Z2070 Windows CE'NET Handheld Computer

1
Z-2070Windows CE.NETHandheld Computer
ZEBEX Industries Inc. TBU Sales Dept.
March 30, 2009
2
Content

• ZEBEX Terminal Product Road Map
• Z-2070 Hardware
• Z-2070 PowerPack Utility

3
Product Road Map
OS
New
WIN CE.Net Handheld / Fixed Computer
WIN CE.NET
Z-2060 Series
Z-2070 Series
Z-7010
Proprietary Handheld Computer
Proprietary
Z-2050 Series
Entry Level Data Collector
8051 C Complier
Z-1060
Z-1070 Series
Z-2030 Series
PDL-20
8-bit C-MOS
32-bit, Intel PXA 270 520MHz
32-bit, Motorola 33MHz
CPU
4
Content

• ZEBEX Terminal Product Road Map
• Z-2070 Hardware
• Z-2070 PowerPack Utility

5
Overview
Z-2070 Windows CE.NET Handheld Computer
6
Z-2070 Features
1gt Open architecture
5gt Long battery life

• - OS Microsoft WIN CE.NET 5.0
• - CPU Intel PXA270 , (Max.520MHz)
• Memory 64 MB RAM
• 64 MB F-ROM

• Li-ion rechargeable battery pack
• 3.7V 2,200mAh / 3,300mAh
• 10 hours w/o wireless battery life
• 48 hours with wireless battery life

2gt Display
6gt Rugged construction

• - 2.4 TFT QVGA 240x320
• TFT Tran missive color display
• with Touch Panel

• Drop Durability 1.5m onto concrete
• Dust splash resistance IP54

7gt Interface
-RS232 - USB 1.1 Client
3gt Integrated Selection
- Wi-Fi 802.11b or b/g (Z-2070WL)
8gt Expandability

• Mini SD I/O Card slot for WLAN or
• memory reserved
• USB Cable ( Terminal to PC )
• Travel Adapter
• Cradle via USB and RS-232 Interface

4gt Function of Jacket
Z-2070BA Z-2070WL

• 1D Laser (Symbol SE-955)
• 1D CCD ( ZEBEX CT-131)
• GPRS 1D Laser (Symbol SE-955)
• HF RFID (ISO-15693 or 14443)

7
Z-2070 Model List
8
Z-2070 Jacket List
9
System Configuration
1D Laser 1D CCD HF RFID
GPRS 1D Laser
IEEE 802.11b/g
GPRS/EDGE
WWAN
WLAN
ISO RFID Tag (ISO 15693 ISO-14443)
10
Accessories
For Z-2070 Device unit
Z-2070BA
Z-2070WL
(1)
(2)
(3)
Mini SD WLAN Card
USB Cable (For Z-2070 only)
USB AC Adapter
Jackets
(1) (2) (3)

IEEE 802.11 b/g
For CRD-70 Cradle unit
Options
Cradle
USB Cable
Adaptor
Mini SD Card
RS-232 Cable
WLAN 802.11b
WLAN 802.11b/g
With Extra Battery Charge slot
11
Focus Market
12
Content

• ZEBEX Terminal Product Road Map
• Z-2070 Hardware
• Z-2070 PowerPack Utility

13
Z-2070 PowerPack Utility
What is PowerPack?

• ZEBEX WinCE Software Utilities
• Easy to Manage ZEBEX WinCE Products
• Reduce S/W Development Cost
• Protect Vendors Software Properties
• Integrated WinCE Application Software

14
Z-2070 PowerPack Utility
lt Single Device Utility gt

• Shortcut Manager
• Backup Restore
• Triple Code
• Firmware Information

• Backlight
• Calculator
• Launcher
• Switch
• Tray Scan

This application is located on path
\settings\control Panel\.
15
Z-2070 PowerPack Utility
Backlight

• LCD and Keyboard
• Backlight ON/OFF
• Auto Mode
• Adjust LCD Brightness

16
Z-2070 PowerPack Utility
Calculator

• Calculator Keyboard mapping
• design for Handheld Computer

Z-2070 keypad
17
Z-2070 PowerPack Utility
Launcher

• Auto launch the checked items when startup
• Use Profile can define the characteristics of
  device

18
Z-2070 PowerPack Utility
Switch

• Easy Switch the Wi-Fi and Bluetooth
• Useful for power saving

19
Z-2070 PowerPack Utility
Tray Scan

• Enable/Disable Barcode Scanner
• Emulate Keyboard input when scan
• - Terminator setting
• - Preamble setting
• Barcode Setting

20
Z-2070 PowerPack Utility
Shortcut Manager
Catalog ? FunctionSimple but Powerful !!

• Function Key Define

Readable Description No more _at_.EXE
Easy to customize your own Catalogs and Functions
more Readability, more Easy
21
Z-2070 PowerPack Utility
Backup Restore

• Registry data Backup
• Database Backup
• Files/Directions Backup
• Backup into removable storage
• Restore from removable storage
• System duplicate

22
Z-2070 PowerPack Utility
Triple Code

• UID - Device S/N , Backup/Restore depend on UID
• VID - ZEBEX Vendor ID Code
• SIC - Software ID code

UID
VID
Check the Triple Code Before AP S/W executive!!
UID
Zebex Distributor
VID
SIC
UID
AP S/W
Dealer or S/W Company
VID
END User
SIC
23
Z-2070 PowerPack Utility
Firmware Information

• Power Pack Version
• OS Version
• Device Model name
• Device ID (click Model)

Click Model to Show out Device ID
24
Thank You!
