

• data collected from a single non-server
  machine on the local subnet using ZoneAlarm
• 864 pings (RPC exploit) from 129.97.xxx.xxx
  were subtracted

18
Top 15 Ports

864 pings (RPC exploit) from 129.97.xxx.xxx
were deleted
19
Whos at that Port?
a top 10 target
port info courtesy of Internet Storm Center
http//isc.incidents.org/
20
Is it working?
back to Top 15 Ports
21
Firewall GUI Demo
22
Where Do We Go From Here?

• firewall
• patching
• antivirus software
• port scanning
• penetration testing
• honey-pot deployment
• network sniffing
• system validation
