How Weather Patterns Influence Bird Movements

1
How Weather Patterns Influence Bird Movements

• Bryan GuarenteUniversity of Illinois at
  Urbana-ChampaignAtmospheric Sciences
  DepartmentCOS Presentation
• Monday March 21, 2005

2
Outline

• Bird Navigation
• How To Read Weather Maps
• Two Caveats
• Case Studies
• Helpful Resources

3
Bird Navigation

• How do birds migrate?
• Using landmarks (Point Peleé)
• Staying within the lines
• Highways (I-95)
• Ridges (Blue Ridge Hawk Mountain)
• Coastlines (Atlantic Coast, Lake Michigan)
• Magnetism of the earth
• Sun, Stars, Moon
• Believing their instincts
• Avoiding weather or go with weather

4
Bird Navigation (cont)

• Most important thing
• Which family of birds?
• What habitat is needed?
• What time of year?
• Circlers (Soaring)
• Falconiformes
• Gruiformes
• Direct Flights (short and long distance)
• Anseriformes
• Charadriiformes
• Passeriformes

5
Bird Navigation (cont)

• Circlers
• Thermals pockets of warm rising air
• Thermals enhance a good migration day for
  circlers
• Strong upper level winds also make for a good
  circler migration day
• Thermals are not required but circlers will limit
  distances on days without thermals

6
Bird Navigation (cont)

• Short Distance vs. Long Distance Migrants
• Long migration is not effected greatly by weather
  patterns
• More dependant on season or amount of sunlight
• Examples Arctic Tern, Sandpipers, and Barnacle
  Goose
• Short migration is effected greatly by weather
  patterns
• Less dependant on season or amount of sunlight
• Examples Most Passerines and Waterfowl

7
Problems encountered

• What would you do if you were flying and you
  encountered
• Significant Cloud Coverage?
• Frozen Precipitation?
• Strong Winds opposing your motion?

• Land!
• Birds experience these conditions and are
  forced to land all the time.

8
Hows the weather up there?

• Upper atmosphere makes all the difference
• BIRDS DO NOT MIGRATE AT SURFACE
• Surface winds seldom important
• Between 1km and 5km AGL winds are the biggest
  weather factor
• 850mb (1km) to 500mb (5km) most important levels
  for winds
• However, surface weather systems effect upper
  atmosphere
• Surface cannot be ignored

9
How to read weather maps

• Birds prefer to follow winds (cross country
  flight example)
• Most maps show winds
• wind barbs ?
• All directions are the same as a compass
• Plotted as the direction the wind is FROM

10
How to read weather maps

• Rotation of highs and lows visible on surface obs

11
How to read weather maps

• Convergence and divergence will show areas of
  preferential movement to and from a location
• Multiple kinds of convergence and divergence
  (directional and speed)

12
How to read weather maps

• Areas of convergence and divergence visible

13
How to read weather maps

• Streamlines
• Shows direction a bird would travel without
  outside forcing
• Can see where migrants will come from or end up
• Easiest way to see convergence at any level
• Fronts become obvious (lines of convergence)
• Fronts make some birds stop migration (strong
  pressure decline, assume bad weather)
• Uncommonly plotted especially for forecasts

14
How to read weather maps
15
How to read weather maps

• 850 mb (1km up)
• BEST place to look for strong winds that will
  promote movements
• Strong winds from preferential direction GOOD
  MOVEMENTS
• Season dependant
• Stronger winds at this level are called
  low-level jet
• The end of a low-level jet has speed convergence
  (great place to look for migrants)

16
How to read weather maps
17
How to read weather maps

• 700mb (2-2.5km up)
• Good place to look for strong winds for migrants
• Not as good as 850mb, but still important
• Low-level jet also present at this level
• Stacked strong winds (700mb strong winds above
  850mb strong winds) GOOD MOVEMENT

18
How to read weather maps
19
How to read weather maps

• 500mb (5-6km) and 250mb (10-12km)
• Winds at these levels only effect high altitude
  fliers
• Hard to track these birds
• Track vertical motions
• Upward vertical motion may lead to movement
• Barring cloud cover (which accompanies rising
  motion)
• Unproven, but feasible

20
How to read weather maps
21
How to read weather maps
22
How to read weather maps

• Jetstreaks and vertical motions
• Jetstreaks areas of fastest moving winds in
  jetstream
• Dynamical effects cause divergence

23
How to read weather maps

• Jetstream convergence and divergence

24
How to read weather maps
25
How to read weather maps
26
How to read weather maps

• Infrared (IR) Satellite Imagery
• Low pressure systems look like commas
• High clouds versus low clouds
• Figure out low level winds from low clouds (if
  present)
• Sometimes see areas of preferred heating of the
  ground (areas good for circlers)
• Nighttime cloud cover

27
How to read weather maps

• Visible Satellite Imagery
• Low pressure systems look like commas
• Cloud levels not clear in some cases
• Visible satellite not available at night

28
How to read weather maps
29
How to read weather maps

• Water Vapor (WV) Satellite Imagery
• Low pressure systems sometimes look like commas
• Rotations can be seen very clearly
• Rotations are usually associated with vertical
  motion and bad weather (can ground birds)
• Jetstream pattern is often clearly visible
• Can infer streamlines
• Images available at night
• Cannot see below 700mb

30
How to read weather maps

• Radars
• Radar Reflectivity
• Two different modes used (for small particles and
  large particles)
• Clear air mode
• Precipitation mode
• Clear air mode
• Easy to pick up fronts and smaller particles
  (clutter issues)
• Precipitation cannot be present
• Precipitation Mode
• Hard to pick up fronts and smaller particles
• Precipitation will be present
• May be hard to distinguish birds from
  precipitation

31
How to read weather maps
32
Two Caveats?!

• Good weather patterns do not always equal good
  migration
• All weather forecasts are model produced
• Models differ
• Models are made using our current understanding
  of the atmosphere
• Weather forecasts beyond three days are
  pipedreams
• Because of this models are NEVER correct!
• BUT, we need to look for guidance somewhere

33
Experience is the key

• As it is with birds
• The more you look, the more you understand
• This may not come easy for some of you
• Every day forecasts change
• Look often and be flexible
• Are you ready for your first try?

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
What happened on this day?

• Black-legged Kittiwake (Rissa tridactyla) showed
  up near Chicago (reported by Eric Walters)
• Refer to emails on IBET (8077, 8078, 8082, 8087,
  8091) for discussion of patterns
• For sightings refer to IBET (8094 BLKI, 8096
  BLKI, 8100 FEHA, 8101 SACR)

42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
What happened on this day?

• Sandhill Cranes (Grus canadensis) clouded the
  Chicago area skies (1,269 reported by Matt
  Karabestos 400 reported by Leslie Cummings)
• First real push of Sandhill Cranes (G.
  canadensis) all season
• IBET posts (9514 9518, 9521, 9526, 9528)

51
Summary

• Upper-level winds are the most important factor
  (weather-wise)
• The longer time scale the better
• Areas of convergence runways
• Surface fronts play a role but can be avoided by
  larger birds if they are weak fronts
• Clouds, precipitation, and strong winds opposing
  motion will make a bird land

52
Useful Resources

• http//www.atmos.uiuc.edu/bguaren2/
  birdweather/index.html
• http//www.rap.ucar.edu/weather
• http//weather.cod.edu/
• http//vortex.plymouth.edu/
• http//www.crh.noaa.gov/

53
Other helpful sources

• Severe and Hazardous Weather 2nd edition
• Rauber, Charlevoix, and Walsh
• Excellent introductory weather book
• Written with non-science students in mind
• Figures from todays presentation from book

54
Thank you!

• COS
• IBET
• COS member Tom Kelly
• Bruce D. Lee and Catherine Finley
• Albert Guarente (my dad)
