NEPTUNE Power System Protection

1
NEPTUNE Power System Protection

• Kevin Schneider, Chen-Ching Liu
• Department of Electrical Engineering, University
  of Washington
• Harold Kirkham
• Jet Propulsion Laboratories

2
Protection Areas

• 1) Medium voltage backbone protection
• 2) Internal node protection
• 3) Low voltage protection

3
Backbone Protection Layers

• 1st- Differential measurements and pilot tones,
  combined.
• 2nd- Primary zone distance relays.
• 3rd- Secondary zone distance relays

4
Backbone 1st Protection Layer

• Uses two protection techniques
• 1) Differential current protection
• 2) Pilot tone relaying

5
Normal Operating Conditions

• Differential current measurements.
• Double pilot tone.
• DO NOT TRIP
• Primary relay in place.
• Back up relay in place.

6
Loss of Both Signals

• Differential comms. are lost.
• Pilot tones are lost.
• PRIMARY TRIPS BREAKER
• Back up relay in place.

7
Loss of Differential Comms.

• Differential comms. Are lost.
• Pilot tones are not lost.
• DO NOT TRIP
• Primary relay in place.
• Back up relay in place.

8
Loss of Pilot Tones

• Pilot tones are lost.
• TRIP IF DIFFERENTIAL PROTECTION DETECTS FAULT
• Back up relay in place.

9
Backbone 2nd Protection Layer
10
Backbone 3rd Protection Layer
11
Backbone Relay Coordination
12
Node Protection Layers

• 1st- Node differential protection step 1
• 2nd- Converter differential protection
• 3rd- Node differential protection step 2

Note the 1st and 3rd layers work on the same
principle but their resulting protective actions
are different.
13
(No Transcript)
14
Node 1st Protection Layer
Current 1 Current 2 Current 3 0 If a fault
is detected then the running converter is secured
and the second unit is started
15
Node 2nd Layer Protection

• Same techniques as transformer differential
  protection
• Must account for losses in the main power
  converter
• If a fault is detected the converter is secured
  and the other unit started

16
Node 3rd Layer Protection
Current 1 Current 2 Current 3 0 Similar to
the first layer except that in the event of a
fault the entire node is secured through the
opening of adjacent node backbone breakers
17
Node Relay Coordination
Note all three layers will actuate before the
3rd layer of the backbone protection. This will
prevent unnecessary loss of loads.
18
Node Low Voltage Protection

• Low voltage protection is similar to distribution
  system protection
• Can use any of the following methods
• 1) Over current
• 2) Distance relaying
• 3) Ground fault indication
• 4) A combination of methods

19
Questions?
