Glacial Facies and Fabrics

1
Glacial Facies and Fabrics
2
General Review of Facies

• Facies
• A body of sediment with a distinctive combination
  of properties that distinguish it from
  neighboring sediments.
• Stratigraphic units distinguished by lithologic,
  structural, and organic characteristics
  detectable in the field.

3
3 Methods of Describing Facies

• Genetic facies
• State or imply a specific mode of formation
• Dune-bedded sands
• Lithofacies
• Only describes the physical characteristics of
  the deposit
• Silt laminae
• Cross-bedded sand
• Biofacies
• Defined by the presence of, or lack of,
  biological material

4
Ice-marginal Environments
Till Ablation till
G-lac. Drift Dropstones
G-lac. Drift Kame delta
Till Lodgment
Till Moraines
Alluvium Kame terraces
Alluvium Outwash/drift
Alluvium Eskers
Alluvium Outwash
5
Sequences Events and Materials

• Active ice
• Lodgment
• Flowtill
• Outwash
• Stagnant ice
• Melt-out

6
Till Fabrics

• Orientation of clasts in space
• Reflects accumulated deformation

7
Till Fabrics
8
Modified Foliation

• Finally, foliation fabric forms fully!

9
Glacial Sequences (Boulton)

• Spatial and temporal distribution of erosion AND
  deposition
• Marginal till sequences

10
Glacial Sequences (Boulton)

• Spatial and temporal distribution of erosion AND
  deposition
• Marginal till sequences
• Ice sheet synthesis

11
Glacial Sequences (Boulton)

• Spatial and temporal distribution of erosion AND
  deposition
• Marginal till sequences
• Ice sheet synthesis

12
Till Sequence example Illinois

• Loess/Malden till/red Tiskilwa till/gray Tiskilwa
  till/bedrock
• Unclear boundaries and genesis
• Interpretation of genetic facies

13
Till Sequence example Illinois
14
Montana plains

• Fullerton et al., 2004, USGS SI-2843

15
Till sequence

• Illinoisan
• Wisconsinan
• Late Wisconsinan
• But
• How know age?
• Alternative working hypotheses?

16
Till facies

• Glacier tills
• Ice sheet tills
• Modified tills

17
Till facies
18
Drift of Coastal New England
Interlobate Moraine
Ground Moraine
Terrestrial End Moraines
Marine(?) End Moraines
19
End Moraine Facies
Mud/debris flow
Flowtill
Sheetflow
Debris flow
Bar gravel
Debris flow
Sheetflow
HyperX flow
HyperX flow
Sheetflow
Distal flowtill
HyperX flow
Sheetflow
Stream flow
Stream flow
Overbank
Gelifluction
20
Facies Distribution

• NOTE
• May be gradation from pure till to type A as well
  as among types!

21
Distinction from Outwash
22
Grounded Ice andGlaciofluvial locations
23
Grounded Ice FaciesUnstratified Diamicts

• Bimodal Partical Size Distribution
• Unsorted pebbles, cobbles, and boulders
• Interstitial matrix of sand, silt, and clay
• Elongate particles show preferred orientation
• Some crude imbrication
• Long axes dipping upstream

24
Stratified Diamicts

• Sediments generated by
• Supraglacial, englacial, subglacial processes
• Better sorting
• Lack the bimodal size distribution associated
  with direct deposition
• Pebbles may be rounded by meltwater transport
• Some stratification from reworking
• Seen in the form of kames, kame terraces, eskers
